Adam Equipment 103 Manual de usuario

COMPACT BALANCES

BALANCES COMPACTES

KOMPAKTWAAGEN

Models / Modèles / Modelle

103, 202, 402, 802, 301, 501, 1201, 2001, 4001, 6000

rev C1 18/04/2012

English

1 INSTALLATION 1

2 SPECIFICATIONS 4

3 DISPLAY and KEYPAD 5

4 OPERATION 6

5 PARAMETER SETTINGS 9

6 SIMPLE CALIBRATION 13

7 COMMUNICATIONS 14

8 ERROR MESSAGES 16

Français

9 INSTALLATION 17

10 CARACTERISTIQUES 20

11 ECRAN et CLAVIER 21

12 FONCTIONNEMENT 22

13 PARAMETRES DE REGLAGE 25

14 CALIBRAGE SIMPLE 30

15 COMMUNICATIONS 31

16 MESSAGES D’ERREUR 33

Deutsch

17 INSTALLATION 35

18 TECHNISCHE DATEN 38

19 ANZEIGE und TASTATUR39

20 BETRIEB 40

21 PARAMETEREINSTELLUNGEN 43

22 EINFACHE KALIBRIERUNG 47

23 ANSCHLÜSSE 48

24 FEHLERMELDUNGEN 50

English

1 INSTALLATION

1) Remove the balance, draft shield, top pan,AC adapter and pan support

from the packaging

2) Remove the shipping protection screw and transit disc from the top of the

balance and place the plastic top pan support on the balance. Do not use

excessive force when removing and installing the screw.

3) Gently place the plastic pan support into the receptacle and secure with the

supplied screw. Do not over-tighten the screw. It should be finger tight only.

Put the Stainless steel pan on top of the pan support

4) Place the draft shield on top of the balance, the location notches in the

breeze shield should align with the cut outs on the balance. For optimum

performance the balance should be used with the draft shield (if provided).

5) Place the balance onto a firm surface and adjust it to be level using the rear

feet before use,

English

1.1.1 LOCATING AND PROTECTING YOUR BALANCE

In order to keep your balance functioning at its best we suggest that you do the following:

Avoid extremes of temperature. Do not place in direct sunlight or near

air conditioning vents.

Make sure the balance is located on a strong table and free from

vibration.

Avoid unstable power sources. Do not use near large users of

electricity such as welding equipment or large motors. Do not let the

balance battery go flat – if you are not using it for a long time you should

charge the battery up periodically to make sure the battery does not lose its

charge.

Keep free from vibration. Do not place near heavy or vibrating

machinery.

Avoid high humidity that might cause condensation. Keep away from

direct contact with water. Do not spray or immerse the balance in water.

Do not place near open windows, air-conditioning vents or fans that

may cause a draft and unstable readings.

Keep the balance clean. Do not stack material on the balance / balance

pan when it is not in use. The Compact balance has a stacking feature for

stacking more than one unit on top of each other which does not apply

weight to the pan. For more details on this see the section on storing.

English

1.1.2 STORING WHEN NOT IN USE

*You can store them easily on top of each other to save space and protect them from damage.

Without Shield With Shield

*Only applies to 120mm top pan versions

English

2 SPECIFICATIONS

Model 103 202 402 802 301

Capacity 100g 200g 400g 800g 300g

Readability 0.001g 0.01g 0.01g 0.01g 0.1g

Resolution 1:100000 1:20000 1:40000 1:80000 1:3000

Repeatability +/- 0.002g 0.02g 0.02g 0.02g 0.1g

Linearity+/- 0.003g 0.02g 0.02g 0.03g 0.1g

Units g / ct / GN / N / dr / Lb / oZ / oZt / tl t / tl H / tl S /CUS

Model 501 1201 2001 4001 6000

Capacity 500g 1200g 2000g 4000g 6000g

Readability 0.1g 0.1g 0.1g 0.1g 1g

Resolution 1:5000 1:12000 1:20000 1:40000 1:6000

Repeatability +/- 0.1g 0.1g 0.2g 0.2g 1g

Linearity+/- 0.2g 0.2g 0.2g 0.2g 2g

Eccentric loading 0.2g 0.2g 0.2g 0.2g 2g

Units g / ct / GN / N / dr / Lb / oZ / oZt / tl t / tl H / tl S /CUS

Common Specifications

Interface RS-232 bi directional

Stabilization time 3s

Operating temperature 0°C - 40°C / 32°F - 104°F

Power supply 12VAC @ 150 ma (12VDC @ 800ma with internal

battery kit option)

Calibration Automatic external

Display 18mm 6 digits LCD

Housing ABS

Size without breeze shield 178 x 257 x 84mm (7” x 10.1” x 3.3”)

N.W. 1.1 kg (2.4 lb.)

English

3 DISPLAY and KEYPAD

3.1.1 Display

3.1.2 Keypad

KEY FUNCTION

ON/OFF TO POWER UP BALANCE

TARE/ZERO

TO RE ZERO OR DEDUCT WEIGHT OF EMPTY CONTAINER

SMPL

(sample) TO ENTER AND OPERATE COUNTING MODE

UNIT TO SELECT THE REQUIRED WEIGHING UNIT

(percent) TO ENTER AND OPERATE PERCENTAGE WEIGHING MODE

PRINT TO PRINT THE DISPLAYED READING WHEN CONNECTED TO

A COMPUTER OR PRINTER

Low battery indicator

Zero

Stable

Capacity tracker Weighing digits

Percentage symbol

Hold symbol

Net symbol

Units symbol

English

4 OPERATION

4.1.1 Zero/Tare

•To zero the balance, press the [Tare/Zero] key and the reading will

show zero, the symbol “>O<” will be displayed

•Put a container on the pan and the display will show its weight.

•Press [Tare/Zero] to tare the weight of the container from the balance,

the display will now show zero and also display the zero and NET

symbol.

•Put a sample into the container and the display will show the net weight

of the sample.

•Remove the whole container, the display will show a negative value

which is the weight of the container,

•Press the [Tare/Zero] to zero the reading and the display shows zero

and the NET symbol will turn OFF

4.1.2 Weighing

•After zeroing the reading place a sample weight onto the pan and the

display will show the weight of sample.

•The capacity tracker bar will indicate the percentage of the sample on

the pan against capacity of the balance. When the reading is stable, the

display will show the stable symbol.

•Users can select different weighing units by pressing the [Unit] key. The

reading will change according to the unit selected. Previous recorded

accumulated readings will be cleared when a new unit is selected.

•Units available:

g / ct / GN / N / dr / Lb / oZ / oZt / tl t / tl H / tl S /CUS.

The

unit “g” is always active; all other units can be selected to be active or

inactive.
