Canon IR Series Manual de usuario

User’s Guide

Network ScanGear

ENG

Please read this guide before operating this equipment.

After you finish reading this guide, store it in a safe place for future reference.

Organization of this User’s Guide

Introduction

Installation

Before Scanning

Scanning

Index

Chap 1

Chap 2

Chap 3

Chap 4

• The contents of this manual are subject to change without prior notiﬁcation.

• Although every effort is given to the production of this manual, please notify any errors or omissions you should notice.

• The contents of this manual may not be reproduced without permission.

Table of Contents

How to UseThis Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv

Symbols Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

About Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

AboutTrademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Chapter1 Introduction

Introduction to the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Readme File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Help Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

Chapter2 Installation

Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

Uninstallation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Chapter3 Before Scanning

Switching the Scanner Online and Ofﬂine . . . . . . . . . . . . . . . . . . . . . . . .3-2

Switching the Scanner Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Switching Ofﬂine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Selecting the Network Scanner to be Used . . . . . . . . . . . . . . . . . . . . . . .3-8

Starting Network ScanGear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Network ScanGear MainWindow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

Scanning buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

Preview Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

Tab sheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

Status bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

Table of Contents

iii

Chapter4 Scanning

Scanning from the Platen Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Scanning from the Feeder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Scanning from the Feeder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Ensuring Scanned Originals are Correctly Oriented . . . . . . . . . . . . . . . .4-6

Scanning Different Sized Originals Together . . . . . . . . . . . . . . . . . . . . .4-7

Speciﬁng the Scanning Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

Summary of Important Features and Settings . . . . . . . . . . . . . . . . . . .4-10

Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

Image Processing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

Settings for Scanning from the Feeder . . . . . . . . . . . . . . . . . . . . . . . . .4-10

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I-1

How to Use This Manual

Symbols Used in This Manual

In this manual the following headings are used to mark important notes.

IMPORTANT

•

This indicates an important item or restriction that must be observed during operation. Read

carefully to avoid failure or damage to the unit.

NOTE

•

This gives reference material or supplementary information about operation. Reading is

recommended.

About Abbreviations

The following abbreviations are used in this manual.

• Microsoft

Windows

95 is referred to as “Windows 95.”

• Microsoft

Windows

98 is referred to as “Windows 98.”

• Microsoft

Windows

Millennium Edition is referred to as “Windows Me.”

• Microsoft

Windows NT

Version 4.0 is referred to as “Windows NT4.0.”

• Microsoft

Windows

2000 is referred to as “Windows 2000.”

• Microsoft

Windows

XP is referred to as “Windows XP.”

About Trademarks

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in

the United States and/or other countries.

IBM and IBM PC/AT are trademarks of International Business Machines Corporation.

Other company names and product names referred to in this manual are trademarks or

registered trademarks of the respective companies.

CHAPTER

1-1

Introduction

This chapter gives basic information required in order to use Network ScanGear.

Introduction to the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Readme File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Help Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

Introduction to the Software

1-2

Introduction

Introduction to the Software

Features

Network ScanGear is a 32-bit TWAIN-compliant scanner driver that allows computers on a

network to use a Canon imageRUNNER series digital copier that is located in the same

subnet as a scanner.

It consists of the following software.

■

ScanGearTool

This software is installed together with the Network ScanGear driver, and enables the

user to select the device name of the scanner on the network to be used for scanning with

the Network ScanGear driver. No scanner is selected during Network ScanGear

installation, so you must start the ScanGear Tool and select a scanner before use.

■

Network ScanGear driver

This is a scanner driver that can be accessed from TWAIN-compliant applications.This

driver is then used when scanning.

Readme File

The readme.txt ﬁle includes important notes on use of the product. Be sure to read it before

starting.

Help Information

When using Network ScanGear, help is always available from the following sources. Use

them when you are unsure about how to do an operation.

• When Network ScanGear is running, click the button in the toolbar to display Network

ScanGear help.

• When the ScanGear Tool is running or the Network ScanGear driver settings dialog box is

displayed, click the Help button for help relating to the items in the dialog box.

Operating Environment

1-3

Introduction

Operating Environment

Network ScanGear requires the following operating environment.

Hardware

• IBM PC/AT or compatible computer running Windows 95/98/Me/NT4.0/2000/XP

• At least 100 MB of available hard disk space (recommended)

NOTE

•

Space equal to at least twice the size of the scanned image on the hard disk is required.

• Main memory must meet the following conditions:

For Windows 95/98/Me:at least 16 MB (32 MB or more recommended)

For Windows NT4.0/2000:at least 32 MB (48 MB or more recommended)

For Windows XP: at least 96 MB (128 MB or more recommended)

• Monitor providing at least 640 x 480 dot display resolution (800 x 600 dot or greater

recommended), at least 256 colors

• A network host adapter providing TCP/IP and UDP/IP protocols over Ethernet or Token

Ring

• The iR series digital copier. (With some imageRUNNER series digital copiers a Network

Scanner Kit is necessary.)

NOTE

•

When scanning a large number of images or images that are very large, memory shortage can

result in errors or greatly reduced scanning speed. In this case, take one or more of the following

measures.

- Delete unnecessary ﬁles from the hard disk to release additional disk space, or increase the hard

disk capacity.

- Rescan at a lower resolution.

- Add more RAM.

- Set the virtual memory size as large as possible.
