Avalue Technology AID-173S Manual de usuario

By Jason Lin Part No: E2017173SA1R

Avalue Intelligent Display & System

AID-173S

All-In-One Bedside Terminal

Quick Reference Guide

1st Ed- 15 October 2010

AID-173S Quick Reference Guide

Federal Communication Commission Interference Statement

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT

TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from the one the receiver is

connected to.

Consult the dealer or an experienced radio/TV technician for help.

Notice:

(1) A Unshielded-type power cord is required in order to meet FCC emission limits and

also to prevent interference to the nearby radio and television reception. It is

essential that only the supplied power cord by used.

(2) Use only shielded cables to connect I/O devices to this equipment.

(3) Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

AID-173S Quick Reference Guide

FCC RF Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for

an uncontrolled environment. This equipment should be installed and

operated with minimum distance 20cm between the radiator & your body.

For product available in the USA/Canada market, only channel 1~11 can

be operated. Selection of other channels is not possible. The antenna(s)

used for this transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter. Shielded interface

cables must be used in order to comply with emission limits.

AID-173S Quick Reference Guide

CONTENT

1. AID-173S Bedside Terminal Features .............................................................5

1.1 Front view..........................................................................................6

1.2 Rear & Bottom view..........................................................................7

1.3 Handset..............................................................................................8

2. Setting Up AID-173S Bedside Terminals........................................................9

2.1 Mounting..........................................................................................10

2.2 Cabling.............................................................................................11

Please follow below steps to connect power cable to system. ........11

2.3 System Activation & Registration .................................................12

2.4 Connecting to the Internet.............................................................13

3. Using AID-173S Bedside Terminals...............................................................14

3.1. Turn ON/OFF the System ..............................................................15

3.1.1 Turn ON the System .....................................................................15

3.1.2 Turn OFF the System ...................................................................15

3.2 Using LCD Display and Touch Screen..........................................16

3.2.1 Adjust System Volume.................................................................16

3.2.2 Adjust LCD Display Brightness.................................................16

3.2.3 Using Touch Screen.....................Error! Bookmark not defined.

3.3Using Earphone and Microphone ..................................................16

3.4 Using the Smart Card Reader........................................................18

3.5 Using Magnetic Stripe Reader.......................................................19

3.6 Using RFID Reader/Writer..............................................................20

3.7 Using Handset.................................................................................21

3.8 Using Barcode Scanner .................................................................23

4. Upgrading AID-173S Bedside Terminals..................................................24

4.1 Adding/Removing/Replacing Memory ..........................................25

4.2 Adding/Removing/Replacing TV Tuner.........................................26

4.3 Removing and Replacing the Wireless Card................................27

4.4 Adding 3rd Party Mini-PCIe Cards ................................................28

4.5 Removing and Replacing the Hard Disk Drive.............................29

AID-173S Quick Reference Guide

1. AID-173S Bedside Terminal Features

▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬

In this chapter, you will get to know all features of our AID-173S

bedside terminal.

1.1 Front view

1.2 Rear & Bottom view

1.3 Handset

AID-173S Quick Reference Guide

1.1 Front view

Camera

Handset

Magnetic Stripe Reader

Smart Card Reader

RFID Reader/Writer

17.3”TFT-LCD & Touch Screen

Cord

3 x USB

Volume

Up/down

Brightness

Up/down

Reserved

Power on/off

AID-173S Quick Reference Guide

1.2 Rear & Bottom view

Microphone

Service Door

COM1

Speaker

DVI-I Output (Optional, 1024*768)

HDMI Output (optional)

TV Antenna Input (optional)

USB Port

DC in

LAN

COM2

Nursing Call Input

BNC Video Input (Optional)

Service Door

AID-173S Quick Reference Guide

1.3 Handset

Key

Descriptions

Activate the phone software (i.e. Skype)

Nurse Call

Answer

Hang Up

Contact List (Up)

Contact List (Down)

Numeric Keys

* Key

# Key

Barcode Scanner

Scan button

Volume

Scan button

AID-173S Quick Reference Guide

2. Setting Up AID-173S Bedside Terminals

▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬

This chapter gives instructions on how to set up AID-173S bedside

terminal hardware and how to connect different cables.

Furthermore, with provided Internet ISP setting information, you will

be able to connect AID-173S bedside terminal to the Internet.

2.1 Mounting

2.2 Cabling

2.3 System Activation & Registration

2.4 Connecting to the Internet

AID-173S Quick Reference Guide

2.1 Mounting

Suggested Screw type for mounting

Note: 4 pieces of M6x10 screws

VESA 75 Mounting
