Belkin P75341ej Manual de usuario

Introduction

User Manual

USB Plus Hub

P75341ej_F5U307ej.indb 1 05/06/2008 13:28:00

Table of Contents

Introduction 1

Installation 3

Information 5

P75341ej_F5U307ej.indb 2 05/06/2008 13:28:00

Introduction

Introduction | EN-1

Congratulations and thank you for purchasing the Belkin USB Plus Hub. The Hub

provides seven downstream USB ports that offer backward-compatible, Plug-and-Play

connectivity with all USB devices, including USB 1.1 (or low- and full-speed) devices, as

well as with USB 2.0 (or high-speed) devices. This includes such peripherals as scanners,

printers, mass-storage devices, and high-resolution cameras. The Hub is self-powered,

which allows you to cascade devices with additional hubs, so that up to 127 USB devices

may be connected to a single port.

The Hub lets you connect your peripherals through the back or top ports. Reserve the

top ports for flash drives and MP3 players while using the back ports for stationary

devices. The cable-management feature lets you easily remember which cables

correspond to each device. The Hub also provides a status LED for each individual port

and a master power LED.

Features

 •CompliantwithUniversalSerialBusspecification2.0(datarate1.5/12/480Mbps)

 •Backward-compatiblewithUniversalSerialBusspecification1.1(datarate

1.5/12Mbps)

 •CompatiblewithWindows®98SE,Me,2000,XP,andVista™

 •ApprovedbyUSBImplementersForum(USB-IF)

 •SupportforPlug-and-Playspecifications

 •Supportfor“hotswapping”ofUSBdevices

 •Individualport-status-indicatorLEDs

 •Four480Mbpsdownstreamports

 •FullycompatiblewithUSB1.1andUSB2.0devices

 •Cord-managementfeaturekeepscablesorganizedinonelocation

P75341ej_F5U307ej.indb 1 05/06/2008 13:28:00

Package Contents

 •USBPlusHub

 •ACPowerAdapter

 •UserManual

 •USBDeviceCable

Technical Specifications

Upstream Ports: 1

Downstream Ports: 7

Per-PortVoltage:  DC+5V

Per-PortCurrent:  500mA(max)

Power Mode: Self-powered

OperatingTemperature: 5°C~40°C

StorageTemperature: -20°C~60°C

Enclosure:  ABS

Power Supply:

 Output: DC5V,3.8A

 PlugSize: 3.5x1.3x9.5mm

Plug Polarity: Center-pin positive

Main-Power-LED Color Definitions

Off: Not operational

Red: Operational

Port-Status-LED Color Definitions

Off: No device detected

Green: Device detected

Introduction | EN-2

Introduction

P75341ej_F5U307ej.indb 2 05/06/2008 13:28:00

Installation | EN-3

Important Note: Please do not connect any USB devices to the Hub until instructed to

dosoinstep4ofthisinstallationprocedure.

1. PlugtheACadapterintoawalloutletorsurgeprotector.PlugtheDCconnectorinto

the DC power jack found on the rear of the Hub.

2. Plug the flat end of the provided USB device cable into the downstream port of your

computer, or downstream port of another hub, then plug the mini-USB connector on

the device cable into the upstream port on the rear of the Hub.

Installation

P75341ej_F5U307ej.indb 3 05/06/2008 13:28:00

Installation

|EN-4

Important Note: The Hub must be connected to a USB 2.0-compliant host in order

tofunctioninhigh-speedmode(480Mbpsdatarate).IftheHubisconnectedto

a USB 1.1-compliant host, it will operate only in low-speed or full-speed mode

(1.5Mbps/12Mbps).

3. WindowswillnowdetectyourHubandinstalltherequireddriversupport.(The

Windows“InstallNewHardwareWizard”maypromptyoutoprovideyourWindows

Installation CD to complete the driver installation process.)

Important Note: High-speed hub drivers are included with most USB 2.0 PCI

upgrade cards, and are preinstalled along with the PCI card drivers. If you purchased

an upgrade card prior to the release of high-speed hub support, please check

with your PCI card vendor for an updated USB 2.0 driver. The Belkin USB 2.0 driver

supportsallcompetitivecardsbasedontheNEChostcontrollerwiththeexceptionof

Adaptec.

4. PlugtheUSBAconnectoroftheUSBdevice,oranadditionalhub,intoanyofthe

downstream ports of the Hub.

Important Note: WhenmovingadevicefromoneportontheHubtoanother,itmay

be necessary to reinstall the USB drivers for that device.

P75341ej_F5U307ej.indb 4 05/06/2008 13:28:00

Information|EN-5

Information

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR

ELECTROMAGNETIC COMPATIBILITY

We,BelkinInternational,Inc.,of501WestWalnutStreet,Compton,CA90220,declare

under our sole responsibility that the product:

F5U307

to which this declaration relates:

ComplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.Thisequipmentmayonlybeoperatedindoors.Operationoutdoorsisin

violationof47U.S.C.301andcouldsubjecttheoperatortoseriouslegalpenalties.

CE Declaration of Conformity

We,BelkinInternational,Inc.,declareunderoursoleresponsibilitythattheF5U307,

to which this declaration relates, is in conformity with Generic Emissions Standard

EN55022:1998ClassB,EN50081-1,andwithGenericImmunityStandardEN50082-1:1992.

Belkin International, Inc., Limited Lifetime Product Warranty

What this warranty covers.

Belkin International, Inc., warrants to the original purchaser of this Belkin product that

the product shall be free of defects in design, assembly, material, or workmanship.

What the period of coverage is.

Belkin International, Inc., warrants the Belkin product for the lifetime of the product.

P75341ej_F5U307ej.indb 5 05/06/2008 13:28:00

Information

|EN-6

What will we do to correct problems?

Product Warranty.

Belkinwillrepairorreplace,atitsoption,anydefectiveproductfreeofcharge(except

for shipping charges for the product).

What is not covered by this warranty?

AllabovewarrantiesarenullandvoidiftheBelkinproductisnotprovidedtoBelkin

International,Inc.,forinspectionuponBelkin’srequestatthesoleexpenseofthe

purchaser, or if Belkin International, Inc., determines that the Belkin product has been

improperlyinstalled,alteredinanyway,ortamperedwith.TheBelkinProductWarranty

doesnotprotectagainstactsofGod(otherthanlightning)suchasflood,earthquake,

war, vandalism, theft, normal-use wear and tear, erosion, depletion, obsolescence,

abuse,damageduetolowvoltagedisturbances(i.e.brownoutsorsags),non-authorized

program,orsystemequipmentmodificationoralteration.

How to get service.

To get service for your Belkin product you must take the following steps:

1.ContactBelkinInternational,Inc.,at501W.WalnutSt.,ComptonCA90220,Attn:

CustomerService,orcall(800)-223-5546,within15daysoftheOccurrence.Be

prepared to provide the following information:

a. The part number of the Belkin product.

 b.Whereyoupurchasedtheproduct.

 c.Whenyoupurchasedtheproduct.

d. Copy of original receipt.

2. Your Belkin Customer Service Representative will then instruct you on how to forward

your receipt and Belkin product and how to proceed with your claim.

P75341ej_F5U307ej.indb 6 05/06/2008 13:28:01

Information | EN-7

Information

BelkinInternational,Inc.,reservestherighttoreviewthedamagedBelkinproduct.Allcostsof

shipping the Belkin product to Belkin International, Inc., for inspection shall be borne solely

by the purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship the

damagedequipmenttoBelkinInternational,Inc.,Belkinmaydesignate,initssolediscretion,an

equipmentrepairfacilitytoinspectandestimatethecosttorepairsuchequipment.Thecost,

ifany,ofshippingtheequipmenttoandfromsuchrepairfacilityandofsuchestimateshallbe

bornesolelybythepurchaser.Damagedequipmentmustremainavailableforinspectionuntil

theclaimisfinalized.Wheneverclaimsaresettled,BelkinInternational,Inc.,reservestheright

tobesubrogatedunderanyexistinginsurancepoliciesthepurchasermayhave.

How state law relates to the warranty.

THISWARRANTYCONTAINSTHESOLEWARRANTYOFBELKININTERNATIONAL,INC.,THERE

ARENOOTHERWARRANTIES,EXPRESSEDOR,EXCEPTASREQUIREDBYLAW,IMPLIED,

INCLUDINGTHEIMPLIEDWARRANTYORCONDITIONOFQUALITY,MERCHANTABILITYOR

FITNESSFORAPARTICULARPURPOSE,ANDSUCHIMPLIEDWARRANTIES,IFANY,ARELIMITED

INDURATIONTOTHETERMOFTHISWARRANTY.

Some states do not allow limitations on how long an implied warranty lasts, so the above

limitations may not apply to you.

INNOEVENTSHALLBELKININTERNATIONAL,INC.,BELIABLEFORINCIDENTAL,SPECIAL,

DIRECT,INDIRECT,CONSEQUENTIALORMULTIPLEDAMAGESSUCHAS,BUTNOTLIMITEDTO,

LOSTBUSINESSORPROFITSARISINGOUTOFTHESALEORUSEOFANYBELKINPRODUCT,

EVENIFADVISEDOFTHEPOSSIBILITYOFSUCHDAMAGES.

This warranty gives you specific legal rights, and you may also have other rights, which may

varyfromstatetostate.Somestatesdonotallowtheexclusionorlimitationofincidental,

consequential,orotherdamages,sotheabovelimitationsmaynotapplytoyou.

Forinformationonproductdisposalpleasereferto

http://environmental.belkin.com

P75341ej_F5U307ej.indb 7 05/06/2008 13:28:01
