Akko 5087B Plus Manual de usuario
用户手册
User Manual
Benutzerhandbuch
Dimensions
Approximately
360*132*40mm
Key/Lighting Effects Customization
Programmable through software in wired
or 2.4G mode.
Weight
Approximately
0.9kg
Country of
Origin
China
Type
Mechanical Keyboard
Keycap
PBT Material
Connection
Bluetooth/USB/2.4Ghz
Interface
Type-C To USB
Multimedia Keys
YES
N-Key Rollover
YES
Battery
Capacity
3000mAh
Technical Specifications
HotKeys
*The key combinations below are applicable to Windows system. The combination might change with respect
to different Windows systems or along with system updates. Please follow Akko website for the latest
File Explorer
E-mail
Windows Search
Browser Homepage
Media
Pause / Playback
Previous Song
Next Song
Swap W A S D
with ↑↓ ← →
Calculator
Mute
Decrease Volume
Increase Volume
Lock Windows Key
Fn + left Win / right Win
Restore Factory Setting
Press and hold the left Win
+ right Win together for 5
seconds.
Revert Ctrl into Menu (APP) key
Hold down Fn and press right
Ctrl
System Commands (Windows)
System Commands(Mac)
Decrease display
Increases display
Open mission control
Activate Siri
Skip back (Audio)
Pause/Play (Audio)
Skip forward (audio)
Mute
Volume down
Volume up
Command
Option
Left Win
LeftAlt
Command
Option
Right Win
Right Alt
Effect 1 / Effect 2 / Effect 3
Effect 4 / Effect 5 / Effect 6
Effect 7 / Effect 8 / Effect 9 / Effect
10
Effect 11 / Effect 12 / Effect 13
Effect 14 / Effect 15 / Effect 16
Effect 17 / Effect 18/ Effect 19 /
Ins
Home
PgUp
Del
End
PgDn
L
Lock Win
Bright
Dim
Set animation direction to
Set animation direction to
Slower Animation
Faster Animation
Backlight Settings
Bluetooth Feature Overview
Caps Lock Battery Level
Lock Win
Bluetooth device 1
Bluetooth device 2
Bluetooth device 3
2.4G wireless
Wired mode
Short press to connect with slow
flashing blue LED;
Press and hold to pair device with
fast flashing blue LED.
Short press to connect with slow
flashing green LED;
The lighting effect will be
restored when pairing succeeds.
Back Switch Indicator
Left: Windows Mode
(Internal Power Supply ON)
Middle: Mac Mode by Default
(Internal Power Supply OFF)
Right: Mac Mode
(Internal Power Supply ON)
Bluetooth Setup Instruction 1
1. Switch to Bluetooth mode
2. Set the Bluetooth profile
① When the keyboard remains unplugged, turn the back switch to ON. Then long press and hold Fn + E / R / T to start
pairing with Bluetooth devices. The keyboard will enter Bluetooth pairing mode when the blue LEDs under E / R / T keys
flash quickly.
② When the Keyboard is plugged into the computer through USB interface, it will enter Bluetooth mode automatically
without having to push the switch on the back. Users can directly long press and hold Fn + E / R / T to enable
Bluetooth pairing. The keyboard will enter Bluetooth pairing mode when the blue LEDs under E / R / T keys flash
To help user recognize individual Bluetooth device, the keyboard is equipped with both Bluetooth 5.0 and 3.0
frameworks. The device name under the Bluetooth 5.0 framework is 5087BP-1 / 5087BP-2 / 5087BP-3 while the device name
under Bluetooth 3.0 is Akko 5087BP BT3.0. Once the devices are paired through Fn + E/R/T, the system will by default
memorize the last connected device before you turn off the Bluetooth mode.
3. Bluetooth Pairing
The keyboard can be paired with PC, Pad, smartphone and other devices with Bluetooth turned on. When you first try to
search Bluetooth devices, two groups of device names shall appear with Akko 5087 BT3.0 (Bluetooth 3.0) and 5087BP-1
(Bluetooth 5.0). Select a Bluetooth group based on your preferences (Note: some devices can only search for the Bluetooth
4. Switch the Bluetooth device
After 4 Bluetooth devices have been paired with the keyboard, press Fn+E / Fn+R / Fn+T / Fn+Y for at least 3 seconds to
quickly switch between them.
5. Shut off the keyboard
Turn the power off on the keyboard back panel while unused for power saving;
If the keyboard remains unused for over 10 mins, it would go to sleep mode and you can activate it by pressing any key.
Note: The battery saver mode for Windows system would affect/delay the sleep activation time of the keyboard.
6. Reset the keyboard
If you forgot the specific paired front-end device or if there remains disorder in Bluetooth connection and
communication, you'll need to clear the computer's Bluetooth cache by removing the 5087 keyboard from the list of
Bluetooth Setup Instruction 2
Key/Lighting Effects Customization
1. The key/lighting effects customization must be completed in wired mode with Akko
driver.
2. In wired mode, the lighting effects can also achieve music rhythm effects with Akko
driver.
3. Please download the Akko Cloud driver on our website.
