AWS PNX-203 Manual de usuario

PNX & KGX Series

Precision Balance

Models:

PNX-203

PNX-202

PNX-602

PNX-2002

PNX-1001

PNX-2001

PNX-6001

KGX-10

KGX-20

TARE

UNIT

CAL

TARE

UNIT

CAL

TARE

UNIT

CAL

TARE

UNIT

CAL

Parts and Setup .............................................................................................2

Getting Started..............................................................................................4

Basic Operation .............................................................................................7

Basic Weighing ......................................................................................................................... 7

Calibration / Adjustment...................................................................................................... 8

Application Modes ........................................................................................9

Counting Mode........................................................................................................................ 9

Percentage Mode ..................................................................................................................10

Basic Settings...............................................................................................11

Unit Settings............................................................................................................................11

Backlight Setting ...................................................................................................................12

Beep Setting............................................................................................................................12

Communication Settings ............................................................................13

Balance Setup ..............................................................................................15

Auto-Zero Tracking Range .................................................................................................15

Stability Range .......................................................................................................................15

Sensitivity.................................................................................................................................15

Filtering.....................................................................................................................................15

Factory Restore............................................................................................16

Print Data Format ..................................................................................................................16

Specications...............................................................................................18

Table of Contents

Parts & Setup

SAFETY

To avoid damage to the device or personal injury, please read all operating

instructions carefully before use.

IDon’t use the balance under dangerous working conditions.

IVerify that the required input voltage on the power adapter matches your

locally supplied AC power.

ITurn o and unplug the balance when cleaning or if the balance will not

be used for more than one week.

ITurn o and unplug the balance before connection with other

equipment.

IStrong magnetic elds and static electricity can have an adverse eect on

the balance’s accuracy. If you need to weigh magnetized or statically

charged samples, use the underweighing hook to suspend the sample

below the balance.

SERVICE

− Use only authorized parts and accessories. We are not responsible for any

modications made to the device.

− Breaking the tamper evident seal inside the scale base will void the

warranty.

− For warranty service, contact AWS at 1-866-643-3444. There is a One Year

Limited Warranty starting from the date of purchase.

1. UNPACKING

− After unpacking the balance, please check to make sure there is no visible

damage. Notify the delivery company of any damages in shipping as

soon as possible.

− Please keep the original box and packaging to store the balance when

not in use or to send in for service. If packaging the balance for transport,

please remove the platform and draft ring rst, then secure the draft

chamber doors with tape.

Parts & Setup

2. PACKING LIST

Model No. Scale

Base

Calibration

Mass

Adapter

USB

Cable

Weighing

Pan

Operating

Manual

PNX-203 1pc 1pc 1pc 1pc 1Set (2pcs) 1pc

PNX-202, PNX-

602, PNX-2002,

PNX-1001, PNX-

2001, PNX-6001

1pc 1pc 1pc 1pc 1pc 1pc

KG-10, KG-20 1pc 1pc 1pc 1pc 1pc

INSTALLATION

When selecting a location to use the balance, keep these tips in mind:

IDo not use the balance close to air vents or other sources of drafts such as

doors or windows.

IDo not expose the balance to extreme heat or cold. Keep the balance

away from direct sunlight which may cause it to heat up. Large

temperature uctuations may require recalibration of the balance.

IAvoid dust, dirt, and moisture which may accumulate on the weighing

sensors and cause a malfunction.

3. TEMPERATURE CHANGES

When moving the balance from a high temperature environment to a low

temperature environment (or vice versa), please allow the balance to

acclimatize to its new surroundings for two hours before using. Also, allow

sucient warm-up time after plugging in the balance. For warm-up times,

refer to the specications chart on page 9.

Getting Started

4. BALANCE ASSEMBLY

− Place the draft ring around the opening in

the center of the draft shield chamber.

− Place the platform on the central mounting

post.

5. LEVELING THE BALANCE

− The balance must be leveled whenever

changing locations. To adjust the level

condition, use the two adjustment feet at the

rear of the balance. Turn the adjustment feet

until the bubble on the spirit level is centered

within the bull’s-eye.

6. KEY EXPLANATION

Power Key

Turn the balance on or o.

Unit Key (Move Key)

Function 1: Change the current weighing unit.

Function 2: Move the cursor one digit to the left.

Menu Key

Function 1: Press to enter Counting Mode

Function 2: Press and hold for 5 seconds to enter the

system settings menu.

Function 3: Cycle through menu items. If there is only

one menu item, pressing will return to previous menu.

Function 4: Press and hold for 1 second to save and

exit system settings menu.

Getting Started

Cal Key (Enter / Zero Key)

Function 1: Press and hold for 5 seconds to enter

calibration. Press again to cancel calibration.

Function 2: Conrm menu setting.

Function 3: Remove any items from the weighing

platform then press to Zero the balance.

LNote: The balance has an automatic zero tracking (AZT) feature which

helps maintain a zero balance condition within the tolerances set in the

Zero Range Setting menu (Menu Code 4.1)

Print Key

Function 1: Send weighing data to the printer or other

device when the balance is congured to print on

demand (Menu Code 3.5 set to KEY).

Function 2: Increment the highlighted digit.

Function 3: Cycle through menu options.

Tare Key

Function 1: Tare the balance. Taring sets the weight of

an empty container to zero, so that the weight of the

contents (net weight) can then be measured.

Function 2: Exit the current menu without saving and

return to the previous menu.

Function 3: Press and hold for 1 second to exit the

current application mode (such as Density, Counting,

Animal Weighing Mode, etc).

LNote: Taring the balance subtracts the weight from the available

capacity. For example, on the PNX-203 (200g capacity), if you tare a 20g

container, you will have a remaining capacity of 180g.

Getting Started

Pieces

Menu Level / Date

Time

Weighing Result / Menu Item

Net Weight Indicator

Negative Indicator

Center of Zero Indicator

Tare Indicator

Stability Indicator

Unit Indicator

Temperature

Filtering Level

Sensitivity Level

Density Mode

Dynamic Weighing Mode

7. DISPLAY EXPLANATION

Basic Operation

8. BASIC WEIGHING FUNCTIONS

Preparation

− Turn the balance on: Press (ON/OFF) Key.

Warm up time:

ITo ensure proper operation, allow the balance to warm up according to

the warm-up times listed in the chart below:

Model Warm-up Time (minutes)

PNX 10-20

KGX 10-20

INSTANCE

Basic Weighing (after warming up)

Action Description Display Status

Press [CAL] 1. Zero the balance.

2. If using a container or tray, place it on the

platform.

( example : 20g )

Press [TARE] 3. Press the Tare key to zero the weight of

the container or tray.

4. Place the sample in the container.

( example : 100g )

Calibration / Adjustment

INote: Adjustment should only be performed under the following

conditions:

− Nothing on the platform

− Balance is properly zeroed and stable

Calibration

INSTANCE

Span Calibration (after warming up)

Action Description Display Status

1. Zero the balance.

Press and

Hold [ CAL ]

2. Press and hold the CAL key for 5 seconds

until the display shows “CAL” then release.

3. When the display ashes the calibration

value, place the required mass on the

platform. ( example : 200g )

4. When the value stops ashing, calibration is

complete. You may remove the calibration

mass.

Linear Calibration ( Advanced Users Only )

Action Description Display Status

1. Zero the balance.

Press and

Hold [ CAL ]

2. Press and hold the CAL key for 5 seconds

until the display shows “CAL”, then release.

Press and

Hold [ MENU ]

3. Press and hold the MENU key for 7

seconds until the display ashes“CAL”

again, then release.

4. When the display ashes the rst

calibration value, place the required mass

on the platform. (example : 200g)

5. When the value stops ashing, remove

the weight. The next calibration value

will be displayed. Place the mass on the

platform ( example : 170g )

6. Repeat Step 5 until the display shows

zero.
