Adam Equipment LHS Series Manual de usuario

AdamEquipment



LHS/LHSaSERIES



Softwareversion1.2



1.0 CONTENTS

P.N.7.00.6.6.0200,RevisionC1,November2017



1.0 CONTENTS .......................................................................................................... 1

2.0 INTRODUCTION ................................................................................................... 2

2.1 FEATURES ....................................................................................................... 2

2.2 TECHNICAL SPECIFICATIONS ....................................................................... 3

2.3 SAFETY NOTICE .............................................................................................. 4

2.4 KEY AND PANEL DESCRIPTION ..................................................................... 4

2.5 DISPLAY INDICATIONS WITH LED ................................................................. 5

3.0 OPERATION ......................................................................................................... 5

3.1 SAFETY INSTRUCTIONS ................................................................................. 5

3.2 BATTERY OPERATION .................................................................................... 6

3.3 BASIC OPERATIONS ....................................................................................... 6

3.4 REMOTE CONTROL UNIT ............................................................................... 8

3.5 USER PARAMETERS ....................................................................................... 8

4.0 CALIBRATION ...................................................................................................... 9

5.0 PARTS LIST ....................................................................................................... 10

WARRANTY INFORMATION ....................................................................................... 12



2.0INTRODUCTION

2.1 FEATURES



TheLHS/LHSaSeriesarearangeofheavy‐dutylowercapacitycranescales

Themainfeaturesinclude:

 EasyOperation&Ruggedconstruction

 25mmbrightredLEDdisplayenablingagoodviewingangle.

 360degreerotarysafetyhookandsupportringdesign

 Overloadsafetyupto125%ofmodelcapacity

 Selectableweighingunitsofkg,LbsandNewtons(Newtonsnotavailablefor“a”

models)

 StandardandPeakHoldfeature

 Internalrechargeablebatteryfittedasstandard

 Autopoweroffafter30minutesofnonuse

 6Vdc600mabatterycharger

 StrongDiecastAlluminiumhousing

 Infraredremotecontrol



2.2 TECHNICALSPECIFICATIONS



ModelNo Capacity Division ModelNo Capacity Division

LHS‐500 500kg 0.1kg LHS‐1000a 1000lb/500kg 0.2lb/0.1kg

LHS‐1500 1500kg 0.2kg LHS‐3000a 3000lb/1500kg 0.5lb/0.2kg

LHS‐2000 2000kg 0.5kg LHS‐ 4000a 4000lb/2000kg 1lb/0.5kg



2.3 SAFETYNOTICE



ThelimitstatedbelowistheUltimateOverloadLimitsofthescales.

AdamEquipmentCo.Ltd.Itsdirectors,ownersandaffiliatedcompaniesandorganisationscannot

beheldliableforanyresultingdamageorinjurysustainedasaresultofthemachinesbeingusedin

excessoftheirstatedcapacitiesorultimateoverloadlimits.



ModelNo. LHS500/1000a LHS1500/3000a LHS2000/4000a

Max

capacity  500kg/1000lb 1500kg/3000lb 2000kg/4000lb

Overload

capacity 625kg/1250lb 1875kg/3750lb 2500kg/5000lb

NOTICE:

Donotusethescalesifanypartsarebentorlooseorshowsignsofdamageorwear.Refertothe

usermanual.

2.4 KEYANDPANELDESCRIPTION







[ON/OFF] Thepowerswitch islocatedontherearhousing.Usethiskeytoturn

thescaleONandOFF.

[Zero] Pressthe[Zero] keytoreturnthereadingtozero.

[Unit] Press the [Unit] key to change the weighing unit being displayed

betweenKg,LbsandNewtons(Newtonsnotavailablefor“a”models)

[Hold]

Usethiskeytoactivate standard Hold.WhenpressedtheHold LEDwill

lightatthetopleftsideofthedisplayandthereadingonthedisplay

will lock and flash. Press the [Hold] key again to cancel the [Hold]

function.

*WhenPeakholdisselectedfromtheparametersectionthepressof

theHoldkeywillactivatePeakHold.TheHoldLEDwillflashandthe

display will also flash and lock showing the maximum weight

registeredofasingleweighingprocess.

Pressthe[Hold]keyagaintocancelthe[Hold]function.



2.5 DISPLAYINDICATIONSWITHLED

KglbN TheLEDwilllightupintheweighingunitthatisbeingusedto

indicatewhentheweightisstable.

Hold HoldIndicator

3.0 OPERATION

3.1 SAFETYINSTRUCTIONS

ReadthismanualcarefullybeforeyouoperatetheSHSCraneScale.

 UnpacktheCraneScalecarefullyfromthepackaging.

 Attachittoyourhoistorequivalentexistingequipmentsecurelyatthegroundlevel

tothesupportringintheuprightposition.Makesurethattheequipmenttowhich

thescaleisattachedisinpropercondition.Theoperatorshouldbetrainedforits

safeoperation.

 Carryoutregularvisualinspectionforanydamageorwearandtearonparts.The

splitpinsinparticularatthehookandeyebolts,aswellastheinnerwallofthehook

andalljointsshouldbecheckedregularly.Ifanydamageorwearhastakenplace,

stopusingthescaleandreplacetheparts.

 Doallinspectionandmaintenanceworkwhenthescaleisnotinuse.

 Donotexposethescaletoextremetemperatures.Theoperatingtemperaturerange

is0°Cto40°C.

 Securethesampletobeweighedinthehookofthescale.Ensurethatthesprung

SafetyLeverreturnstoitsrestingpositionwhichpreventsthesamplefromslipping

outofthehook.

 DonotexceedthemaximumcapacityoftheScale.

 Cleanandprotectyourscaleafteruse.

OverloadWarning

Pleasedonotaddanyitemthatexceedsthemaximumcapacityofthescale.Whenthedisplay

shows”-----”removetheitemtoavoiddamagetotheloadcellandscale.

3.2 BATTERYOPERATION



 The rechargeable battery will operate continuously for between 20 and 30 hours

beforerequiringrecharging.

 Tochargethebattery,plugthechargerunitintothesocketasmarkedontherearof

thescale.PlugthechargerintothemainspowersupplyandwaituntiltheLEDonthe

chargershowsgreen.Thebatteryisnowfullycharged.

 Chargingtimeforacompletelydischargedbatteryisapproximately16hours.Afull

batterypackisrecommendedtokeepthescalecontinuouslyoperational.

 Onlyusethechargerassuppliedwiththeunit.

 The scale will automatically power down after 30 minutes of nonusetofurther

protectthebattery.

 To replace the battery, turn the locking screw on the battery cover 90 degrees

clockwiseandliftopenthecover.Disconnectandremovetheoldbatteryandreplace

withanewone.

 Contactyourdealerforareplacementbattery.

BASICOPERATIONS

Poweronandoff

Pressthe[ON/OFF]buttontoturnthescaleonoroff.Thedisplayonthescalewillshowthe

modelcapacitythencountdownfrom9to0beforedisplayingzeroweight.



Zerothescale

Pressthe[Zero]keysothatthedisplayshowszero.



ChangetheweighingUnit

Pressthe[Unit]keytochangetheweighingunit



StandardHold(setting1)

Whenthereadingmaynotbeperfectlystableoryoucannotviewareadingeasilyyoucanpress

the[Hold]keytolockit.Thereadingwillbelockedandalsoflashatthepointyoupressthe

[Hold]buttonenablingyoutoviewitwhenyoucan.TheHoldLEDwillalsolightupandonce

youhavenotedthereadingapressofthe[Hold]keywillreturnthescaletothenormalweighing

mode.



PeakHold(setting0)

PeakHoldisthehighestweightreadingregisteredbythescalewhenaweighingtakesplace.

Pressthe[Hold]keywhenthedisplayisatzeroandtheHoldLEDwillflashwhichdenotesPeak

Holdhasbeenactivated.Whenweight/forceisappliedtothescalethedisplaywillalsoflash

andlockthehighestrecordedweightofthatweighingprocess.ThisvalueandtheHoldLEDwill

remainflashingonthedisplayuntilthe[Hold]keyispressedagainatwhichpointthescalewill

returntonormalweighingmodedisplayingthecurrentweightonthescale.

Press[Hold]againtoperformanotherPeakHoldweighingatanytime.





3.3 REMOTECONTROLUNIT



TheremotecontrolworksviainfraredandcanbeusedtooperatetheLHSfromlongdistances.

Itoperatesusing2xAAAbatteriesandthesecanbeexchangedbyunclippingacoverontherear

oftheremotecontrolunit.

3.5 USERPARAMETERS

FiveUSERparametersareontheSHS,toaccessthesepowerupthescaleandwhilstthedisplay

iscountingdownpressandthenreleasethe[Unit]button.Thedisplaywillshow00000.Usethe

[Hold]and[Unit]buttonstoenterthecode11111andthenpress[Zero].bEE1willbedisplayed.

Press the [Hold] button to change the setting and the [Zero] button to move to the next

parameter.



PARAMETERSETTINGTABLE

FUNCTION DESCRIPTION DEFAULT

BEE Setsbuzzer

0:Disable1:Enable 1

HODSetstheHoldfunction

0:Peak1:Standard

1

STBSetstheStablefunction

0:Disable1:Enable

1

CHT

Setsweighingunitonpowerup

0:kg1:Lb’s

2:Newtons(Newtonsnotavailablefor“a”

models)

0

YES Setssave:

0:Notsaved1:Savenewsettings

0



4.0CALIBRATION



 Pressthe[Zero]keyandpowerupthescaleusingtheon/offbutton.

 Release the [Zero] key and the display will show “SPAN”. Make sure the hook is

emptyunlessyouintendtouseanychains,slingsetctoholdthecalibrationmass.

Addanyitemssuchasthesetothehookbeforecontinuing.

 Press the [Zero] button and the display will show “SET” then “00000” when the

readingatzeroisstable.Thiscompletesthezerocalibration.

 Following zero calibrationthe valueof the massbeing used to calibratethescale

shouldbeentered.Usethe[Hold]buttontoincrementtherighthanddigit,andthe

[Unit]buttontomovethisdigittotheleft.Proceedbyenteringanumberforthenext

digit if required, until the value of your chosen calibration weight is displayed

correctly.

 Loadthismassontothehookandwhenthescaleisstablepressthe[Zero]key.The

displayshows‘HOLD’.

 After a few seconds, the calibration is complete and the scale returns to normal

weighingshowingthevalueofthecalibrationmassasused.



**TocalibrateinLbsmakesurethatthescaleisLbsmodebeforecommencing,tocalibrate

inKgmakesurethescaleisinKgmodebeforecommencing.


