Belkin 24-Port Gigabit Switch Manual de usuario

Router

10/100

1000

Connection speeds:

24-Port

Gigabit Switch

(F5D5141au24)

Workstation(s) with Desktop

Network PCI Card

F5D5000au

Workstation(s) with Desktop

Network PCI Card

F5D5000au

Power Workstation(s)

with Gigabit Desktop

Network PCI Card

F5D5005au

Server(s)

Connect

up to 16

devices

Connect

up to 24

devices

Connect

up to 24

devices

16-Port

10/100 Switch

(F5D5131au16)

24-Port

10/100 Switch

(F5D5131au24)

The Belkin 24-Port Gigabit Switch allows you to easily upgrade your

network to achieve gigabit transfer speeds. Backward-compatible with

your existing 10/100 network, this Switch simply plugs in for instant high

performance. It provides your servers and workstations the capacity to

small-to-medium-sized company, the Switch is easy to install. Its

compact, 13-inch case easily wall-mounts or positions on your desktop,

and rack-mount hardware is included for optional placement in a 19-inch

rack. A metal chassis houses its internal power supply to ensure a durable

form factor. All ports automatically adjust for straight-through or crossover

cables—you don’t have to worry about cable type.

Compatible with existing 10/100 networks and major operating systems,

your 24-Port Gigabit Switch from Belkin delivers error-free transfers at

maximum network speeds.

switches through 24 switched 10/100/1000 ports

• Auto-senses and adjusts for network speed and cabling type

automatically, for easy integration into your existing 10/100

Ethernet network

• Features 13-inch case, durable metal chassis, and internal power

supply for easy assimilation into a small-to-medium-sized

business environment

• Includes rack-mount hardware for optional placement in a

19-inch rack

• Comes with a Belkin Limited Lifetime Warranty and free, 24-hour

technical support

Here’s what you need

For additional solutions,

please visit us at belkin.com

1800-BELKIN Aus

0800-BELKIN NZ

For product Enquiries, call:

24-Port Gigabit Switch

Ports

24 RJ45 10/100/1000Mbps ports

Auto MDI/MDI-X

Cabling Type

Category 5e (or better)

Standards

IEEE 802.3ab

IEEE 802.3u

IEEE 802.3

IEEE 802.3x

IEEE 802.1p

Forwarding Mode

Store and Forward

Performance

Throughput: 48Gbps

Forward Rate: (10Mbps port): 14,880 packets/sec

(100Mbps port): 148,800 packets/sec

(1000Mbps port): 1,488,000 packets/sec

MAC Address

Entries Supported: 4,000

Packet Buffer: 256K

LEDs

Power

Link

Activity

Full Duplex

Half Duplex

Collision

10Mbps

100Mbps

1000Mbps

Power Supply

100/240VAC, 50/60Hz universal input

Size: 13 x 9 x 1.7 in. (330 x 228 x 43mm)

IU chassis

Temperature Humidity

Operating: 32–113º F (0–45º C) 10-90%

Storage: -4–158º F (-20–70º C) 10-95%

Electromagnetic Emissions

FCC Class A, CE Class A, VCCI A

Safety

UL (UL 60950), CUL, CE, C-Tick, TUV (EN 60950)

Warranty

Lifetime

Technical Support

Free technical support

Package Includes

24-Port Gigabit Switch

Rack-mount bracket for rack installation

Self-adhesive rubber pads for desktop installation

AC power cord

User Manual

Warranty card





Belkin Corporation Belkin Components, Ltd. Belkin, Ltd.

310.898.1100 +44 (0) 1933 35 2000 +61 (0) 2 4372 8600

Compton • CA • USA Rushden • United Kingdom West Gosford • Australia

24PB006au

Part Number Description UPC

F5D5141au24 24-Port Gigabit Switch 7-22868-51285-2

Gigabit Desktop Network PCI Card

(F5D5005au)

5-Port Gigabit Switch

(F5D5141au5)

8-Port Gigabit Switch

(F5D5141au8)

16-Port Gigabit Switch

(F5D5141au16)


