Belden HIRSCHMANN RSP20 Manual de usuario

Installation RSP20/25/30/35

Release

09/2021

Technical support

https://hirschmann-support.belden.com

User Manual

Installation

Industrial Ethernet Rail Switch Power

RSP20/25/30/35

22.09.2021 Installation RSP20/25/30/35

Release

09/2021

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation RSP20/25/30/35

Release

09/2021 3

Contents

Important information 5

Safety instructions 7

About this manual 21

Key 22

1 Description 23

1.1 General description 23

1.2 Device name and product code 24

1.3 Device views 27

1.3.1 Front view 27

1.3.2 Rear view 28

1.4 Power supply 29

1.4.1 Supply voltage with the characteristic value K9 29

1.4.2 Supply voltage with the characteristic value KK 29

1.4.3 Supply voltage with the characteristic value TT 29

1.4.4 Supply voltage with the characteristic value CC 29

1.5 Ethernet ports 30

1.5.1 10/100 Mbit/s twisted pair port 30

1.5.2 100/1000 Mbit/s twisted pair port (optional) 30

1.5.3 100 Mbit/s F/O port 31

1.5.4 100/1000 Mbit/s F/O port (optional) 31

1.6 Display elements 32

1.6.1 Device state 32

1.6.2 Port status 33

1.7 Management interfaces 34

1.7.1 V.24 interface (external management) 34

1.7.2 SD card interface 34

1.8 Signal contact 35

2 Installation 36

2.1 Checking the package contents 36

2.2 Installing the SD card (optional) 36

4Installation RSP20/25/30/35

Release

09/2021

2.3 Installing and grounding the device 37

2.3.1 Installing the device onto the DIN rail 37

2.3.2 Grounding the device 38

2.4 Installing an SFP transceiver (optional) 39

2.5 Connecting the terminal blocks 39

2.5.1 Supply voltage with the characteristic value K9 40

2.5.2 Supply voltage with the characteristic value KK 41

2.5.3 Supply voltage with the characteristic value CC 42

2.5.4 Supply voltage with the characteristic value TT 43

2.5.5 Signal contact 44

2.6 Operating the device 45

2.7 Connecting data cables 45

2.8 Filling out the inscription label 46

3 Making basic settings 47

4 Upgrading Software 49

5 Monitoring the ambient air temperature 50

6 Maintenance and service 51

7Disassembly 52

7.1 Removing the device 52

7.2 Removing an SFP transceiver (optional) 53

8 Technical data 54

8.1 General technical data 54

8.2 Dimension drawings 58

8.3 EMC and immunity 59

8.4 Network range 61

8.5 Power consumption/power output 65

8.6 Scope of delivery, order numbers and accessories 65

9 Underlying technical standards 68

A Further support 69

Installation RSP20/25/30/35

Release

09/2021 5

Important information

Note: Read these instructions carefully, and familiarize yourself with the

device before trying to install, operate, or maintain it. The following notes may

appear throughout this documentation or on the device. These notes warn of

potential hazards or call attention to information that clarifies or simplifies a

procedure.

Symbol explanation

This is a general warning symbol. This symbol alerts you to

potential personal injury hazards. Observe all safety notes that

follow this symbol to avoid possible injury or death.

If this symbol is displayed in addition to a safety instruction of the

type “Danger” or “Warning”, it means that there is a danger of

electric shock and failure to observe the instructions will

inevitably result in injury.

This symbol indicates the danger of hot surfaces on the device.

In connection with safety instructions, non-observance of the

instructions will inevitably result in injuries.

DANGER

DANGER draws attention to an immediately dangerous situation, which will

inevitably result in a serious or fatal accident if not observed.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

CAUTION indicates a possible danger which, if not avoided, may result in

minor injuries.

6Installation RSP20/25/30/35

Release

09/2021

NOTICE

NOTE provides information about procedures that do not involve the risk of

injury.

Installation RSP20/25/30/35

Release

09/2021 7

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Certified usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product only according to the technical specifications.

See “Technical data” on page 54.

Connect to the product only components suitable for the requirements

of the specific application case.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8Installation RSP20/25/30/35

Release

09/2021

Installation site requirements

If you connect the device to a power supply that does NOT meet the

requirements for Limited Power Source, NEC Class 2 or PS2

according to IEC/EN 62368-1 and is NOT limited to 100 W output

power, the device must be installed in either a switch cabinet or other

fire enclosure.

The fire enclosure can be made of metal or plastic with fire-protection

properties of at least V-1 according to IEC 60695-11-10. Bottom

openings of the fire enclosure must NOT exceed 2 mm in diameter.

Only for device variants featuring supply voltage with characteristic

value K9 or KK:

Install this device only in a switch cabinet or in an operating site with

restricted access, to which maintenance staff have exclusive access.

Strain relief

Note: If the strain relief is insufficient, there is a risk of torsion, contact

problems and creeping interruptions.

Relieve the connection points of cables and lines from mechanical

stress.

Design strain relieves in such a way that they prevent any mechanical

damage to cables, wires or conductors caused by external influences

or their own weight.

To prevent damage to device connections, connectors and cables,

follow the instructions for proper installation in accordance with DIN

VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.

Device casing

Only technicians authorized by the manufacturer are permitted to open

the casing.

Never insert pointed objects (narrow screwdrivers, wires, etc.) into the

device or into the connection terminals for electric conductors. Do not

touch the connection terminals.

Keep the ventilation slits free to ensure good air circulation.

Mount the device in the vertical position.

At ambient air temperatures > +140 °F (+60 °C):

The surfaces of the device housing may become hot. Avoid touching

the device while it is operating.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Installation RSP20/25/30/35

Release

09/2021 9

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Grounding the device

Grounding the device is by means of a separate ground connection on the

device.

Ground the device before connecting any other cables.

Disconnect the grounding only after disconnecting all other cables.

Ground the device via the ground screw.

Shielding ground

The overall shield of a connected shielded twisted pair cable is connected

to the grounding connector on the front panel as a conductor.

Beware of possible short circuits when connecting a cable section with

conductive shielding braiding.

Requirements for connecting electrical wires

Before connecting the electrical wires, always verify that the

requirements listed are complied with.

Requirements for connecting the signal contact

All of the following requirements are complied with:

The electrical wires are voltage-free.

The cables used are permitted for the temperature range of the application case.

Table 1: Requirements for connecting electrical wires

All of the following requirements are complied with:

The voltage connected complies with the requirements for a safety extra-low voltage

(SELV) as per IEC 60950-1 or ES1 as per IEC/EN 62368-1.

The connected voltage is limited by a current limitation device or a fuse.

Observe the electrical threshold values for the signal contact.

See “General technical data” on page 54.

Table 2: Requirements for connecting the signal contact

10 Installation RSP20/25/30/35

Release

09/2021

Requirements for connecting the supply voltage

Device variant Requirements

All variants All of the following requirements are complied with:

The supply voltage corresponds to the voltage specified on the type

plate of the device.

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device (for

example a switch or a plug). This disconnecting device is clearly

identified. So in the case of an emergency, it is clear which

disconnecting device belongs to which power supply cable.

The cross-section of the ground conductor is the same size as or

bigger than the cross-section of the power supply cables.

Relevant for North America:

The power supply cables are suitable for ambient air temperatures of

at least +167 °F (+75 °C). The wires of the power supply cables are

made of copper.

Only for device

variants featuring

supply voltage with

the characteristic

value CC:

If you connect 2 independent power sources, verify that the minus

terminal is grounded. Failure to follow this instruction can result in

equipment damage.

The wire diameter of the power supply cable is at least 0.75 mm² (North

America: AWG18) on the supply voltage input.

The following requirements are alternatively complied with:

Alternative 1 The power supply complies with the requirements

for a limited power source (LPS) according to IEC/

EN 60950-1 or PS2 according to IEC/EN 62368-1.

Alternative 2 Relevant for North America:

The power supply complies with the requirements

according to NEC Class 2.

Alternative 3 All of the following requirements are complied with:

The power supply complies with the

requirements for a safety extra-low voltage

(SELV) according to IEC 60950-1 or ES1

according to IEC/EN 62368-1.

A back-up fuse suitable for DC voltage is

located in the plus conductor of the power

supply.

The minus conductor is on ground potential.

Otherwise, a back-up fuse is also located in the

minus conductor.

Regarding the properties of this back-up fuse:

See “General technical data” on page 54.

Table 3: Requirements for connecting the supply voltage

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Belden

Belden

Belden Hirschmann SPIDER Standard Line Series Manual de usuario

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTS2948X-6Q-A Manual de usuario

Belden

Belden Hirschmann MACH104-PoEP Series Manual de usuario

Belden

Belden lumberg automation 0960 IOL 3816-001 Manual de usuario

Belden

Belden HIRSCHMANN MACH 100 Series Manual de usuario

Belden

Belden Hirschmann RS20 Series Manual de usuario

Belden

Belden Hirschmann MACH104 Series Guía del usuario

Belden

Belden Hirschmann SPIDER 8TX EEC Manual

Belden

Belden Hirschmann RED25 Series Manual de usuario

Belden

Belden Hirschmann MICE MS20 Manual de usuario

Belden

Belden Hirschmann IT MAMMUTHUS MTS26 Series Manual de usuario

Belden

Belden Hirschmann SPIDER II 8TX Manual de usuario

Belden

Belden Hirschmann SPIDER-SL-20-01T1S29999SZ9HHHH Manual de usuario

Belden

Belden Hirschmann MACH104-PoEP Series Manual de usuario

Belden

Belden HIRSCHMANN MSP30 Manual de usuario

Belden

Belden MAMMUTHUS MTM2800-PSU120 Manual de usuario

Belden

Belden HIRSCHMANN OCTOPUS OS24 Series Manual de usuario

Belden

Belden HIRSCHMANN PTN-CSM310-A Manual de usuario

Belden

Belden Hirschmann SPIDER-SL-20-08T1999999SY9HHHH Manual de usuario

Belden

Belden HIRSCHMANN RSPE 30 Manual de usuario

Belden

Belden HIRSCHMANN MACH 4000 Series Manual de usuario

Belden

Belden Telecast Fiber Systems THOR-SLG Manual de usuario

Belden

Belden HIRSCHMANN EESX Series Guía de configuración rápida

Belden

Belden Hirschmann MACH4002 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
