3. Put both feet on the deck of the XA-750 and gently rotate the THROTTLE GRIP, on
the right side of the handlebars. The XA-750 will begin to move on its own power.
4. When finished riding or storing the XA-750, be sure to turn the key to the off position
and remove it to ensure safe storage or accidental start of the scooter.
**Your scooter has a variable speed hand throttle. You can control the speed of your
scooter by the amount of pressure you use when rotating the hand throttle. The more
you rotate, the faster you will go.
Forward/Reverse
Your XA-750 can go forward or reverse. Located on the left side of the of the
ATV body is an on/off switch. For normal forward movement, the switch
needs to be in the off position. To operate the ATV in reverse turn the switch
to the on position. When finished in reverse, simply turn the switch off.
Stopping/Braking
1. To brake, release the THROTTLE GRIP and depress the BRAKE LEVER (on the left
side of the handlebars. Depressing the brake will disengage power to the motor.
When the unit feels like it is loosing power or not accelerating to full speed, the scooter
is ready to be re-charged.
Headlight/Taillights and Turning Signals
Your XA-750 comes equipped with a headlight, taillight and turning signals. It also
comes with a horn. To operate these features, locate the switches on the left hand grip.
Braking System
The XA-750 uses a hydraulic brake system on the rear wheels. A hand brake lever on the
left side of the handlebar activates the braking system. This brake system requires no
maintenance or adjustments. Squeezing the hand brake lever with your left hand will
activate the brakes. Make sure to release the HAND THROTTLE GRIP when engaging
the brakes.
Practice braking on a smooth, dry surface to get used to the feel of the braking system.
Braking distance is affected by wet conditions and loose and uneven riding surfaces.
