AmazonBasics B082L6KJ2J Manual de usuario

Universal Sound Bar TV Bracket

Support Universel pour Téléviseur et Barre de Son

Universalhalterung für Soundbar und TV

Staffa di Montaggio Barra del Suono Universale per TV

Soporte para TV y Barra de Sonido Universal

Universele TV-beugel voor Soundbar

ユニバーサウンドバーTVブラケット

B082L6KJ2J

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Nederlands . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

日本語 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Assembly • Montage • Montage •

Montaggio • Montaje • Montage •

組み立て . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

A(x 2)

5/8" (M4 x 16 mm)

B(x 2)

5/8" (M5 x 16 mm)

C(x 2)

15/32" (M6 x 12 mm)

D(x 2)

5/8" (M6 x 16 mm)

E(x 2)

5/8" (M6 x 16 mm)

F(x 2)

J(x 4)

K(x 1)

L(x 4)

35/64" (M4 x 14 mm)

M(x 4)

1-9/16" (M4 x 40 mm)

N(x 4)

5/8" (M6 x 16 mm)

O(x 4)

1-3/8" (M6 x 35 mm)

P(x 4)

Q(x 4)

25/32" (M8 x 20 mm)

R(x 4)

1-15/16" (M8 x 50 mm)

S(x 4)

T(x 8)

0.39" (10 mm)

U(x 2)

0.15" (4 mm)

G(x 1)

H(x 2)

I(x 2)

IMPORTANT SAFEGUARDS

Read these instructions carefully and retain them for future use.

If this product is passed to a third party, then these instructions

must be included.

When using the product, basic safety precautions should always be

followed to reduce the risk of injury including the following:

NOTICE This product is for indoor use only! Never use the mount

outdoors!

NOTICE This product is for private household use only and therefore

may not be used in public places like restaurants or hotels.

• A competent adult must install this product.

• Keep children and pets away while installing the product.

• Do not use this product if any parts are missing, damaged, or worn.

• Do not overtighten the fasteners.

• Regularly examine the product for wear and tear. Stop using the

product at ﬁrst sign of damage or if parts become detached.

CAUTION Risk of injury! This mount is intended for use only

with the maximum weight of 22 lbs (10 kg). Use with heavier than the

maximum weights indicated may result in instability causing possible

injury.

CAUTION Risk of injury! Only use this mount with TV mounts that

are rated to hold the total weight of the TV, soundbar, and this mounting

bracket.

CAUTION Risk of injury! Never use the mount with stand alone

TV’s. TVs, and their included stand/support, are designed for the weight

and balance of the TV only, not additional accessories.

Before First Use

• Check the product for transport damages.

• Remove all the packing materials.

DANGER Risk of suffocation! Keep any packaging materials

away from children – these materials are a potential source of danger,

e.g. suffocation.

Cleaning and Maintenance

Cleaning

• To clean the product, wipe with a soft, slightly moist cloth.

• Never use corrosive detergents, wire brushes, abrasive scourers,

metal or sharp utensils to clean the product.

Maintenance

• Regularly check that all the components and fasteners are tightened.

• Store the product in a cool and dry place away from children and

pets, ideally in its original packaging.

• Avoid any vibrations and shocks.

Speciﬁcations

Net weight: approx. 2 lbs (0.92 kg)

Dimensions (W x H x D): approx. 27 x 1.69 x 1.18"

(687 X 43 X 30 mm)

Feedback and Help

Love it? Hate it? Let us know with a customer review.

AmazonBasics is committed to delivering customer-driven products

that live up to your high standards. We encourage you to write a review

sharing your experiences with the product.

US: amazon.com/review/review‑your‑purchases#

UK: amazon.co.uk/review/review‑your‑purchases#

US: amazon.com/gp/help/customer/contact‑us

UK: amazon.co.uk/gp/help/customer/contact‑us

16.8" (427 mm)

20.6" (524 mm)

25.4" (644 mm)

C J

C(x 2)

J(x 2)

G(x 1)

A B

F H

F I

Installation type / Type d’installation /Installationsart /

Tipo di installazione

/ Tipo de instalación /

Installatietype /

設置の種別

A(x 2)

B(x 2)

D(x 2)

E(x 2)

F(x 2)

H(x 2)

I(x 2)

A B

P S

L M N O Q R

L(x 4)

M(x 4)

N(x 4)

O(x 4)

P(x 4)

Q(x 4)

R(x 4)

S(x 4)
