Avalue Technology SID-15WR1 Manual de usuario

Part No. E2017S5R1A1R

SID-15WR1

15.6" Panel PC with Rockchip RK3288 SoC, 2G RAM, 16G

eMMC

Quick Reference Guide

2nd Ed –27 September 2021

SID-15WR1

2 SID-15WR1 Quick Reference Guide

FCC Statement

Federal Communication Commission Interference Statement

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE

FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT

MAY CAUSE UNDESIRED OPERATION.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction, may cause

harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Notice:

(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent

interference to the nearby radio and television reception. It is essential that only the supplied

power cord by used.

(2) Use only shielded cables to connect I/O devices to this equipment.

(3) Changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

Quick Reference Guide

SID-15WR1 Quick Reference Guide

FCC RF Radiation Exposure Statement

This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant

to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF

Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far

below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a

manner that the potential for human contact during normal operation is minimized. When nearby

persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits

established in the ANSI C95.1 standards, the distance between the antennas and the user should not

be less than 20 cm.

WARNING

“CAUTION –Use suitable mounting apparatus to avoid risk of injury.”

“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been

approved and complies with the safety standard of your particular country.”

“WARNING –To avoid risk of electric shock, this equipment must only be connected to a supply

mains with protective earth.”

Notice

This guide is designed for experienced users to setup the system within the shortest time.

For detailed information, please always refer to the electronic user's manual.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective

owners.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

SID-15WR1

4 SID-15WR1 Quick Reference Guide

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

Life Support Policy

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN

LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL

OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform,

when properly used in accordance with instructions for use provided in the labeling, can

be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose

failure to perform can be reasonably expected to cause the failure of the life

support device or system, or to affect its safety or effectiveness.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

SID-15WR1 Quick Reference Guide

Content

1. Getting Started............................................................................................................6

1.1 Safety Precautions ................................................................................................6

1.2 Packing List...........................................................................................................6

1.3 System Specifications ...........................................................................................8

1.4 System Overview.................................................................................................11

1.4.1 I/O View...................................................................................................................................... 11

1.5 System Dimensions.............................................................................................12

2. Hardware Configuration...........................................................................................13

2.1 SID-15WR1 connector mapping..........................................................................14

2.1.1 Serial port connector (COM)...................................................................................................... 14

2.1.2 RJ-45 Ethernet connector (LAN) ............................................................................................... 14

2.1.3 HDMI connector (HDMI) ............................................................................................................ 15

2.1.4 USB2.0 connector (USB2.0)...................................................................................................... 15

SID-15WR1

6 SID-15WR1 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x SID-15WR1 Panel PC

1 x Power adapter

1 x Power cord

1 x Screw

1 x Antenna

Quick Reference Guide

SID-15WR1 Quick Reference Guide

Definitions

Warning! Class I Equipment. This equipment must be earthed. The power plug must be

connected to a properly wired earth ground socket outlet. An improperly wired socket

outlet could place hazardous voltages on accessible metal parts.

Caution! Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used

Batteries According to the Instructions."

Warning! For RTC battery, current statement in the manual is acceptable.

There is danger of explosion if the battery is mishandled or incorretly replaced.

Replace only with the same type of battery. Do not disassemble it or attempt to

recharge it outside the system. Do not crush, puncture, dispose of in fire, short the

external contacts, or expose to water or ther liquids. Dispose of the battery in accordance with local

regulations and instructions from your service provider.

SID-15WR1

8 SID-15WR1 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

ACP-RK3288B

CPU

RockChip RK3288-W Cortex-A17, Quad Core 1.8GHz

CPU Cooler (Type)

Aluminum type w/ Shielding cover

Memory

2GB DDR3L on board

Power Supply

DC-in 12V~24V wide voltage DC input support

Adapter

AC/DC adapter 12V/5A, screw type

Wireless LAN

802.11 b/g/n Wireless LAN on board

Bluetooth

Bluetooth 4.0 on board

Operating System

Android 8.1

Storage

Solid State Drive

16GB eMMC on board

Panel

LCD Panel

- BOE NV156FHM-N42 15.6” TFT-LCD

- 16:9 wide screen, 1920 x 1080

- eDP Interface

Touch Screen

ACDC DY1562W-4262

- Projective Capacitive, Multi touch, 10 points

- Hardness: ≥6H

- Transmission: ≥85%

- USB Interface

Touch Controller

Silicon Works-SW4101D

External I/O

Serial Port

1 x DB9 for RS-232(Tx/Rx, Default)

USB Port

2 x USB 2.0 ports (Type A), Option 3th USB 2.0 port

Video Port

1 x HDMI 2.0 port (Type A)

Audio Port

1 x Line out jack (Audio/Green)

LAN Port

1 x Gigabit Ethernet (RJ-45 connector)

Wireless LAN

Antenna

1 x Dipole Antenna

Switch

1x Power button w/ LED

Others

1 x Reset button

Power Requirement/Mechanical

Power Type

12V~24V wide voltage DC input

Power Connector

Type

2.5mm DC-in jack

Quick Reference Guide

SID-15WR1 Quick Reference Guide

Construction

Metal

Color

Black

Dimension

391.2 x 239.2 x 48.1mm

Weight

3.59 kg

Fanless

Yes

IP Rating

Front IP65

Reliability

EMI Test

CE/FCC Part 15, Subpart B

Safety

IEC-60950-1 & EN 60950-1

Dust and Rain Test

Front Panel IP65

Random Vibration

Test

Test Standard: Reference IEC60068-2-64 Testing procedures

1. System condition: Operation mode

2. PSD: 0.00454G²/Hz , 1.5 Grms

3. Test Frequency : 5-500Hz

4. Test Axis : X,Y and Z axis

5. Test time: 30 minutes per each axis

6. Storage : eMMC

Sine Vibration Test

(Non-operation)

Test Standard: Reference IEC60068-2-6 Testing procedures

1. System condition : Non-Operating mode

2. Test Acceleration : 2G

3. Test frequency : 5~500 Hz

4. Sweep：1 Oct/ per one minute. (logarithmic)

5. Test Axis : X,Y and Z axis

6. Test time :30 min. each axis

Packing Vibration

Test

Test Standard: Reference IEC60068-2-64 Testing procedures

1. Non-operation mode

2. PSD: 0.026G²/Hz , 2.16 Grms

3. Test Frequency : 5-500Hz

4. Test Axis : X,Y and Z axis

5. Test time: 30 min. per each axis

Mechanical Shock

Test

Test Standard: Reference IEC60068-2-29 Testing procedures

1. System Condition: Operation

2. Wave form: Half-Sine wave

3. Acceleration: Rate: 10g

4. Duration: Time: 11ms

5. No. of Shock: Z axis 300 times

6. Test Axis: Z axis

Packing Drop Test

Reference ISTA 2A, Method: IEC-60068-2-32 Test:Ed

1. Test Phase: One comer, three edges, six faces

2. Packing weight: around 1.5kg

SID-15WR1

10 SID-15WR1 Quick Reference Guide

3. Test high: 96.5cm (Based on product weight

Operating

Temperature

0°C ~ 40°C (32°F ~ 104°F)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Note: Specifications are subject to change without notice.

Tabla de contenidos

Otros manuales de Panel táctil de Avalue Technology

Avalue Technology

Avalue Technology CPC-2102 Manual de usuario

Avalue Technology

Avalue Technology APC-18W5 Manual de usuario

Avalue Technology

Avalue Technology ARC-1533 Manual de usuario

Avalue Technology

Avalue Technology FPC 15 Series Manual de usuario

Avalue Technology

Avalue Technology ARC-1538 Manual de usuario

Avalue Technology

Avalue Technology RITY122 Manual de usuario

Avalue Technology

Avalue Technology BFC-1509 Manual de usuario

Avalue Technology

Avalue Technology ARC-1738-C1 Manual de usuario

Avalue Technology

Avalue Technology SPC-1209 Manual de usuario

Avalue Technology

Avalue Technology LPC-1231 Manual de usuario

Avalue Technology

Avalue Technology BFC-15W9 Manual de usuario

Avalue Technology

Avalue Technology SPC-1533-B1 Manual de usuario

Avalue Technology

Avalue Technology CCD-07WR2 Manual de usuario

Avalue Technology

Avalue Technology ARC-1532-C2 Manual de usuario

Avalue Technology

Avalue Technology MPC-21W7 Manual de usuario

Avalue Technology

Avalue Technology ARC-1538-B Manual de usuario

Avalue Technology

Avalue Technology SPC-1207 Series Manual de usuario

Avalue Technology

Avalue Technology LPC-0809 Manual de usuario

Avalue Technology

Avalue Technology AID-156ST2 Manual de usuario

Avalue Technology

Avalue Technology AID-173SBT Manual de usuario

Avalue Technology

Avalue Technology LPC-0807 Manual de usuario

Avalue Technology

Avalue Technology APC-2132 Manual de usuario

Avalue Technology

Avalue Technology ARC-21W33 Manual de usuario

Avalue Technology

Avalue Technology AID-173S Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
