Akko ACRYLIC87 Manual de usuario
用户手册
User Manual
8
System Commands
Note: The following features are realized by the combination of “Fn” + corresponding key
F1
F2
F3
F4
F5
F6
F7
F8
File Explorer
E-mail
Windows Search
Browser Homepage
Media
Pause /Playback
Previous Song
Next Song
Hold down Fn and press right Ctrl
Revert Ctrl into Menu (APP) key
C
M
<
>
Left Win
Calculator
Mute
Decrease Volume
Increase Volume
Lock Win
Swap W A S D
with ↑↓ ←→
W
Press and hold the
left Win + right Win together
for 5 seconds.
Restore Factory Settings
9
Backlight Settings
Note: The following features are realized by the combination of “Fn” + corresponding key
F9
F10
F11
F12
-
+
ScrLK
Acrylic Case Light Animation Faster
Acrylic Case Light Animation Slower
Acrylic Case Light Dimmer
Acrylic Case Light Brighter
Slower Animation
Faster Animation
Light On / Off
Bright
Dim
Change Animation Direction
Change Color
↑
↓
←
→
Ins
Del
Home
End
PgUp
PgDn
Lighting Effect A
Lighting Effect B
Lighting Effect C
Lighting Effect D
Lighting Effect E
Lighting Effect F
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn", "Left Win" and "Right Win".
3. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will
trigger the two keys in the order of A followed by B.
4. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key
A and key B cannot be defined and will follow the system's default trigger time.
10
Akko Macro V1.0 Macro Setup Instruction 1
11
Akko Macro V1.0 Macro Setup Instruction 2
Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Left Win Fn+Esc (End Recording)
(Press Keys to Store)
Clear Macro：
If a key has been defined, after entering the Macro editor, you can press “FN + the key” to clear
its definition.
If you want to re-customize that key, press “FN + the key”again to start the new Macro recording
after clearing its old definition.
Step 1: Press Fn + left Win for 3 seconds to enter the Macro mode.
Step 2: Press Fn + ESC to launch Macro editor.
Step 3: Press Fn + A. This means we choose key “A” to record.
Step 4: Press A, K, K, O, G, E, A, R in order as replacement definition of “A”.
Step 5: Press Fn + A again to end the Macro recording of key “A”.
At this point, pressing “A” in notepad will display “AKKOGEAR”.
If you want to create a Macro for key “B”, press Fn + B to start the Macro recording.
Step 6: Press Fn + Esc to exit Macro editor.
Under the Macro mode, you can configure the keys and Macros you set.
Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key definition.
Macro Recording Example: Define “A” as “AKKOGEAR”
12
Akko Macro V1.0 Macro Setup Instruction 3
Method A:
Enter the Macro mode by long pressing Fn+left Win. Then all keys will turn to pre-configured definitions with locked
Win key. Press Fn+Win to unlock Win key if necessary. In the Macro mode, you can use keys with customized definitions.
Note, everytime you reboot or re-plugged the cable of the keyboard, the Macro mode will be turned off by default and
all keys will return to default definitions until you re-enter the Macro mode.
Method B:
Under the default key definition, you can also quickly call the customized content of specific keys through “Fn+right
Alt+the key that has been defined through Macro”. Note that you must first press Fn and then press Alt to call the Macro.
13
Akko Macro V1.0 Calling Macros
1. Akko provides 1-yr warranty for customers in mainland China. For other regions, please contact your
seller (Akko distributor) for specific warranty policy.
2. If the warranty window expires, customers need to pay for repairs. Akko will also provide instructions
if users
prefer to repair the keyboard by themselves. However, users shall take full responsibility for any loss
happenedduring self-repair.
3. Dissembling the keyboard without manufacturer/seller’s instruction will immediately void the warranty.
4. The return and warranty policy may vary in different platforms and are subject to the specific distribu-
tor at the time of purchase.
Precautions Man-made damage is not limited to immersion, falling off, and pulling off the wires with excessive forces, etc.
14
Akko Warranty and Service Statement
www.akkogear.com
扫描关注官方微博扫描关注官方微信
instagram.com/akkogear
facebook.com/akkogear
