3D Systems CUBE Manual de usuario

3rd Generation

Personal 3D Printer

Quick Start Guide

See Inside for Use and Safety Information

The USB Mass Storage Device Contains the User Guide and

Quick Start Guide in other Languages

Congratulations on the purchase of your new Cube® 3D Printer! This Quick Start Guide has the use and

safety information you need to get started. Welcome to the 3D creative revolution – let the possibilities

begin!

If you have any questions, do not hesitate to reach us at cubifysupport@cubify.com.

This Quick Start Guide will give you basic instructions on how to get your Cube®3D Printer plugged in

and printing so you can start making your own creations.

For more detailed instructions, refer to the Cube®User Guide located on your USB

mass storage device.

CONTENTS

SAFETY ........................................................................................................................ 1

YOUR CUBE AT A GLANCE ........................................................................................ 2

UNPACK YOUR CUBE................................................................................................. 3

What’s Included .........................................................................................................................6

SETTING UP AND ACTIVATING YOUR CUBE ........................................................... 7

FINISHING YOUR CREATION ................................................................................... 23

Removing your Creation from the Print Pad.........................................................................23

Removing Supports and Rafts (If Required).........................................................................23

MAINTENANCE.......................................................................................................... 24

Print Pad Maintenance............................................................................................................24

Gap Verication .......................................................................................................................26

Manual Gap Adjustment .........................................................................................................28

SAFETY

HOT SURFACE HAZARD: A HOT SURFACE IS ACCESSIBLE IN THE VICINITY OF THIS

SIGN OR AT THE PRINT JET. AVOID CONTACT WITH THESE AREAS. HOT SURFACES

CAN CAUSE SEVERE BURNS.

Caution: Indicates something may happen that could cause loss of data,

damage to equipment, or could cause personal injury.

Caution: Indicates a pinch point hazard that could cause personal injury.

• Follow all safety rules in this section and observe all cautions and warnings in this guide.

• DO NOT modify any safety features or make modications to the Cube. Doing so is prohibited and

voids your warranty.

• Use of print materials other than 3D Systems print materials and genuine 3D Systems components

may void warranty.

• Adult supervision is required; observe children closely and intervene as necessary to prevent

potential safety problems and ensure the appropriate use of the Cube. Ensure small 3D prints are

not accessible to young children. These 3D prints are potential choking hazards for young children.

• DO NOT change a material cartridge during printing; doing so may damage the Cube.

WARNING: DO NOT TOUCH THE PRINT JETS DURING SETUP AND OPERATION. THE

PRINT JETS BECOME VERY HOT.

Caution: DO NOT unplug the Cube while the print jet is hot. Refer to the

touchscreen to determine when the print jets are cool enough.

CAUTION: Read and follow all instructions prior to setting up the printer.

To ensure safety, please exercise caution when operating your printer. Read and follow all safety

precautions as outlined in this document and the Cube User Guide. Be careful when operating your

Cube 3D Printer to ensure proper printing and be mindful of and avoid hot surfaces.

YOUR CUBE AT A GLANCE

Print Jets

Print Jet Tubes

Material Cartridges

Print Pad

Print Platform

Touchscreen Display

On / Off Button

USB Inlet Port (mass

storage device only)

Power Inlet

Refuse Bins with

Wipers

F G

H I

UNPACK YOUR CUBE

NOTE: Keep all packing materials for future transport. Shipping the printer without

the original packing materials may damage the printer and void the manufacturer’s

warranty.

1. Pull the clips (A) and remove them from the top of the

printer box and open the box.

2. Remove the upper foam support.

3. Remove the printer from the box and remove the

protective bag from the printer. Place the printer on a

solid, level base.

NOTE: When installing the printer there must

be a minimum of 8” (203 mm) of space on top

and on either side of the printer.

NOTE: There must be a minimum of 4” (102

mm) space in front of and behind the printer.

8” (203 mm)

Hand Clearance Around the Printer Build Plate Travel Area

4” (102 mm)

Back

Front

Front View Top View

4. Remove the top insert.

5. Fold the sides inward and remove the lower insert from

the printer.

6. Raise the print platform (A) and remove the spacer (B)

from the printer.

7. Open the accessories box and unpack the material cartridges, the USB mass storage device,

the power supply, cord, and the Cube Glue bottle.

8. Connect the power supply cable to the power inlet port

(A) on the printer.

NOTE: The cable should lock in place. To

remove the cable, pull back on the outer cable

end and carefully pull it out from the printer.

9. Connect the power cord to utility power and to the power

supply.

NOTE: Ensure the connection is secure.

10. Power on the printer by pressing the button (A) next to

the touchscreen display.

WHAT’S INCLUDED

1Depending on your printer model or conguration, up to two cartridges may be included.

NOTE: *The User Guide can be found on your USB mass storage device.

NOTE: The appearance of some components may vary.

Power Supply Power Cord Quick Start

Guide

Pliers Scraper

Removable Print Pad Cartridges1

Cube Cube Glue

Casing and its contents

USB Mass

Storage Device*

1.5 mm Allen

Wrench

Gap Gauge

Sandpaper

Casing

SETTING UP AND ACTIVATING YOUR CUBE

1. Select your language. Press the checkmark to conrm

your selection.

NOTE: The selected language will be indicated.

2. Enter a name for your printer. Scroll through the letters

by pressing the arrow symbols on each side of the

screen. Select the letters to spell out the name. Select

the checkmark to conrm your choice. Select SKIP

to bypass this step. You can name your printer at any

time by navigating to the System 1 screen and selecting

CUBE NAME.

NOTE: The abc button toggles between

lowercase letters, uppercase letters and

numerals.

3. Connect your printer to your network. Use the up or

down arrows to scroll to your network choice. Select

the desired network. Select SKIP to bypass this step.

You can connect to a wireless network at any time by

navigating to the Network screen and selecting WIFI.

NOTE: The printer can also connect to an ad

hoc network. Refer to the User Guide for more

information about connecting to an ad hoc

network.
