Zte MF28B Manual de usuario

Inserting SIM Card

Open the protective cover of the SIM port shown below and insert the

SIM card.

Note: Please power off the MF28B router and remove the external

power adapter before removing or inserting the SIM card. If not, the

router or SIM card may be damaged.

Switching On Your Device

1. Turn the Power Switch on to get started.

Note: Do not put anything on the top of the router. Do not lay

routers overlapping each other when using.

2. Wait 2~3 minutes after turning the MF28B router on before you

use the service.

Note: If the Mobile Network indication LED (left most indicator)

is blinking constantly, try to move the router to another location.

The router takes 1~2 minutes to initialize, connect to the network

and obtain an IP address.

1

Power Switch

Appearance

SIM Port

LED Indicators

WPS ButtonUSB Port

Interface

Indicator Description

SIM Port Where the SIM card is inserted.

LED Indicators To indicate the status of the device.

USB Port To connect with an external storage device or

USB shared printer.

Interface

Contains RJ45 interfaces (LAN1/WAN, and

LAN2 ~ LAN4), power switch, reset switch,

and power socket.

WPS Button To activate Wi-Fi Protected Setup

authentication process.

2

Interface Description

1 LAN1/WAN For Ethernet connections or ADSL/cable

modem connection.

2 LAN2~LAN4 For Ethernet connections.

3 ON/OFF To turn the router ON or OFF.

4 Reset Switch To restore the router to the factory default

settings by holding for 7 seconds.

5 Power Socket To connect to the external power supply.

3

LED Indicator

Indicator State Description

1 Mobile Network

Blue Registered to LTE network

Green Registered to 4G network

OFF Not Registered

2 Mobile Network

connection

status

Always ON Mobile network connection

established

Blinking Mobile network connection is

establishing

OFF Mobile network connection not

established

3 Mobile Network

signal strength

Always ON Signal strength is very good or

good

Blinking Signal strength is weak

OFF No signal

4 Error Blinking

No SIM card inserted, PIN

enabled without entering correct

PIN code on Web UI

5 Wi-Fi

Always ON Wi-Fi connection established

Blinking Wi-Fi data transmission

OFF Wi-Fi is shut down

4

6 Power Always ON

Green--Once device initialized

and ready

Red-- Device is initializing

OFF Device is powered off

Connecting to the internet via Wi-Fi

1. Power on your device. It will take 2~3 minutes to initialize.

2. Scan for available wireless networks using the normal Wi-Fi

application of your Wi-Fi device.

3. Select the SSID of your MF28B router, and connect to it (The

default SSID and Wi-Fi password can be found on the label

found on the MF28B router box). Wait approximately 30 seconds

for the connection to establish.

Note: You can modify the SSID and password using the Web

GUI advanced conguration page.

Connecting to the internet via Ethernet Cable (RJ45)

1. Power on your device. It will take 2~3 minutes to initialize.

2. Connect the supplied Ethernet cable to a LAN port at the back of

the MF28B router.

3. Connect the other end of the Ethernet cable to your computer

and wait approximately 45 seconds for the connection to

establish.

5

6

Logging into the WebGUI (for optional device

conguration)

1. Establish a connection between the MF28B router and Wi-Fi

device.

2. Launch your web browser and enter the router address (Default

address: http://192.168.1.1).

Note: It is recommended that you use one of the following web

browsers: Internet Explorer (7.0 or later), Firefox (3.0 or later),

Opera (10.0 or later), Safari (4.0 or later) or Chrome (10.0 or

later).

3. When the login page appears as follows, input the password (The

default password is admin).

Please refer to your MF28B User Manual for conguration options

and instructions.
