H91

Components Required:

❏ Bath Filler*: (specify nish)

❏ Bath Drain: 1599.205.XXX (specify color)

Custom Accessories Available:

❏ Safe-T-Heater Whirlpool Heater: 9075.120

❏ 5 Foot Apron: 9261.019.XXX (specify color)

❏ Tile Bead Kit: 751755-100

For color/nish availability and other faucet choices, please

see the Product Selector and Pricing Guide.

NOTE: Whirlpool Heater is designed to maintain water

temperature during operation. It will not heat cold water to

desired bathing temperature.

EVOLUTION™ 5' x 32"

Comfortable bathing design with form-tted

backrest and molded-in armrests

❏ 2422VC Whirlpool w/EverClean® System

• EverClean® System

• Deep Soak overow drain

• 1.4 HP single speed pump/motor

• Side-mounted air switch On/Off

• Eight Jet system featuring:

- Two ow adjustable Comfort Jets™

Hi-Flo Jets

- Six ow adjustable Comfort Jets™

including two in lumbar area

• Two silent air volume controls

• Undermount installation option

• Quick connect whirlpool heater system

(must order whirlpool heater separately)

❏ 2422V Whirlpool

• Same as 2422VC without EverClean System

❏ 2422V.002 Bathing Pool

Nominal Dimensions:

60" x 32" x 21-1/2"

(1524 x 813 x 546mm)

Compliance Certications -

Meets or Exceeds the Following Specications:

• Underwriters Laboratories - Hydromassage

Bathtubs UL 1795

• ASME A112.19.7M for Whirlpool Appliances

• ANSI Z124.1 for Plastic Bathtubs

• ASTM E162 for Flammability

• NFPA 258 for Smoke Density

American Standard whirlpools with EverClean®

incorporate a patented silver-ion additive right

into the circulation piping to protect the pipes

from mold, mildew, algae and fungus that could

cause deterioration or staining of the pipes.

SEE REVERSE FOR ROUGHING-IN DIMENSIONS

AND PRODUCT SPECIFICATIONS

* See American Standard Faucet Selector

EVOLUTION™ 5' x 32"

WHIRLPOOL AND BATHING POOL

HIGH GLOSS

H92

EVOLUTION™ 5' x 32"

WHIRLPOOL AND BATHING POOL

HIGH GLOSS

Revised 3/06

NOTES:

BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION.

SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL BY OTHERS.

■REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.

FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.

IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1

These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided leaet.

Model 2422VA

shown

60 x 32 x 21-1/2 In.

(1524 x 813 x 546mm)

74 Lbs. (34 Kg.)

690 Lbs. (313 Kg.)

74 Gal. (280 L)

33 Gal. (125 L)

41-1/4 x 22-1/4 In. (1048 x 565mm)

52-1/4 X 26 In. (1327 x 660mm)

18-1/2 In. (470mm)

52 Lbs./Sq.Ft. (253 Kgs./Sq.m)

GENERAL SPECIFICATIONS FOR 2422V WHIRLPOOL

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

WHIRLPOOL MIN. OPERATING VOL.

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)

WHIRLPOOL ELECTRICAL SPECIFICATIONS

1.4 HP, 9.7 AMPS, 120V.PUMP

60"

(1524mm)

32"

(813mm)

11"

(279mm)

7-3/4"

(197mm)

13-3/4"

(349mm)

(152mm)

(76mm)

3-1/4"

(83mm)

32"

(813mm)

20"(C)

(502mm)

21-1/2"(H)

(546mm)

C/L OF

OVERFLOW

20-1/8"(A)

(511mm)

CUT OUT IN FLOOR

FOR DRAIN

DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE

OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.

GENERAL SPECIFICATIONS FOR 2422V BATHING POOL

60 x 32 x 20-1/2 (1524 x 813 x 546mm)

54 Lbs. (27 Kg.)

675 Lbs. (306 Kg.)

74 Gal. (280 L.)

41-1/4 x 22-1/4 In. (1048 x 565mm)

52-1/4 x 26 In. (1327 x 660mm)

18-1/2 (470mm)

57 Lbs./Sq.Ft. (247 Kgs./Sq.m)

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)
