Avalue Technology PPC-1529 Manual de usuario

Part No. E2017P190A2R

PPC-1529/1729/2129

15"/17"/21.5" Intel® Celeron® SoC Processor J1900 Fanless

Plastic Chassis Touch Panel PC

Quick Reference Guide

2nd Ed –29 March, 2016

PPC-1529/1729/2129

2 PPC-1529/1729/2129 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

Notice

This guide is designed for experienced users to setup the system within the shortest time.

For detailed information, please always refer to the electronic user's manual.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective

owners.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide

PPC-1529/1729/2129 Quick Reference Guide

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

Life Support Policy

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN

LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL

OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform,

when properly used in accordance with instructions for use provided in the labeling, can

be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose

failure to perform can be reasonably expected to cause the failure of the life

support device or system, or to affect its safety or effectiveness.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

PPC-1529/1729/2129

4 PPC-1529/1729/2129 Quick Reference Guide

Content

1. Getting Started............................................................................................................5

1.1 Safety Precautions ................................................................................................5

1.2 Packing List...........................................................................................................5

1.3 System Specifications ...........................................................................................6

1.4 System Overview.................................................................................................10

1.4.1 PPC-1529 Rear View.................................................................................................10

1.4.2 PPC-1729 Rear View.................................................................................................10

1.4.3 PPC-2129 Rear View.................................................................................................10

1.5 System Dimensions.............................................................................................12

1.5.1 PPC-1529..................................................................................................................12

1.5.2 PPC-1729..................................................................................................................13

1.5.3 PPC-2129..................................................................................................................14

2. Hardware Configuration...........................................................................................15

2.1 PPC-1529/1729/2129 connector setting..............................................................16

2.1.1 Serial port 1 connector (COM1).................................................................................16

2.2 Installing Hard Disk & Memory ............................................................................17

Quick Reference Guide

PPC-1529/1729/2129 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x PPC-1529/1729/2129 Panel PC

1 x CD/DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

1 x packing set includes the followings

—1 x power cord

—1 x AC/DC adapter 12V/5A 60W (PPC-1529/1729);

12V/7A 84W (PPC-2129)

PPC-1529/1729/2129

6 PPC-1529/1729/2129 Quick Reference Guide

1.3 System Specifications

Component

Model

PPC-1529

PPC-1729

Mother Board

EBM-BYT

CPU

Onboard Intel® Celeron® J1900 2.0 GHz CPU

CPU Cooler (Type)

Fanless Heatsink

Fanless Heat Pipe

Memory

One 204-pin SODIMM Supports Up to 4GB DDR3 1066MHz SDRAM (Default

2GB)

Audio Codec

RealTek ALC892-GR

Power Supply

External power adapter

Adapter

12V/5A 60W Adapter

Speaker

8Ω 2W*2

Camera

Optional 2.0M CMOS WCAM w/ Mic-in

Wireless LAN

Optional WiFi module

Operating System

Windows 7

Windows Embedded Standard 7

Windows Embedded POSReady 7

Windows 7 For Embedded System

Windows 8.1 Pro

Windows 7

Windows Embedded Standard 7

Windows Embedded POSReady 7

Windows 7 For Embedded System

Windows 8.1 Pro

Storage

Hard Disk Drive

2.5” HDD

Solid State Drive

2.5” SSD (Default 32GB SSD)

Other Storage Device

Type I/II CF

Panel

LCD Panel

15" XGA TFT LCD 1024*768

17" SXGA TFT LCD AUO 1280*1024

LCD Control Board

Built-in

B/L Inverter/Converter

Built-in

Touch Screen

15” 5-wire Resistive touch

17” 5-wire Resistive touch

Touch Controller

EETI ETP-CP-S458XRU

EETI ETP-CP-MER4485XRU

V1.015.A

External I/O

PS/2 KB & Mouse

Serial Port

1 x COM D-sub 9 Pin

USB Port

4 x USB

HDMI Port

1 x HDMI

Audio Port

1 x Line out (RealTek ALC892-GR)

LAN Port

2 x RJ-45

Quick Reference Guide

PPC-1529/1729/2129 Quick Reference Guide

Wireless LAN Antenna

Optional PCB Antenna 2.4/5.0GHz

Switch

1 x Power Button

Expansion Slots

1 x MiniPCIe Slot

1 x Mini PCIe Supports SIM Card

1 x Mini PCIe Supports mSATA

Mechanical

Power Type

AT/ATX

Power Connector

Type

Lockable DC Plug

Dimension

351mm x 319mm x 54mm

391.5mm x 364.5mm x 59mm

Weight

4.9 Kgs

5.9 Kgs

Color

White + Gray

Fanless

Reliability

EMI Test

Class B

Safety

CE FCC

Operating

Temperature

0°C ~ 40°C

Operating Humidity

10% to 95% @ 40°C, Non-condensing

Storage Temperature

-10~50°C

PPC-1529/1729/2129

8 PPC-1529/1729/2129 Quick Reference Guide

Component

Model

PPC-2129

Mother Board

EBM-BYT

CPU

Onboard Intel® Celeron® J1900 2.0 GHz CPU

CPU Cooler (Type)

Fanless Heat Pipe

Memory

One 204-pin SODIMM Supports Up to 4GB DDR3 1066MHz SDRAM (Default

2GB)

Audio Codec

RealTek ALC892-GR

Power Supply

External power adapter

Adapter

12V/7A 84W

Speaker

8Ω 2W*2

Camera

Optional 2.0M CMOS WCAM w/ Mic-in

Wireless LAN

Optional WiFi module

Operating System

Windows 7

Windows Embedded Standard 7

Windows Embedded POSReady 7

Windows 7 For Embedded System

Windows 8.1

Storage

Hard Disk Drive

2.5” HDD

Solid State Drive

2.5” SSD (Default 32GB SSD)

Other Storage Device

Type I/II CF

Panel

LCD Panel

21.5" FHD TFT LCD 1920*1080

B/L Inverter/Converter

LED Driving board

Touch Screen

21.5” 5-wire Resistive touch

Touch Controller

EETI ETP-CP-S458XRU

External I/O

Serial Port

1 x COM D-sub 9 Pin

USB Port

4 x USB

HDMI Port

1 x HDMI

Audio Port

1 x Line out

LAN Port

2 x RJ-45

Intel WGI211AT

Wireless LAN Antenna

Optional PCB Antenna 2.4/5.0GHz

Expansion Slots

2 x MiniPCIe Slot

Mechanical

Power Type

AT/ATX

Quick Reference Guide

PPC-1529/1729/2129 Quick Reference Guide

Power Connector

Type

Lockable DC Plug

Dimension

542mm x 382mm x 63mm

Weight

8.5 Kgs

Color

White + Gray

Fanless

Reliability

EMI Test

Class B

Safety

CE FCC

Operating

Temperature

0°C ~ 40°C

Operating Humidity

10% to 95% @ 40°C, Non-condensing

Storage Temperature

-10~50°C

Note: Specifications are subject to change without notice.

PPC-1529/1729/2129

10 PPC-1529/1729/2129 Quick Reference Guide

1.4 System Overview

1.4.1 PPC-1529 Rear View

1.4.2 PPC-1729 Rear View

1.4.3 PPC-2129 Rear View

Connectors

Label

Function

Note

COM1

Serial port 1 connector

DB-9 male connector

Compact

Flash/COM2

CF Type I/II Socket with Ejector

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Avalue Technology

Avalue Technology

Avalue Technology SID-10W9 Manual de usuario

Avalue Technology

Avalue Technology AID-173S Manual de usuario

Avalue Technology

Avalue Technology FPC-1707 Manual de usuario

Avalue Technology

Avalue Technology SPC-1533-B1 Manual de usuario

Avalue Technology

Avalue Technology SID-21W04 Manual de usuario

Avalue Technology

Avalue Technology LPC-1009 Series Manual de usuario

Avalue Technology

Avalue Technology MPC-42W7 Manual de usuario

Avalue Technology

Avalue Technology SPC-1507 Manual de usuario

Avalue Technology

Avalue Technology WG-1201 Manual de usuario

Avalue Technology

Avalue Technology BFC-1508 Manual de usuario

Avalue Technology

Avalue Technology C Series Manual de usuario

Avalue Technology

Avalue Technology SPC-1509 Manual de usuario

Avalue Technology

Avalue Technology MPC-OPC12 Manual de usuario

Avalue Technology

Avalue Technology FPC 15 Series Manual de usuario

Avalue Technology

Avalue Technology SID-10WR2 Manual de usuario

Avalue Technology

Avalue Technology APC-2132 Manual de usuario

Avalue Technology

Avalue Technology BFC-1509 Manual de usuario

Avalue Technology

Avalue Technology OFP-21W38 Manual de usuario

Avalue Technology

Avalue Technology AID-156ST2 Manual de usuario

Avalue Technology

Avalue Technology FPC-1736 Manual de usuario

Avalue Technology

Avalue Technology APC-2138-B1 Manual de usuario

Avalue Technology

Avalue Technology FPC 17 W Series Manual de usuario

Avalue Technology

Avalue Technology FPC 17" SERIES Manual de usuario

Avalue Technology

Avalue Technology SPC-1207 Series Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
