Avalue Technology SPC-22W7 Manual de usuario

Part No. E2017S270A0R

SPC-22W7

Full IP-65 Stainless Steel Chassis

Fanless Touch Panel PC

Quick Reference Guide

1st Ed –08 July 2014

SPC-22W7

2 SPC-22W7 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

SPC-22W7 Quick Reference Guide

Contents

1. Getting Started ........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................7

1.4.1 Rear View................................................................................................................................ 7

1.5 System Dimensions ..................................................................................................8

1.5.1 Front, rear and side view......................................................................................................... 8

SPC-22W7

4 SPC-22W7 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x SPC-22W7 Panel PC

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—Wi-Fi drivers and utilities

—Touch controller drivers and utilities

1 x Power Adapter

1 x DC-in extended cable

Quick Reference Guide

SPC-22W7 Quick Reference Guide

1.3 System Specifications

Panel

LCD Size

22”W, 16:10

Resolution

1680 x 1050, WSXGA

Pixel Pitch

0.282mm (H) x 0.282mm (V)

Luminance

250cd/m²

Contrast Ratio

1000

Viewing Angle

80 (U), 80 (D), 85 (L), 85 (R)

Response Time

5ms

Backlight

LED

Touch Screen

5-wire Resistive

Light Transmission

80%

Touch Interface

USB Touch Control Board EETI

System

Board

EBM-CDV

CPU

Onboard Intel® Atom™ D2550 1.86GHz CPU

System Chipset

Intel® NM10 Chipset

I/O Chip

E/C IT8518E

System Memory

One SODIMM socket supports up to 4GB DDR3 800/1066 SDRAM

Storage

One Type I/II Compact Flash Socket

One 2.5” HDD Bay

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor

Monitoring System Temperature, Voltage, and

Cooling Fan Status. with Auto Throttling Control

Expansion

1 x Mini PCIe Slot, Optional Supports mSATA

Rear I/O

Serial Port

1 x RS-232 (Water Proof, IP-67 Rating)

Ethernet

1 x RJ-45 (Water Proof, IP-67 Rating)

(Intel® 82574L Gigabit Ethernet, Optional Dual 82574L Gigabit

Ethernet)

USB

3 x USB 2.0 (Water Proof, IP-67 Rating)

Power Switch

1 x Membrane Power Button

Power Input

1 x DC-in (Water Proof, IP-67 Rating)

Speaker

2 x 2W Speaker

Environment & Mechanical

Color

Front & Rear Panel Silver

Mounting

VESA/ Wall/ Stand 75mm x 75mm & 100mm x 100mm

SPC-22W7

6 SPC-22W7 Quick Reference Guide

System Power

Requirement

+12 ~ 26V DC Power Input

Power Adapter

Input: 100 ~ 250VAC/ 47 ~ 63Hz

Output: 90W Adapter (19V @ 4.74A Adapter)

Operating Temperature

0 ~ 40°C (32 ~ 104°F )

Storage Temperature

-20 ~ 60°C (-4 ~ 140°F)

Relative Humidity

5% ~ 90% Relative Humidity, Non-condensing

Dimensions (W x D x H)

546mm x 378mm x 69mm

Weight

9 Kgs

Quick Reference Guide

SPC-22W7 Quick Reference Guide

1.4 System Overview

1.4.1 Rear View

Connectors

Label

Function

Note

Membrane

Power & 3 programmable buttons

USB

Waterproof USB 2.0 connector x 3

LAN

Waterproof RJ-45 connector

COM

Waterproof DB-9 connector

DC-IN

Waterproof DC Power-in connector

SPC-22W7

8 SPC-22W7 Quick Reference Guide

1.5 System Dimensions

1.5.1 Front, rear and side view

(Unit: mm)
