Antari X-510PRO Manual de usuario

X-510PRO , X-515PRO FOG MACHINE

USER MANUAL

English Français Deutsch• • •

2011 Antari Lighting and Effects Ltd.

Congratulations on the purchase of your new

ANTARI X-PRO SERIES Fogger

Introduction

Thank you for choosing an ANTARI Fogger of the X-PRO SERIES. There are two models available:

the X-510PRO (1000W) and the X-515PRO (1500W). Both units are rugged and powerful

state-of-the-art machines. Besides their ability to operate silently, these new models are user-friendly

in terms of controlling and operating. For Antari X-515PRO fog machine, an optional W-DMX function

(W-DMX) is available. Prior to use, we suggest that you carefully read all of the instructions. By

following the suggestions found in this user manual, you can look forward to the reliable and

satisfactory performance of your ANTARI Fog Machine for years to come.

Important Safeguards

-Danger of Electric Shock

* Keep this device dry.

* For inside use only. Not designed for outside use.

* For all models, use 3-prong grounded electrical outlet only. Prior to use take care to

determine that the unit is installed at the rated voltage.

* Always unplug your ANTARI Fog Machine before filling its tank.

* This machine is not water- or splash-proof. If moisture, water, or fog liquid gets inside the housing,

immediately unplug the unit and wipe off the moisture and keep it dry.

Danger of Burns

* Structural modification inside the machine is not allowed at anytime. Please do not attempt to

modify the machine by removing the cover, otherwise burns may result.

* For adult use only. Never leave the unit running unattended.

Cautions

Risk of electric shock. Disconnect the appliance from the electric

supply before removing the cover.

Note: There are no user serviceable parts inside.

* Never aim the output nozzle directly at people.

* Machine will warm up when operating, locate the fog machine in a well-ventilated area. Never

cover the unit's vents. In order to guarantee adequate ventilation, allow a free air space of at

least 30 cm around the sides and top of the unit.

* Never aim the output nozzle at open flames.

* The output nozzle becomes very hot during operation (200°C). Keep flammable materials at

least 50 cm away from the nozzle.

* Always allow your ANTARI X-PRO SERIES Fogger to cool down before attempting to clean or

service it.

Danger of Explosion

* Never add flammable liquids of any kind (oil, gas, perfume) to the fog liquid.

* Use only the high-quality, water-based ANTARI recommended FLG / FLR fog liquid. Other fog

liquids may cause clogging or damage to internal parts.

* Always make sure there is sufficient liquid in the fog liquid tank. Operating this unit without liquid

will cause overheating.

* If your ANTARI fog machine fails to work properly, discontinue use immediately. Drain all fog

liquid from the tank, pack the unit securely (preferably in the original packing material), and return

it to your ANTARI dealer for service.

* Always drain tank before mailing or transporting this unit.

* Never drink fog liquid. If it is ingested, call a doctor immediately. If fog liquid comes in contact with

skin or eyes, rinse thoroughly with water.

- Unpacking & Inspection

Open the shipping carton and verify that all equipment necessary to operate the system has arrived

intact.

The shipping carton should include the following items:

1. One unit with power cable of the X-PRO SERIES series: X-510PRO or X-515PRO

2. X-10PRO Control Module with cables

3. Fluid tank

4. User manual

Important:

Pay attention to all warning labels and instructions printed on the exterior of

your ANTARI X-PRO SERIES Fogger.

Optional Accessories:

1. Hanging bracket

2. Drip tray

3. X-30PRO Wireless Control Module

4. FX-510, FX-515 Flightcase

Before beginning with the initial setup of your X-PRO SERIES Fogger, make sure that there is no

evident damage caused by transportation. In the event that the unit's housing or cable is damaged,

do not plug it in and do not attempt to use it after having contacted your Antari dealer for assistance.

Setup

1. Remove all packing materials from shipping box. Check that all foam and plastic padding is

removed, especially in the nozzle area.

2. Place fog machine on a flat surface and remove fog liquid tank cap.

3. Fill unit about 3/4 full. Use Antari Fog Fluid only. Antari X-510PRO and X-515PRO Foggers only

work with uncontaminated Antari FLG/FLR Fog Fluid. Other fluids may cause possible clogging

problems and could result in the production of unhealthful fog. The use of other fluids will void the

warranty of the Antari X-510PRO and X-515PRO. When filled, place cap back on liquid tank.

Operation

* The plug is at a position that is accessible when the machine is in use.

Plug power cord into a grounded electrical outlet. Turn power switch on the rear of unit to “ON”

position. Warm-up is completed when the display on control module shows “Ready to Fog”.

* To emit fog, press the appropriate button on the X-10PRO Control Module for the desired length

of time.

* The Control Module’s display will cycle “Warming up” and “Ready to Fog” while the machine

re-heats to the proper operating temperature.

* When the fluid is running low, the LED inside the tank chamber starts blinking until the tank is

refilled again.

* Always monitor liquid level to prevent interrupted operation.

Caution: “Visibility during operation is reduced”.

WARNING

Use of any fluid other than ANTARI fog fluid or modification or attempt to unauthorized

repair of the X-Seies PRO Fogger will immediately invalidate the warranty.

Hanging Bracket

The unit may be installed at floor level or suspended overhead via the hanging bracket. If the unit is to

be mounted using the bracket, it is important that the fog does not shoot directly at any one's face.

Whatever installation method you choose, do not allow the unit to have more than a 15° angle of

inclination.

If you experience low output, pump noise or no output at all, unplug immediately. Check fluid level, the

external fuse, control module connection, and power from the wall. If all of the above appears to be

O.K., plug the unit in again. If fog does not come out after holding the control module button MANUAL

down for 30 seconds, check the hose attached to the tank to make sure there is fluid going

through the hose. If you are unable to determine the cause of the problem, do not simply continue

pushing the control module button, as this may damage the unit. Return the machine to your ANTARI

dealer.

Menu Settings With The Button FUNCTION

Setting time intervals for timer operation

Press the button FUNCTION until the display indicates「Interval Set」. Use the buttons

UP and DOWN to adjust the intervals between the individual fog outputs in timer

mode within the range of 1 and 200 seconds.

Important

Always monitor tank fluid level when you are fogging. Running a fog machine with no

fluid can permanently damage the unit.

Setting the output duration for timer operation

- Press the button FUNCTION until the display indicates「Duration Set」. Use the buttons

UP and DOWN to adjust the duration of the fog outputs in timer mode within the range

of 1 and 200 seconds.

Setting the fog output volume for timer operation

- Press the button FUNCTION until the display indicates「Timer Out」. Use the buttons

UP and DOWN to adjust the fog output volume in timer mode within the range of 1 % and 100

Setting the fog output volume for continuous operation

- Press the button FUNCTION until the display indicates「Volume Out」. Use the buttons

UP and DOWN to adjust the fog output volume in continuous mode within the range of

1 % and 100 %.

- To set the unit to continuous fog output, select 「NON STOP BURST」below a value of 1 % or above

a value of 100 %.

Setting the DMX512 address

Press the FUNCTION until the display indicates「DMX 512 Add」. Use the buttons UP

and DOWN, to set the machine to the same address as on your DMX controller. Please refer

to the chapter DMX512 settings for more information on DMX operation.

Turning the heater on or off

Press the FUNCTION until the display indicates「Heater On」. Use the button

MANUAL, to switch the heater on or off.

Continuous operation

Press the button VOLUME , to activate continuos fog output. The display indicates「Volume」

followed by the value that was set in menu item「Volume Out」or 「NON STOP BURST」. To stop

the fog output, press the button VOLUME once again.`

Manual operation

For immediate fog output at the maximum volume of fog, keep the button MANUAL pressed.

The display indicates「Manual Output」. As soon as you release the button, the fog output will stop.

The manual operation will take priority over the continuous operation and the timer operation. Even if

one of these operating modes is activated, the fog machine will always emit the maximum volume of

fog when the button MANUAL is pressed.

Timer operation

In the timer mode, the fog machine will automatically emit fog. The time intervals, duration and fog

volume depend on the corresponding menu settings. Press the button TIMER , to activate the

timer mode. The display indicates the set time interval. The unit counts down to 0 seconds and emits

fog. To deactivate the timer mode, press the button TIMER again.

Antari X-30PRO Control Module Operation

X-30PRO Wireless Control Module Operation

All the X-10PRO features plus wireless capability.

The wireless control module X-30PRO consists of a transmitter equipped with two buttons for fog on

and off, and a receiver pre-attached to the panel of each X-30PRO.

* Transmitter:

With the transmitter it is possible to emit fog via radio over a distance of up to 50 meters. The

transmitter is compatible to any receiver of the X-30PRO and can control an unlimited number of

machines in parallel.

Press the button “A”, to emit fog. The button “A” has the same function as the button VOLUME on the

control panel, i.e. the fog output depends on the setting of menu item »Volume Out«. The display

indicates 「Volume」followed by the defined value or 「NON STOP BURST」when continuous fog

output was selected. To stop the fog output, press the button “B”.

* Receiver:

The receiver is tested and pre-attached to the panel of each X-30PRO. Please do not try to remove it.

The receiver responds to up to 5 different transmitters that are registered with the machine. The

included transmitter has been registered to the machine before shipment. It can be directly operated

without any start-up setting.

-Registering transmitters

To operate the machine with a different transmitter than the included one, or to operate it with up to 5

different transmitters, each transmitter must be registered first. For this purpose, turn on the machine.

When the display indicates 「Wireless Setup」, press the button “A” 1 second on each transmitter.

Thus the previous transmitters are cleared from the memory of the receiver. The setting must be

completed within 15 seconds after switching on the machine. Then the machine will automatically exit

the transmitter setting mode. The display shows 「Wireless Setup OK」. At this point, no further

transmitter can be added.

If no transmitter is registered when the machine is switched on, the memory of the receiver will keep

the record of the previous operation.

Setting Example 1:

In order to register several transmitters with a machine, turn on the machine. When the display

indicates 「Wireless Setup」, press the button “A” 1 second on each transmitter within 15 seconds to

establish the signal transmission.

Setting Example 2:

In order to use 1 transmitter to control 2 or more machines, turn on the machines respectively. When

the displays indicate「Wireless Setup」, press the button “A” 1 second on the transmitter within 15

seconds to establish the signal transmission.

- Battery change on the transmitter

If the range of the transmitter decreases, the battery is probably exhausted and must be replaced. For

this purpose, take off the housing cover and remove the used battery. Insert a fresh battery as

indicated in the battery compartment and refit the housing cover.

- Switching the wireless function on and off

Press the button FUNCTION until the display indicates 「Wireless On」. Use the buttons UP and

DOWN to deactivate the wireless function (indication 「Wireless Off」) and to reactivate it (indication

「Wireless On」).

* Note: When warming-up process is completed and wireless function is activated the LCD screen

indicates “Ready To Fog W”. (“W” means Wireless) On the contrary, when the wireless function is

deactivated the LCD screen shows “Ready To Fog” (Without “W”).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Máquina de niebla de Antari

Antari

Antari Z-1200 III Manual de usuario

Antari

Antari Z-1520 RGB Manual de usuario

Antari

Antari W-508 Manual de usuario

Antari

Antari Z-350 FAZER Manual de usuario

Antari

Antari IP-1500 Manual de usuario

Antari

Antari S-120 Manual de usuario

Antari

Antari FT-55 Manual de usuario

Antari

Antari Z II Series Manual de usuario

Antari

Antari F-2 Fazer Manual de usuario

Antari

Antari FT-100 Fire Training Manual de usuario

Antari

Antari F-80ZY Manual de usuario

Antari

Antari Fazer Z-300 Manual de usuario

Antari

Antari Z-800II Manual de usuario

Antari

Antari FT-100 Fire Training Manual de usuario

Antari

Antari B-200 Manual de usuario

Antari

Antari Z-1200II Manual de usuario

Antari

Antari FT-100 Fire Training Manual de usuario

Antari

Antari M-11 Manual de usuario

Antari

Antari Z-3000II Manual de usuario

Antari

Antari Fog cooler DNG-100 Manual de usuario

Antari

Antari X FOGGER Manual de usuario

Antari

Antari M-8 Manual de usuario

Antari

Antari HZ-350 Manual de usuario

Antari

Antari F-5 Fazer Manual de usuario

Manuales populares de Máquina de niebla de otras marcas

Boost

Boost BOOST-FOG400LED-BK Manual de usuario

Home Accents Holiday

Home Accents Holiday FM1000-ASH Manual de usuario

EuroLite

EuroLite ZEITGEIST FOG-1200 Manual de usuario

Dyna-Fog

Dyna-Fog CYCLONE ULTRA 2734 Manual de usuario

PROEL

PROEL DRAGO HEAVY PLFD150HY Manual de usuario

Sparklyn

Sparklyn Y846 Manual de usuario

Magicfx

Magicfx CO2 Gun Manual de usuario

Ibiza

Ibiza LSM500LAS Manual de usuario

Venue Lighting Effects

Venue Lighting Effects ULTRA MINI-FOGGER Manual de usuario

High End

High End F-100 Manual de usuario

Chauvet

Chauvet ARENA 2100 FLEX Manual de usuario

Beamz

Beamz F1600 Manual de usuario

Sagitter

Sagitter SG ARS900C Manual de usuario

KISANKRAFT

KISANKRAFT KK-STF-480 Manual de usuario

Orion

Orion OT-U250PP Guía

Beamz

Beamz S2500 Manual de usuario

American DJ

American DJ Dyno-Fog II Manual de usuario

JB Systems

JB Systems FX 1700 Manual de usuario
