Akko 3068 BT5.0 Manual de usuario
用户手册
User Manual
BT5.0
蓝牙版
311 x 102 x 40mm
Approximately 0.63KG
PBT Material
Bluetooth / Wired
Type-C To USB
1800mAh
YES
YES
YES (use Akko Marco V1.0)
Mechanical Keyboard
China
3068 Technical Specifications
13
Dimensions
Weight
Keycap
Connection
Interface
Battery Capacity
Multimedia Keys
N-Key Rollover
Custom Keys
Type
Country of Origin
CtrlFn
3068 HotKeys
14
Menu
Cal
Insert
Home
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
1 2 3 4 5 6 7 8 9 10 - =
End
W
M < > PgDn
PgUp
I
C
F1 - F10
F11
F12
Home
End
Fn+
1 - 0
-
=
PgUp
PgDn
=
Calculator
Insert
Mute
Decrease Volume
Increase Volume
C
I
M
<
>
Fn+ =
Revert Ctrl into Menu (APP) key
Swap W A S D with ↑↓ ← →
Fn+ W
Hold down FN and press right Ctrl
Ctrl
Fn
Fn
～
Press Fn and left Win key
Lock Windows Key
Hold down Fn and press ～ key
Restore Factory Settings
3068 System Commands
15
Win
Win
Fn
～
3068 Backlight Settings
16
Bright
Dim
Slower Animation
Faster Animation
Light On/Off
17 Lighting Effects
“↑”
“↓”
“←”
“→”
L
Del
Fn+ =
In Bluetooth mode, the light is turned
off by default for power saving.
Press Fn+L to turn on the light.
↑
↑
↑
↑
Fn
Del
L
～
3068 Bluetooth Feature Overview
17
Wired Mode
Searching for device. The light will turn off after pairing is successful.
Switching device. The light will turn off after connection is established.
TAB LED
Cable Plugged-in Charging
Fully Charged
Bluetooth Mode/Cable Unplugged Flashing Light
Lights On
Lights Off
ON
Fast Flashing
Slow Flashing
Power LED
Low Battery
18
3068 Bluetooth Setup Instruction 1
1.Switch to Bluetooth mode
Long press FN+Tab and the Tab LED flashes. This means the Bluetooth mode is activated.
2.Set the Bluetooth profile
The keyboard can memorize 4 switchable Bluetooth devices, which are saved in 4 Bluetooth profiles through
short-cuts Fn+E/R/T/Y (corresponds to BT1/BT2/BT3/BT4); When you first use the keyboard, select a desired
Bluetooth profile by pressing Fn+E/R/T/Y to initialize device searching ; Once it’s been setup and paired,
whenever you use the keyboard again, it would memorize the last Bluetooth device it has been worked on,
trying to send Bluetooth signal to communicate with the specific device.
3.Bluetooth Pairing
When you use your PC/ PAD/iPhone to pair with the keyboard, and the Bluetooth mode of the keyboard and
PC/PAD/iPhone have all been turned on, the keyboard would show up based on the Bluetooth profile you set in
step 2 such as Akko 3068-BT1 / Akko 3068-BT2 / Akko 3068-BT3 / Akko 3068-BT4.
19
3068 Bluetooth Setup Instruction 2
4.Switch the Bluetooth device
After 4 Bluetooth devices have been paired with the keyboard, long press Fn+E / Fn+R / Fn+T / Fn+Y for at
least 3 seconds to quickly switch between them.
5.Shut off the keyboard
Turn the power off on the keyboard back panel while unused for power saving;
If the keyboard remains unused for over 10 mins, it would go to sleep mode and you can activate it by
pressing any key.
Note: The battery saver mode for Windows system would affect/delay the sleep activation time of the keyboard.
6.Reset the keyboard
If you forgot the specific paired front-end device or if there remains disorder in Bluetooth conneciton and
communication, you can press Fn + ~ to reset the keyboard. This action erases all pairing information stored
in your keyboard.
Akko Macro V1.0
Macro Setup Instruction 1
20
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn" and "Left Win".
3. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the
two keys in the order of A followed by B.
4. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key
B cannot be defined and will follow the system's default trigger time.
Akko Macro V1.0
Macro Setup Instruction 2
21
Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Left Win Fn+Esc (End Recording)(Press Keys to Store)
Clear Macro：
If a key has been defined, after entering the Macro editor, you can press “FN + the key” to
clear its definition.
If you want to re-customize that key, press “FN + the key”again to start the new Macro
recording after clearing its old definition.
