Belden Hirschmann SPIDER 8TX EEC Manual de usuario

Installation OCTOPUS 8TX-EEC

Release

01/2021

Technical support

https://hirschmann-support.belden.com

User Manual

Installation

IP65/67 Switch

OCTOPUS 8TX-EEC

OCTOPUS 8TX PoE-EEC

OCTOPUS 8TX-EEC-M

2021-01-26 Installation OCTOPUS 8TX-EEC

Release

01/2021

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation OCTOPUS 8TX-EEC

Release

01/2021 3

Contents

Safety instructions 5

About this Manual 11

Legend 12

1 Description 13

1.1 General device description 13

1.2 Device view 14

1.2.1 OCTOPUS 8TX-EEC 14

1.2.2 OCTOPUS 8TX PoE-EEC 15

1.2.3 OCTOPUS 8TX-EEC-M 17

1.3 Power supply 18

1.4 Ethernet ports 18

1.4.1 10/100 Mbit/s twisted pair port 18

1.4.2 10/100 Mbit/s PoE port 18

1.4.3 Pin assignment OCTOPUS 8TX-EEC and

OCTOPUS 8TX-EEC-M 19

1.4.4 Pin assignment OCTOPUS 8TX PoE-EEC 19

1.5 Display elements 20

1.5.1 Device state 20

1.5.2 Port Status 23

1.6 Management interfaces 26

1.6.1 ACA-M12 interface 26

1.6.2 ACA22-C interface 26

1.6.3 Signal contact 28

2 Installation 30

2.1 Checking the package contents 30

2.2 Installing and grounding the device 30

2.2.1 Mounting on a flat surface 30

2.2.2 Grounding the device 31

2.3 Connecting the power supply and the signal contact lines 32

2.3.1 Connecting the signal contact (optional) 32

2.3.2 Pin assignment OCTOPUS 8TX-EEC 32

4Installation OCTOPUS 8TX-EEC

Release

01/2021

2.3.3 Pin assignment OCTOPUS 8TX PoE-EEC 33

2.3.4 Pin assignment OCTOPUS 8TX-EEC-M 33

2.4 Operating the device 33

2.5 Connecting data cables 34

2.6 Configuration (optional) 35

2.6.1 Configuration readout 41

3 Making basic settings 42

3.1 First login (Password change) 43

4 Monitoring the ambient air temperature 44

5 Maintenance and service 45

6Disassembly 46

7 Technical data 47

7.1 General technical data 47

7.2 Dimension drawings 49

7.3 EMC and immunity 52

7.4 Network range 52

7.5 Power consumption/power output 53

7.6 Signal contact 53

8 Scope of delivery, order numbers and

accessories 54

9 Underlying technical standards 56

A Further support 57

B Open Source Software used in the product 58

Installation OCTOPUS 8TX-EEC

Release

01/2021 5

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Certified usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product only according to the technical specifications.

See “Technical data” on page 47.

Connect to the product only components suitable for the requirements

of the specific application case.

Operational environment:

On the inside of vehicles

On the inside of buildings

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

6Installation OCTOPUS 8TX-EEC

Release

01/2021

Installation site requirements

When you are selecting the installation location, make sure you

observe the climatic threshold values specified in the technical data.

Operate the device at the specified ambient temperature (temperature

of the ambient air at a distance of 2 in (5 cm) from the device) and at

the specified relative humidity exclusively.

Use the device in an environment with a maximum pollution degree

that complies with the specifications in the technical data.

Note: Operation of the device in high humidity or condensing

atmospheres is exclusively allowed when using recommended

accessories with IP67 rating.

Strain relief

Note: If the strain relief is insufficient, there is a risk of torsion, contact

problems and creeping interruptions.

Relieve the connection points of cables and lines from mechanical

stress.

Design strain relieves in such a way that they prevent any mechanical

damage to cables, wires or conductors caused by external influences

or their own weight.

To prevent damage to device connections, connectors and cables,

follow the instructions for proper installation in accordance with DIN

VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.

Device casing

At ambient air temperatures > +140 °F (+60 °C):

The surfaces of the device housing may become hot. Avoid touching

the device while it is operating.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

Installation OCTOPUS 8TX-EEC

Release

01/2021 7

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Shielding ground

The overall shield of a connected shielded twisted pair cable is connected

to the ground connection on the metal housing as a conductor.

Beware of possible short circuits when connecting a cable section with

conductive shielding braiding.

Requirements for connecting electrical wires

Before connecting the electrical wires, always verify that the

requirements listed are complied with.

General requirements for connecting electrical wires

The following requirements apply without restrictions:

The electrical wires are voltage-free.

The cables used are permitted for the temperature range of the application case.

Ground the device via the ground screw.

Disconnect the grounding only after disconnecting all other cables.

Exclusively use 60/75 °C (140/167 °F) or 75 °C (167 °F) copper (Cu) wire.

The power supply cable to be connected is suitable for ambient air temperature of at least

212 °F (100 °C).

The power supply complies with the requirements for a safety extra-low voltage (SELV) as

per IEC/EN 60950-1.

Requirements for connecting the supply voltage

The following requirements apply without restrictions:

All of the following requirements are complied with:

The supply voltage corresponds to the voltage specified on the type plate of the device.

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device (for example a switch or

a plug). This disconnecting device is clearly identified. So in the case of an emergency, it is

clear which disconnecting device belongs to which power supply cable.

The power supply cable is suitable for the voltage, the current and the physical load.

Hirschmann recommends a wire diameter of 0.5 mm² to 0.75 mm² (AWG20 up to AWG18).

The following requirements apply alternatively:

Relevant when the device is supplied via 1 voltage input:

Alternative 1 The power supply complies with the requirements for a limited power source

(LPS) as per EN 60950-1.

Alternative 2 Relevant for North America:

The power supply complies with the requirements according to NEC Class 2.

8Installation OCTOPUS 8TX-EEC

Release

01/2021

Relevant for use in explosion hazard areas (Hazardous

Locations, Class I, Division 2)

This equipment is exclusively suitable for use in Class I, Division 2,

Groups A, B, C, and D or non-hazardous locations.

WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT

EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE

AREA IS KNOWN TO BE NON-HAZARDOUS.

WARNING - EXPLOSION HAZARD - SUBSTITUTION OF ANY

COMPONENT MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.

Avertissement - Risque d'explosion - Ne pas débrancher tant que le

circuit est sous tension à moins que l'emplacement soit connu pour ne

contenir aucune concentration de gaz inflammable.

Avertissement - Risque d'explosion - La substitution de tout composant

peut rendre ce matériel incompatible pour une utilisation en classe I,

division 2.

This device is an open-type device that is to be installed in an enclosure

suitable for the environment.

Exclusively use the device for the application cases specified by the

manufacturer. Failure to follow these instructions can impair device

protection.

Alternative 3 All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) as per IEC/EN 60950-1.

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Connect the minus conductor to the ground potential. If the minus

conductor is not connected to the ground potential, also install an external

fuse in the minus conductor.

Regarding the properties of this fuse:

See “General technical data” on page 47.

Relevant when the device is supplied via 2 voltage inputs:

Alternative 1 The total voltage supply meets the requirements for a limited power source

(LPS) as per EN 60950-1.

Alternative 2 Relevant for North America:

The total voltage supply complies with the requirements as per NEC Class 2.

Alternative 3 All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) as per IEC/EN 60950-1.

In both voltage inputs, install a fuse suitable for DC voltage in the plus

conductor of the power supply.

In both voltage inputs, connect the minus conductor to the ground potential.

If the minus conductor is not connected to the ground potential, also install

an external fuse in the minus conductor.

Regarding the properties of this fuse:

See “General technical data” on page 47.

Requirements for connecting the supply voltage

Installation OCTOPUS 8TX-EEC

Release

01/2021 9

E marking

The labeled devices comply with the conditions of ECE Directive No. 10:

Certified devices must be labeled with the E type approval indicator.

The labeled devices comply with the conditions of ECE Directive No. 118:

Certified devices must be labeled with the E type approval indicator.

OCTOPUS 8TX-EEC devices are suited for installation in vehicles

according to the conditions of ECE Regulation No. 118.

CE marking

The labeled devices comply with the regulations contained in the following

European directive(s):

2011/65/EU and 2015/863/EU (RoHS)

Directive of the European Parliament and of the Council on the restriction

of the use of certain hazardous substances in electrical and electronic

equipment.

2014/30/EU (EMC)

Directive of the European Parliament and of the Council on the

harmonisation of the laws of the Member States relating to

electromagnetic compatibility.

In accordance with the above-named EU directive(s), the EU conformity

declaration will be at the disposal of the relevant authorities at the

following address:

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

www.hirschmann.com

The device can be used in the industrial sector.

Interference immunity: EN 61000-6-2

Emitted interference: EN 55032

The assembly guidelines provided in these instructions must be strictly

adhered to in order to observe the EMC threshold values.

Warning! This is a class A device. This device can cause interference in

living areas, and in this case the operator may be required to take

appropriate measures.

10 Installation OCTOPUS 8TX-EEC

Release

01/2021

FCC note

Supplier's Declaration of Conformity

47 CFR § 2.1077 Compliance Information

OCTOPUS 8TX-EEC

U.S. Contact Information

Belden – St. Louis

1 N. Brentwood Blvd. 15th Floor

St. Louis, Missouri 63105, United States

Phone: 314.854.8000

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

Recycling note

After usage, this device must be disposed of properly as electronic waste,

in accordance with the current disposal regulations of your county, state,

and country.

Otros manuales para Hirschmann SPIDER 8TX EEC

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Belden

Belden

Belden HIRSCHMANN PTN-CSM310-A Manual de usuario

Belden

Belden grass valley KULA AV Manual de usuario

Belden

Belden Hirschmann RS20 Series Manual de usuario

Belden

Belden grass valley MASTERPIECE 12G-SDI Manual de usuario

Belden

Belden Hirschmann RS20 Series Manual de usuario

Belden

Belden Hirschmann GREYHOUND GRS1042 Manual de usuario

Belden

Belden Hirschmann IT MAMMUTHUS MTS26 Series Manual de usuario

Belden

Belden lumberg automation 0960 IOL 3816-001 Manual de usuario

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTS2948X-6Q-A Manual de usuario

Belden

Belden Hirschmann GREYHOUND GRS1042 Manual de usuario

Belden

Belden Hirschmann HiOS-2S Manual de usuario

Belden

Belden Hirschmann MACH1040 Series Manual de usuario

Belden

Belden grass valley GV FABRIC Manual de usuario

Belden

Belden Hirschmann Rail Switch Power Lite Manual de usuario

Belden

Belden HIRSCHMANN Octopus II Manual de usuario

Belden

Belden Grass Valley K-Frame Cómo utilizar

Belden

Belden HIRSCHMANN GREYHOUND GRM Series Manual de usuario

Belden

Belden Hirschmann MACH4002 Series Manual de usuario

Belden

Belden HIRSCHMANN HiOS-2A Manual de usuario

Belden

Belden Hirschmann SPIDER-SL-20-08T1999999SY9HHHH Manual de usuario

Belden

Belden HIRSCHMANN SPIDER II 16TX EEC Manual de usuario

Belden

Belden MAMMUTHUS MTM2800-PSU120 Manual de usuario

Belden

Belden HIRSCHMANN MACH 4000 Series Manual de usuario

Belden

Belden HIRSCHMANN MACH4002-48+4G Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
