Agilent 7890A Gas Chromatograph

Safety Manual

Agilent Technologies

Introduction

Important Safety Warnings 4

Hydrogen Safety 7

Micro-Electron Capture Detector (µECD) 14

Fuses and Batteries 16

Safety and Regulatory Certifications 17

Intended Use 20

Cleaning 20

Recycling the Product 20

47890A GC Safety Manual

Introduction

Important Safety Warnings

Before moving on, there are several important safety notices that you

should always keep in mind when using the Agilent 7890A GC.

Many internal parts of the GC carry dangerous voltages

If the GC is connected to a power source, even if the power switch is off,

potentially dangerous voltages exist on:

•The wiring between the GC power cord and the AC power supply, the

AC power supply itself, and the wiring from the AC power supply to

the power switch.

With the power switch on, potentially dangerous voltages also exist on:

•All electronics boards in the instrument.

•The internal wires and cables connected to these boards.

•The wires for any heater (oven, detector, inlet, or valve box).

WARNING

When handling/using chemicals for preparation or use within the GC, all applicable

local and national laboratory safety practices must be followed. This would include,

but is not limited to, correct use of Personal Protective Equipment (PPE), correct use

of storage vials, and correct handling of chemicals, as defined in the laboratory’s

internal safety analysis and standard operating procedures. Failure to adhere to

laboratory safety practices could lead to injury or death.

WARNING

All these parts are shielded by covers. With the covers in place, it should be difficult

to accidentally make contact with dangerous voltages. Unless specifically

instructed to, never remove a cover unless the detector, inlet, or oven are turned off.

WARNING

If the power cord insulation is frayed or worn, the cord must be replaced. Contact

your Agilent service representative.

Introduction

7890A GC Safety Manual 5

Do not use an Uninterruptable Power Supply (UPS) with a GC

If the area where the GC is located suddenly looses power, an unsafe

condition can result if the GC remains powered on. Do not use the GC

with a UPS.

Electrostatic discharge is a threat to GC electronics

The printed circuit (PC) boards in the GC can be damaged by electrostatic

discharge. Do not touch any of the boards unless it is absolutely

necessary. If you must handle them, wear a grounded wrist strap and take

other antistatic precautions. Wear a grounded wrist strap any time you

must remove the GC right side cover.

Many parts are dangerously hot

Many parts of the GC operate at temperatures high enough to cause

serious burns. These parts include but are not limited to:

•The inlets

•The oven and its contents

•The detectors

•The column nuts attaching the column to an inlet or detector

•The valve box

You should always cool these areas of the GC to room temperature before

working on them. They will cool faster if you first set the temperature of

the heated zone to room temperature. Turn the zone off after it has

reached the setpoint. If you must perform maintenance on hot parts, use a

wrench and wear thermally protective gloves. Whenever possible, cool the

part of the instrument that you will be maintaining before you begin

working on it.

WARNING

Be careful when working behind the instrument. During cool-down cycles, the GC

emits hot exhaust which can cause burns.

67890A GC Safety Manual

Introduction

Oven thermal leaks

Do not allow wiring or temperature probes to pass through the oven door

jam. Agilent recommends using one of the access holes.

WARNING

The insulation around the inlets, detectors, valve box, and the insulation cups is

made of refractory ceramic fibers. To avoid inhaling fiber particles, we recommend

the following safety procedures: ventilate your work area; wear long sleeves,

gloves, safety glasses, and a disposable dust/mist respirator; dispose of insulation

in a sealed plastic bag; wash your hands with mild soap and cold water after

handling the insulation.

WARNING

Objects passing through the oven door seal can cause thermal leaks which create

hazardous hot spots which cause burns and melt equipment.

Introduction

7890A GC Safety Manual 7

Hydrogen Safety

Hydrogen gas may be used as carrier gas, and/or as fuel for the FID, FPD,

and NPD. When mixed with air, hydrogen can form explosive mixtures.

Hydrogen is a commonly used GC carrier gas. Hydrogen is potentially

explosive and has other dangerous characteristics.

•Hydrogen is combustible over a wide range of concentrations. At

atmospheric pressure, hydrogen is combustible at concentrations from

4% to 74.2% by volume.

•Hydrogen has the highest burning velocity of any gas.

•Hydrogen has a very low ignition energy.

•Hydrogen that is allowed to expand rapidly from high pressure into the

atmosphere can self- ignite due to an electrostatic spark.

•Hydrogen burns with a nonluminous flame which can be invisible under

bright light.

GC precautions

When using hydrogen as a carrier gas, remove the large round plastic

cover for the MSD transfer line located on the GC left side panel. In the

unlikely event of an explosion, this cover may dislodge.

WARNING

When using hydrogen (H2) as the carrier gas or fuel gas, be aware that hydrogen

gas can flow into the GC oven and create an explosion hazard. Therefore, be sure

that the supply is turned off until all connections are made and ensure that the inlet

and detector column fittings are either connected to a column or capped at all times

when hydrogen gas is supplied to the instrument.

Hydrogen is flammable. Leaks, when confined in an enclosed space, may create a

fire or explosion hazard. In any application using hydrogen, leak test all

connections, lines, and valves before operating the instrument. Always turn off the

hydrogen supply at its source before working on the instrument.

87890A GC Safety Manual

Introduction

Hydrogen shutdown

Hydrogen gas may be used as a carrier or as fuel for some detectors.

When mixed with air, hydrogen can form explosive mixtures.

The GC monitors inlet and auxiliary gas streams. If a stream shuts down

because it is unable to reach its flow or pressure setpoint and if that

stream is configured to use hydrogen, the GC assumes that a leak has

occurred and declares a hydrogen safety shutdown. The effects are:

•The offending channel and any associated channels (such as septum

purge) are set off.

•The split valves in the split/splitless and PTV inlets open.

•The oven (heater and fan) turns off.

•The small heated zones are turned off.

•An alarm tone sounds.

To recover from this state, fix the cause of the shutdown (tank valve

closed, serious leak, others). Turn the instrument off, then back on.

WARNING

The GC cannot always detect leaks in inlet and/or detector gas streams. For this

reason, it is vital that column fittings should always be either connected to a

column, or have a cap or plug installed. The H2streams must be configured for

hydrogen so that the GC is aware of hydrogen use.

Introduction

7890A GC Safety Manual 9

Dangers unique to GC/MSD operation

Hydrogen presents a number of dangers. Some are general, others are

unique to GC or GC/MSD operation. Dangers include, but are not limited

to:

•Combustion of leaking hydrogen.

•Combustion due to rapid expansion of hydrogen from a high- pressure

cylinder.

•Accumulation of hydrogen in the GC oven and subsequent combustion

(see your GC documentation and the label on the top edge of the GC

oven door).

•Accumulation of hydrogen in the MSD and subsequent combustion.

Hydrogen accumulation in a GC/MSD

All users should be aware of the mechanisms by which hydrogen can

accumulate (Table 1) and know what precautions to take if they know or

suspect that hydrogen has accumulated. Note that these mechanisms apply

to all mass spectrometers, including the GC/MSD.

WARNING

The GC/MSD cannot always detect leaks in inlet and/or detector gas streams. For

this reason, it is vital that column fittings should always be either connected to a

column, or have a cap or plug installed. The H2streams must be configured for

hydrogen so that the GC is aware of hydrogen use.

Table 1 Potential hydrogen accumulation mechanisms in GC/MSD

Mechanism Results

Mass spectrometer turned off A mass spectrometer can be shut down

deliberately. It can also be shut down accidentally

by an internal or external failure. A mass

spectrometer shutdown does not shut off the flow

of carrier gas. As a result, hydrogen may slowly

accumulate in the mass spectrometer.

10 7890A GC Safety Manual

Introduction

Mass spectrometer automated isolation

valves closed

Some mass spectrometers are equipped with

automated diffusion pump isolation valves. In these

instruments, deliberate operator action or various

failures can cause the isolation valves to close.

Isolation valve closure does not shut off the flow of

carrier gas. As a result, hydrogen may slowly

accumulate in the mass spectrometer.

Mass spectrometer manual isolation

valves closed

Some mass spectrometers are equipped with

manual diffusion pump isolation valves. In these

instruments, the operator can close the isolation

valves. Closing the isolation valves does not shut

off the flow of carrier gas. As a result, hydrogen

may slowly accumulate in the mass spectrometer.

GC off A GC can be shut down deliberately. It can also be

shut down accidentally by an internal or external

failure. Different GCs react in different ways. If a

7890A GC equipped with Electronic Pressure

Control (EPC) is shut off, the EPC stops the flow of

carrier gas. If the carrier flow is not under EPC

control, the flow increases to its maximum. This

flow may be more than some mass spectrometers

can pump away, resulting in the accumulation of

hydrogen in the mass spectrometer. If the mass

spectrometer is shut off at the same time, the

accumulation can be fairly rapid.

Power failure If the power fails, both the GC and mass

spectrometer shut down. The carrier gas, however,

is not necessarily shut down. As described

previously, in some GCs a power failure may cause

the carrier gas flow to be set to maximum. As a

result, hydrogen may accumulate in the mass

spectrometer.

Table 1 Potential hydrogen accumulation mechanisms in GC/MSD (continued)

Mechanism Results

Otros manuales para 7890A

Tabla de contenidos

Otros manuales de Equipo de laboratorio de Agilent Technologies

Agilent Technologies

Agilent Technologies Cary 8454 Manual de usuario

Agilent Technologies

Agilent Technologies 1260 Infinity II Manual de usuario

Agilent Technologies

Agilent Technologies 1200 Infinity Series Manual de usuario

Agilent Technologies

Agilent Technologies Bravo Guía de configuración

Agilent Technologies

Agilent Technologies G7166A Manual de usuario

Agilent Technologies

Agilent Technologies G1701EA Manual de usuario

Agilent Technologies

Agilent Technologies Agilent 7700 Series ICP-MS Instrucciones de funcionamiento

Agilent Technologies

Agilent Technologies G1701EA Manual de usuario

Agilent Technologies

Agilent Technologies ZORBAX RRHT Series Manual de usuario

Agilent Technologies

Agilent Technologies MX3000P Guía de seguridad

Agilent Technologies

Agilent Technologies 5100 ICP-OES Manual de usuario

Agilent Technologies

Agilent Technologies G1982-6700 Manual de usuario

Agilent Technologies

Agilent Technologies 1260 Infinity II Manual de usuario

Agilent Technologies

Agilent Technologies 1100 Series Manual de usuario

Agilent Technologies

Agilent Technologies 4150 TapeStation system Guía del usuario

Agilent Technologies

Agilent Technologies PlateLoc Manual de usuario

Agilent Technologies

Agilent Technologies Enhancer Cell Manual de usuario

Agilent Technologies

Agilent Technologies 6890 Series Manual de usuario

Agilent Technologies

Agilent Technologies InfinityLab LC Companion Manual de instrucciones

Agilent Technologies

Agilent Technologies 1200 series Manual de usuario

Agilent Technologies

Agilent Technologies 1290 Infinity II 2D-LC Solution Manual de usuario

Agilent Technologies

Agilent Technologies 6850 Series II Manual de instrucciones

Agilent Technologies

Agilent Technologies G2747A Manual de usuario

Agilent Technologies

Agilent Technologies SIPS 10 Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario

Yamato

Yamato BM510 Manual de usuario
