Akko 3098 Manual de usuario

用户手册

User Manual

382 x 134 x 40mm

Approximately 1.05KG

China

Mechanical Keyboard

PBT Material

Type-C To USB

YES

YES (use Akko Marco V1.0)

3098 Technical Speciﬁcations

Dimensions

Weight

Country of Origin

Type

Keycap

Interface

Multimedia Keys

N-Key Rollover

Custom Keys

3098 HotKeys

Hold down FN and press right Ctrl Revert Ctrl into Menu (APP) key

File Explorer

E-mail

Windows Search

Browser Homepage

Media

Fn+

Pause/Playback

Previous Song

Next Song

Print Screen

Calculator

Fn+

Mute

Decrease Volume

Increase Volume

Fn+ =

Swap W A S D

with ↑↓ ← →

Cal

PrtSc

C M < >

Ctrl

F1 F2 F3 F4 F5 F6 F7 F8

3098 System Commands

Press Fn and left Win key

Lock Windows Key

Hold down Fn and press ～ keyRestore Factory Settings

Win

3098S Single-Color Backlight

*Backlight function is only available on the backlight version of 3098s.

Lighting Eﬀect 1

Lighting Eﬀect 2

Lighting Eﬀect 3

Lighting Eﬀect 4

Del

Ins

PgUp

PgDn

Bright

Dim

Slower Animation

Faster Animation

“↑”

“↓”

“-”

“+”

Fn+ Fn+

The adjustments on the left is for generic

lighting eﬀects. Some lighting eﬀects

cannot be tweaked.

For example, eﬀects with constant light

can only adjust brightness as they don’t

have animation speed and direction.

Del Ins PgUp PgDn

↑

Fn+ =

3098S Custom Backlight

1. The keyboard provides 4 groups of Fn + (F9 ~ F12) customizable lighting eﬀects.

The system has 4 groups of default pre-loaded lighting eﬀects that can be triggered.

2. Press Fn + (F9 ~ F12) to trigger custom lighting eﬀects.

3. Edit custom lighting eﬀects:

Step 1. Press Fn + (F9 ~ F12) to enter the custom lighting mode.

Step 2. Press Fn + (F9 ~ F12) again to start editing. Press to specify the desired illuminated keys for the

speciﬁc lighting eﬀect group.

Step 3. Continue to press Fn + (F9 ~ F12) to save the changes.

F9 F10 F11 F12

Akko Macro V1.0

Macro Setup Instruction 1

1. Akko Macro V1.0 is hardware-based and works without software-driven.

2. The following keys cannot be programmed: "Esc", "Fn" and "Left Win".

3. Press and hold Fn + Win for 3 seconds to switch to the Macro mode. When the keyboard is re-connected or the

system is restarted, the Macro mode will be exited. You need to switch to the Macro mode again to use

programmed keys.

4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the

two keys in the order of A followed by B.

5. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key

B cannot be deﬁned and will follow the system's default trigger time.

Akko Macro V1.0

Macro Setup Instruction 2

Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key

Exit Macro EditorExit Macro Mode

Fn + Custom Key

Record the next Key

Back to Default Mode Fn+Esc

Long Press Fn +Left Win Fn+Esc (End Recording)(Press Keys to Store)

Clear Macro：

If a key has been deﬁned, after entering the Macro editor, you can press “FN + the key” to

clear its deﬁnition.

If you want to re-customize that key, press “FN + the key”again to start the new Macro

recording after clearing its old deﬁnition.

Akko Macro V1.0

Macro Setup Instruction 3

Step 1: Press Fn + left Win for 3 seconds to enter the Macro mode.

Step 2: Press Fn + ESC to launch Macro editor.

Step 3: Press Fn + A. This means we choose key “A” to record.

Step 4: Press A, K, K, O, G, E, A, R in order as replacement deﬁnition of “A”.

Step 5: Press Fn + A again to end the Macro recording of key “A”.

At this point, pressing “A” in notepad will display “AKKOGEAR”.

If you want to create a Macro for key “B”, press Fn + B to start the Macro recording.

Step 6: Press Fn + Esc to exit Macro editor.

Under the Macro mode, you can conﬁgure the keys and Macros you set.

Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key deﬁnition.

Macro Recording Example: Deﬁne “A” as “AKKOGEAR”

Akko Macro V1.0 Calling Macros

Method A:

Enter the Macro mode by long pressing Fn+left Win. Then all keys will turn to pre-conﬁgured deﬁnitions with

locked Win key. Press Fn+Win to unlock Win key if necessary. In the Macro mode, you can use keys with

customized deﬁnitions.

Note, everytime you reboot or re-plugged the cable of the keyboard, the Macro mode will be turned oﬀ by

default and all keys will return to default deﬁnitions until you re-enter the Macro mode.

Method B:

Under the default key deﬁnition, you can also quickly call the customized content of speciﬁc keys through

“Fn+right Alt+the key that has been deﬁned through Macro”. Note that you must ﬁrst press Fn and then press

Alt to call the Macro.
