Installation GREYHOUND Switch

Release

02/2021

Technical support

https://hirschmann-support.belden.com

User Manual

Installation

GREYHOUND Switch GRS1042/GRS1142

GREYHOUND Power Supply Unit GPS1-C/GPS1-K/GPS3-P

GREYHOUND Media Module GMM20/30/32/40/42

11.02.2021 Installation GREYHOUND Switch

Release

02/2021

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation GREYHOUND Switch

Release

02/2021 3

Contents

Important Information 6

Safety instructions 7

About this Manual 17

Key 18

1 Description 19

1.1 General device description 19

1.2 Device name and product code 22

1.2.1 Basic device 22

1.2.2 Power supply modules 23

1.2.3 Media modules 24

1.3 Device views 27

1.3.1 GRS1042 27

1.3.2 GRS1142 28

1.3.3 Power supply modules 30

1.3.4 Media modules 31

1.3.5 Port assignments 34

1.4 Power supply 35

1.5 Signal contact 36

1.6 Ethernet ports 37

1.6.1 1/2.5 Gbit/s F/O port 37

1.6.2 100/1000 Mbit/s F/O port 37

1.6.3 100 Mbit/s F/O port 37

1.6.4 10/100/1000 Mbit/s twisted pair port 38

1.6.5 Support of PoE(+) 38

1.6.6 Out-of-band management port 39

1.7 Pin assignments 39

1.8 Display elements 40

1.8.1 Device state 40

1.8.2 Port status 43

1.8.3 Media module status 46

1.9 Management interfaces 48

4Installation GREYHOUND Switch

Release

02/2021

1.9.1 V.24 interface (external management) 48

1.9.2 USB interface 49

1.9.3 SD card interface 50

2 Installation 51

2.1 Checking the package contents 51

2.2 Installing the SD card (optional) 51

2.3 Installing a power supply module 52

2.4 Installing a media module (optional) 53

2.5 Installing a cover panel (optional) 54

2.6 Installing and grounding the device 54

2.7 Connecting the terminal blocks 59

2.7.1 Supply voltage 59

2.7.2 Signal contact 63

2.8 Installing an SFP transceiver (optional) 63

2.9 Operating the device 64

2.10 Connecting data cables 64

2.11 Filling out the inscription label 64

3 Making basic settings 65

3.1 First login (Password change) 66

4 Monitoring the ambient air temperature 67

5 Maintenance and service 68

6Disassembly 69

6.1 De-installing a power supply module 69

6.2 Removing a media module 70

6.3 Removing an SFP transceiver (optional) 71

6.4 Removing the device 71

7 Technical data 72

7.1 General technical data 72

7.1.1 Basic device 72

7.1.2 Power supply modules 74

Installation GREYHOUND Switch

Release

02/2021 5

7.1.3 Media modules 75

7.2 Dimension drawings 76

7.3 EMC and immunity 80

7.4 Network range 83

7.5 Power consumption/power output 87

8 Scope of delivery, order numbers and

accessories 88

9 Underlying technical standards 91

A Further support 93

6Installation GREYHOUND Switch

Release

02/2021

Important Information

Notice: Read these instructions carefully, and look at the equipment to

become familiar with the device before trying to install, operate, or maintain

it. The following special messages may appear throughout this

documentation or on the equipment. The message warns of potential

hazards or calls attention to information that clarifies or simplifies a

procedure.

Symbol explanation

This is the safety alert symbol. It is used to alert you to potential

personal injury hazards. Obey all safety messages that follow

this symbol to avoid possible injury or death.

The addition of this symbol to a “Danger” or “Warning” safety

label indicates that an electrical hazard exists, which will result

in personal injury if the instructions are not followed.

This symbol points out the dangers posed by hot device

surfaces. In connection with safety notes, the disregard of these

instructions will result in injury.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided,

can result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided,

can result in minor or moderate injury.

NOTICE

NOTICE is used to address practices not related to physical injury.

Installation GREYHOUND Switch

Release

02/2021 7

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8Installation GREYHOUND Switch

Release

02/2021

Correct usage

Only use the device for those purposes specified in the catalog and in the

technical description. Only operate the device with external devices and

components that are recommended and permitted by the manufacturer.

The proper and safe operation of this product depends on proper handling

during transport, proper storage, assembly and installation, and

conscientious operation and maintenance procedures.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Requirements for connecting electrical wires

Before connecting the electrical wires, always verify that the

requirements listed are complied with.

Requirements for connecting the signal contact

The following requirements apply without restrictions:

The electrical wires are voltage-free.

The cables used are permitted for the temperature range of the application case.

First connect the ground screw on the back of the device with the protective conductor

before you set up the other connections. When removing the connections, you remove the

protective conductor last.

Exclusively switch on the device when it is installed.

Relevant for North America:

Exclusively use 60/75 °C (140/167 °F) or 75 °C (167 °F) copper (Cu) wire.

Table 1: Requirements for connecting electrical wires

The following requirements apply without restrictions:

Limit the connected voltage with a current limitation or in accordance with its application.

Observe the electrical threshold values for the signal contact.

See “General technical data” on page 72.

Table 2: Requirements for connecting the signal contact

Installation GREYHOUND Switch

Release

02/2021 9

Requirements for connecting the supply voltage

Device variant Prerequisites:

All variants All of the following requirements are complied with:

The supply voltage corresponds to the voltage specified on the type plate

of the device.

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device (for

example a switch or a plug). This disconnecting device is clearly identified.

So in the case of an emergency, it is clear which disconnecting device

belongs to which power supply cable.

For supply voltage connections with protective conductor connection: First

connect the protective conductor before connecting the wires for the

supply voltage.

If your device comprises a 2nd supply voltage connection of this type: First

connect the protective conductor before connecting the wires for the

supply voltages.

Supply with DC voltage:

The wire diameter of the power supply cable is at least 1 mm² (North

America: AWG16) on the supply voltage input.

Supply with AC voltage:

The wire diameter of the power supply cable is at least 0.75 mm² (North

America: AWG18) on the supply voltage input.

The cross-section of the ground conductor is the same size as or bigger

than the cross-section of the power supply cables.

Use a power supply cable which is suitable for the voltage, the current and

the physical load.

Install an external fuse in the conductor that is not on ground potential.

Power supply

module

characteristic

value C

All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) according to IEC 60950-1 or ES1 according to IEC/

EN 62368-1.

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Regarding the properties of this fuse:

See “Technical data” on page 72.

Table 3: Requirements for connecting the supply voltage

10 Installation GREYHOUND Switch

Release

02/2021

Power supply

module

characteristic

value K

All of the following requirements are complied with:

Supply with DC voltage:

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Connect the minus conductor to the ground potential. If the minus

conductor is not connected to the ground potential, also install an external

fuse in the minus conductor.

Regarding the properties of this fuse:

See “Technical data” on page 72.

Supply with AC voltage:

Install a fuse in the outer conductor of the power supply.

Connect the neutral conductor to the ground potential. If the neutral

conductor is not connected to the ground potential, also install an external

fuse in the neutral conductor.

Regarding the properties of this fuse:

See “Technical data” on page 72.

Power supply

module

characteristic

value P

All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) according to IEC 60950-1 or ES1 according to IEC/

EN 62368-1.

The power supply is potential-free. For power supply modules capable of

PoE, exclusively use a potential-free SELV power supply.

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Regarding the properties of this fuse:

See “Technical data” on page 72.

With redundant power supply: A positive grounding is prohibited.

Device variant Prerequisites:

Table 3: Requirements for connecting the supply voltage

Otros manuales para Hirschmann GREYHOUND GRS1042

Este manual sirve para los siguientes modelos

Otros manuales de Cambiar de Belden

Belden

Belden Hirschmann MACH1000 Series Manual de usuario

Belden

Belden Hirschmann MICE MS20 Manual de usuario

Belden

Belden Hirschmann MACH102 Series Manual de usuario

Belden

Belden HIRSCHMANN Octopus II Manual de usuario

Belden

Belden ThinkLogical TLX12 Manual de usuario

Belden

Belden Hirschmann OCTOPUS 8TX PoE-EEC Manual de usuario

Belden

Belden Hirschmann DRAGON MACH Series Manual de usuario

Belden

Belden Hirschmann MACH1040 Series Manual de usuario

Belden

Belden grass valley KULA AV Manual de usuario

Belden

Belden Hirschmann SPIDER II 8TX Manual de usuario

Belden

Belden Hirschmann Rail Switch Power Lite Manual de usuario

Belden

Belden HIRSCHMANN SPIDER II 16TX EEC Manual de usuario

Belden

Belden Hirschmann RS20 Series Manual de usuario

Belden

Belden HIRSCHMANN MACH 4000 Series Manual de usuario

Belden

Belden HIRSCHMANN OCTOPUS OS20 Series Manual de usuario

Belden

Belden HIRSCHMANN BRS20 Manual de usuario

Belden

Belden lumberg automation 0960 IOL 3816-001 Manual de usuario

Belden

Belden HIRSCHMANN Dragon PTN CSM310-A Manual de usuario

Belden

Belden Hirschmann RS20 Series Manual de usuario

Belden

Belden Hirschmann SPIDER 8TX EEC Manual de usuario

Belden

Belden HIRSCHMANN HiOS-2A Manual de usuario

Belden

Belden Hirschmann SPIDER-SL-20-08T1999999SY9HHHH Manual de usuario

Belden

Belden Hirschmann RED25 Series Manual de usuario

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTM8000 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
