Zte MF65M Manual de usuario

MF65M

Quick Start Guide

Getting to Know Your Device

Appearance

The following gure is for your reference only.

1. LED Indicators

2. Power Key

3. WPS Key

4. Charging/micro-USB Jack

5. (U)SIM Card Slot

6. microSDHC™ Card Slot

NOTE:

microSDHC logo is a trademark of SD-3C, LLC.

Getting to Know Your Device

Indicators

When the device is powered on, the following icons may be

lighting. For a description of the icons, refer to the following

table.

Indicator Status Description

Network

Red solid

Error status. Not registered

to the mobile network, no

(U)SIM card inserted or no

network service available.

Green solid Registered to the mobile

network.

Green blinking

Connected to the mobile

network and data is being

transferred.

Wi-Fi

Blue solid Wi-Fi is active.

Blue blinking WPS is active.

off Wi-Fi is off or your device is

in sleep mode.

SMS Blue solid You have unread

messages.

Blue blinking You have new messages.

off No unread messages.

Battery

Red solid /

blinking

The battery is low. Please

charge the battery.

Green blinking

The battery is being

charged or in standby

mode.

Green solid The battery level is middle

or high.

off

Your device is not being

charged, or the battery is

not inserted.

Getting to Know Your Device

Connection Scenarios

The device can access the Internet in two ways and it

allows multiple clients to surf on the Internet at the same

time. The following gures are for your reference only.

• 3G Mode: A (U)SIM card can be used to access the

Internet.

• Internet Wi-Fi Mode: Your device can be connected to

a WLAN device (such as a hotspot device or wireless

router) through Wi-Fi to access the Internet. The WLAN

device must be already connected to the Internet.

Getting to Know Your Device

NOTE: Your device and the WLAN device must be in

different subnets.

Installing Your Device

1. Slide the back cover and remove it.

NOTE: Do not remove the cover rudely.

Getting to Know Your Device

2. Install a (U)SIM card to the (U)SIM card slot.

WARNING!

Your device does not support micro-SIM cards, nano-SIM

cards or any other non-standard SIM cards. To avoid dam-

age to the device, do not use those cards or any card hold-

ers.

Installing Your Device

3. Install the microSDHC card if necessary.

4. Install the battery.

Installing Your Device

5. Close the back cover.

Connecting to Your Device

Using Wi-Fi

1. Power on your device.

2. Make sure your computer or other client devices

have enabled Wi-Fi, and search for available wireless

networks.

NOTE: Refer to your Wi-Fi-enabled client device

manual for further details on how to search for wireless

networks. If you use a computer, you need to set your

computer to obtain an IP address automatically.

Installing Your Device

3. Select the Wi-Fi name (SSID) of your device, and click

Connect.

4. Enter the Wi-Fi password if necessary, and click OK.

NOTE:

Refer to the chapter Getting to Know the Wi-Fi SSID and

Password to get the default Wi-Fi SSID and password.

5. Wait until the client device is connected to your device

successfully.

Using a USB Cable

1. Connect a computer to your device with a USB cable.

2. Power on your device. The operating system detects

and identies new hardware, and automatically installs

the hardware.

NOTE: If the system does not automatically launch

installation, you can click the device installation icon in My

Computer to install the software.

3. Wait until the computer is connected to your device

successfully.

Connecting to Your Device
