EDGE Industrial Router

ER75i v2

USER’S MANUAL

USED SYMBOLS

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

cellularsales@advantech-bb.com.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Manual Rev. 1 released in CZ, July 25, 2016

CONTENTS

Contents

1 Safety Instruction 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 8

5.3.1 Basic versions ................................ 8

5.3.2 Full version .................................. 8

5.4 Basic dimensions of the router box ......................... 9

5.4.1 Plastic box .................................. 9

5.4.2 Metal box ................................... 9

5.5 Mounting recommendations ............................. 10

5.6 Removing from the DIN rail ............................. 12

5.7 Description of the front panel ............................ 13

5.7.1 Status indication ............................... 14

5.7.2 Power connector PWR ............................ 15

5.7.3 Antenna connector ANT (and AUX) ..................... 16

5.7.4 SIM card reader ............................... 17

5.7.5 Ethernet Port ETH .............................. 18

5.7.6 PORT1 .................................... 19

5.7.7 PORT2 .................................... 19

5.7.8 USB Port ................................... 20

5.7.9 I/O Port .................................... 20

5.7.10 Reset ..................................... 22

6 First Use 23

6.1 Connecting the router before ﬁrst use ....................... 23

6.2 Start .......................................... 24

6.3 Conﬁguration ..................................... 24

6.3.1 Conﬁguration over web browser ....................... 24

6.3.2 Conﬁguration over Telnet .......................... 25

7 Technical Parameters 26

CONTENTS

7.1 Basic parameters ................................... 26

7.2 Standards and regulations .............................. 26

7.3 Technical parameters of module .......................... 27

7.4 Technical parameters of processor ......................... 27

7.5 Technical parameters of I/O port .......................... 27

7.6 Technical parameters of expansion port ...................... 27

8 Recommended Literature 28

9 Troubleshooting 29

9.1 FAQ .......................................... 29

10 Customers Support 31

iii

LIST OF FIGURES

List of Figures

1 Contents of package ................................. 5

2 Front panel ER75i v2B ................................ 6

3 Front panel ER75i v2F ................................ 6

4 Front panel ER75i v2F with WiFi .......................... 6

5 Front panel ER75i v2B SL .............................. 6

6 Front panel ER75i v2F SL .............................. 6

7 Front panel ER75i v2F SL with WiFi ........................ 6

8 Label ER75i v2B ................................... 7

9 Label ER75i v2B SL ................................. 7

10 Label ER75i v2F ................................... 7

11 Label ER75i v2F SL ................................. 7

12 Basic dimensions of plastic box (bottom and front view) ............. 9

13 Basic dimensions of metal box (bottom and front view) .............. 9

14 Space around antennas (plastic) .......................... 10

15 Space around antennas (metal) ........................... 10

16 Cable routing (plastic) ................................ 11

17 Cable routing (metal) ................................. 11

18 Space in front of connectors (plastic) ........................ 11

19 Space in front of connectors (metal) ........................ 11

20 Default position of DIN holder ............................ 12

21 Removing from the DIN rail ............................. 12

22 Front panel ER75i v2F ................................ 13

23 Power connector ................................... 15

24 Connection of power supply ............................. 15

25 Connecting of the antenna .............................. 16

26 Ejected SIM holder .................................. 17

27 Ethernet connector .................................. 18

28 Connection of ethernet cable ............................ 18

29 PORT1 cable connection .............................. 19

30 PORT2 cable connection .............................. 20

31 USB connector .................................... 20

32 I/O connector ..................................... 21

33 Connection of I/O cable ............................... 21

34 Connection of input and output to the router .................... 21

35 Router reset ...................................... 22

36 Router connection .................................. 23

37 Entering the IP address of the router ........................ 24

38 Entering login information .............................. 24

39 Router web interface ................................. 25

LIST OF TABLES

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Ordering codes for Basic versions ......................... 8

4 Ordering codes of full version ............................ 8

5 Front panel description ................................ 13

6 Status indication ................................... 14

7 Connection of power connector ........................... 15

8 Connection of Ethernet connector .......................... 18

9 Connection of USB connector ............................ 20

10 Connection of I/O port ................................ 20

11 Description of reset and restart router ....................... 22

12 Basic parameters ................................... 26

13 Standards and regulations .............................. 26

14 Technical parameters of module .......................... 27

15 Technical parameters of processor ......................... 27

16 Technical parameters of I/O port .......................... 27

1. SAFETY INSTRUCTION

1. Safety Instruction

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling of the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•The router should not be used in locations where ﬂammable and explosive materials

are present, including gas stations, chemical plants, or locations in which explosives

are used. We remind the users of the duty to observe the restrictions concerning the

utilization of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router in a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension

or cancellation of telephone services for the respective client, or, it may result in legal

sanctions; it may also result in both eventualities.

•When using the router in the close proximity of personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when in the close proximity of TV sets, radio receivers

or personal computers.

•It is recommended that you should create an appropriate copy or backup of all the im-

portant settings that are stored in the memory of the device.

2. WEEE DIRECTIVE

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been

introduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques to minimize the impact on the environment. This product contains high

quality materials and components which can be recycled. At the end of it’s life this product

MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-

tions of your supplier for disposal information.

3. ROUTER DESCRIPTION

3. Router Description

EDGE industrial router ER75i v2 is used to wirelessly connect various equipments and de-

vices via Ethernet interface 10/100 to the Internet or intranet. Thanks to high security level and

wide coverage of GPRS/EDGE technology provided by mobile phone operators, it is mostly

used in industrial applications, for remote maintenance and service of machines, or for data

transfer from solar or wind power plants. Other beneﬁts and advantages includes high mod-

ularity – the router offers option to connect various user devices via Ethernet 10/100, RS232,

RS485, RS422, MBUS or I/O.

As a standard, this industrial router is equipped with one Ethernet 10/100, one USB Host

port, one binary input/output (I/O) port and one SIM card. To save and backup communica-

tion data a version with two SIM cards is available. The wide range of interface options of the

router further expands expansion Port1 and Port2, which are selected by the customer. For

Port1 are available: Ethernet port 10/100, serial interface ports RS232, RS485, RS422, MBUS

or inputs/outputs (I/O – CNT). Port2 may be equipped with serial interfaces RS232, RS485,

RS422, MBUS, wireless interfaces WIFI or WMBUS, SDH expansion port or inputs/outputs

(I/O – CNT). Both of ports can be ﬁtted with internal switch (exp. port SWITCH). This wire-

less router is supplied either in a plastic or metal casing, based on the requirements of the

customer.

Conﬁguration is done via web interface protected by password. EDGE industrial router

supports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure

safe communication. Web interface provides detail statistics about the wireless router activi-

ties, signal strength, detailed log, etc. Router supports functions: DHCP, NAT, NAT-T, DynDNS,

NTP, VRRP, control by SMS and many other functions.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature – in case of connection losses,

or hardware watchdog which monitors the status of the router. With the help of a special

window (start up script window) you may insert Linux scripts for various actions. For some

applications the key option to create several different conﬁgurations for one EDGE router, the

so-called proﬁles (maximum of 4), and the option to switch between them (for example via

SMS, binary input status, etc.) is essential. Cellular routers may automatically upgrade con-

ﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many routers in one

time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers or communication VPN server Digicluster.

Examples of possible applications

•mobile ofﬁce

•ﬂeet management

•security system

•telematic

•telemetric

•remote monitoring

•vending and dispatcher machines

4. CONTENTS OF PACKAGE

4. Contents of Package

Basic delivered set of router includes:

•router,

•power supply,

•crossover UTP cable,

•up to two external antennas,

•clip for the DIN rail,

•paper start guide.

Figure 1: Contents of package

Temperature range for power supply is reduced to 0 ◦C to +40 ◦C!

As optional accessories can also be supplied the following expansion ports (one for Basic

version or two for Full version):

•RS232, RS485/422, MBUS, ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH.

•Separation columns for mounting expansion boards are included.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Advantech

Advantech

Advantech B+B SmartWorx SmartStart Guía

Advantech

Advantech EKI-7526I Manual de usuario

Advantech

Advantech B+B SmartWorx SE416 Manual de usuario

Advantech

Advantech ICR-2734 Manual de usuario

Advantech

Advantech ICR-2041 Manual de usuario

Advantech

Advantech ICR-2631 Manual de usuario

Advantech

Advantech B+B SmartWorx LR77 v2 Hoja de instrucciones

Advantech

Advantech Bivias v2 Manual de usuario

Advantech

Advantech ICR-3831 Guía

Advantech

Advantech SmartFlex SR305 Manual de usuario

Advantech

Advantech CR10 v2 Manual de usuario

Advantech

Advantech ICR-2031 Guía

Advantech

Advantech BB-ABDN-ER-IN5010 Manual de usuario

Advantech

Advantech SmartStart SL304 Manual de usuario

Advantech

Advantech ICR-2531 Manual de usuario

Advantech

Advantech ICR-2436 Manual de usuario

Advantech

Advantech MIC-3666 Manual de usuario

Advantech

Advantech EDGE ER75i v2 Manual de usuario

Advantech

Advantech EKI-2726FHPI Series Manual de instalación y operación

Advantech

Advantech UR5i v2 Libratum Instrucciones de instalación y funcionamiento

Advantech

Advantech EKI-7626C Manual de usuario

Advantech

Advantech ICR-2734P Manual de usuario

Advantech

Advantech SmartStart Series Guía

Advantech

Advantech ICR-2437 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
