Avalue Technology RPC-0801-910 Manual de usuario

Part No. E20177630A0R

RPC-0801-910

8” Multi-functional Touch Panel PC

Quick Reference Guide

1st Ed – 19 March 2010

RPC-0801-910

2 RPC-0801-910 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Quick Reference Guide

RPC-0801-910 Quick Reference Guide 3

Contents

1. Getting Started............................................................................................................4

1.1 Safety Precautions ................................................................................................4

1.2 Packing List...........................................................................................................4

1.3 System Specifications ...........................................................................................5

1.4 System Overview...................................................................................................7

1.4.1 Rear View..................................................................................................................................... 7

1.4.2 Right View.................................................................................................................................... 7

1.5 System Dimensions...............................................................................................8

1.5.1 RPC-0801-910............................................................................................................................. 8

2. Hardware Configuration.............................................................................................9

2.1 Jumper and Connector Setting, Driver and BIOS Installing...................................9

2.2 Installing SD card ................................................................................................10

2.3 Mode setting for RSC-W910 (only for boot loader update)..................................11

RPC-0801-910

4 RPC-0801-910 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

z1 x RPC-0801 Series Panel PC

z1 x Quick Reference Guide

z1 x CD/ DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—WinCE5.0/6.0 BSP,SDK and utilities

—Linux BSP and utilities

z1 x Power Adapter

z4 x screws for VESA

Quick Reference Guide

RPC-0801-910 Quick Reference Guide 5

1.3 System Specifications

Panel

Specifications RPC-0801-910

LCD size 8"

Display type SVGA TFT

Resolution 800 x 600

Color 262K

Pixel pitch 0.2025mm(H) x 0.2025mm(V)

Luminance 250 cd/m²

Contrast ratio 500

Viewing angle 60(U), 70(D), 70(L), 70(R)

Response time 50 ms

Backlight LED

Touch Type 4-wire Resistive

Touch Light Transmission 80%

Touch Interface I2C onboard touch interface

System

Board RSC-W910

CPU Onboard Nuvoton NUC910ABN 200 MHz

Boot loader NAND/NOR Flash

Memory Onboard 64MB SDRAM, Optional 128MB

Flash Onboard 128MB, Optional 512MB

Watchdog Timer Interrupt 0.28/1.12/4.47/17.9sec.

System Memory Onboard 64MB SDRAM, Optional 128MB

SSD SD or SDHC

RPC-0801-910

6 RPC-0801-910 Quick Reference Guide

Rear Panel I/O

Serial Port 1 x RS-232, 1x UART for debug message

Ethernet Onchip MAC + PHY, 1x 10/100 Base-Tx Fast Ethernet Compatible

USB 2 x USB 2.0

Mini USB 1 x USB client

Mechanical & Environmental

Color Front Silver and Back Black

Power Requirement +12V DC Input

Operating Temperature 0°C to 60°C.

Relative Humidity 0% to 90% relative humidity, non-condensing

Mounting Wall/Stand/VESA 75 mm X 75 mm

Dimensions 202 mm X 159 mm X 42.5 mm

Weight 1.07 Kgs

Quick Reference Guide

RPC-0801-910 Quick Reference Guide 7

1.4 System Overview

1.4.1 Rear View

1.4.2 Right View

Connectors

Label Function Note

COM0 Serial port 0 Debug message output

COM1 Serial port 1 DB-9 male connector

DC-in +12V DC-in power connector

LAN Ethernet connector RJ-45

Power Power switch

Mini USB USB client connector Mini USB connector

USB 2 x USB 2.0 connector Dual USB decks

RPC-0801-910

8 RPC-0801-910 Quick Reference Guide

1.5 System Dimensions

1.5.1 RPC-0801-910

Quick Reference Guide

RPC-0801-910 Quick Reference Guide 9

2.Hardware

Configuration

2.1 Jumper and Connector Setting, Driver and BIOS

Installing

zPlease refer to RSC-W910 Quick Installation Guide for further

information.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

RPC-0801-910

10 RPC-0801-910 Quick Reference Guide

2.2 Installing SD card

Step 1. Unfasten 6 screws to remove the bottom chassis.

Step 2. Install the SD card into the slot.

Step 3. Assemble the board and bottom chassis back as step 1.
