Xtreme X-560 Manual de usuario

X-Treme TM Electric Scooters

Model: X-560

Product Handbook

(Photosmayvary)

PLEASE BE SAFE WHEN RIDING

ALWAYS WEAR A HELMET AND OBEY ALL LAWS!

Page1

IMPORTANT

BATTERY MAINTENANCE and

CHARGING INSTRUCTIONS

1. You MUST charge completely prior to initial use. (Follow

charging instructions in your Product Handbook)

2. Charge immediately after each use.

3. Charge before storage. You must charge every 30 days if not

in use.

4. Charge the unit for 6-8 hours or until both lights on charger turn

green.

5. DO NOT allow this unit to deep discharge the battery.

6. For safety purposes, DO NOT charge for over 24 hours.

7. Turn the unit OFF when not in use.

Failure to follow these INSTRUCTIONS will

VOID YOUR WARRANTY!

This PRODUCT IS NOT INTENDED FOR EXTREME or

OFF-ROAD Use! Please take care of your X-560!

DO NOT JUMP or ABUSE THIS PRODUCT!

DO NOT RIDE IN WET/ICY CONDITIONS!

Failure to follow these instructions will

VOID YOUR WARRANTY!

Page2

WARNING

This product does not conform to Federal Motor Vehicle Standards and is not

intended for operation on public streets, roads or highways. Serious injury can

result from the unsafe operations of this product. Operator can minimize these

risks by using certain safety equipment such as: safety helmet, goggles, gloves,

elbow and kneepads and appropriate footwear.

DO NOT operate this product in traffic, on wet, frozen, oily or unpaved surfaces o

under the influence of drugs and/or alcohol. Avoid uneven surfaces, potholes,

surface cracks and obstacles.

DO NOT use a water hose to clean this product. See Product Handbook for more

information.

This product is recommended for riders 12 YEARS OF AGE and older.

SAFETY

 Persons without excellent vision, balance, coordination, reflex, muscle and

bone strength and good decision-making capabilities should not use this

product.

 Minors without adult supervision should not use this product.

 Persons unwilling or unable to take responsibility for their own actions should

not use this product.

 The user of this product assumes ALL risks associated with its use. To

minimize these RISKS, the user must wear safety helmet, goggles, gloves,

elbow and kneepads and appropriate footwear.

 This product is ELECTRIC! DO NOT ride this product in wet conditions,

puddles or rainy weather.

IMPORTANT

PLEASE READ THIS BEFORE USING THIS PRODUCT

READ THIS FIRST!

Page3

SAFETY GUIDE

• The minimum recommended age for riding this scooter is 12 years old.

• To avoid damage to the motor and footplate, do not overload the scooter.

• Never ride with more than one person.

• Inspect your scooter thoroughly before each use for loose or missing parts.

• Avoid unintentional starts by turning the scooter off while not in use.

• To avoid the risk of a short circuit in the electrical parts, do not use your

X-Treme Electric scooter in the rain and never spray or wash off your scooter

with water.

• Do not place the battery near fire or heat.

• To avoid damage to the battery, do not use the charger if it has been damaged

in any way.

• Keep hands, face, feet and hair away from all moving parts.

• Do not touch the motor or wheels while they are rotating.

• Brakes are designed to control speed as well as stop the scooter. Practice

braking for proper slowing down and smooth stops.

• Maintain your X-Treme X-560 as recommended in this Product Handbook.

• Use only quality replacement parts as recommended by the manufacturer.

• Inspect the entire scooter prior to each use. Replace any part that is cracked,

chipped or damaged before use.

*NEVER ALLOW CHILDREN TO OPERATE THE SCOOTER WITHOUT ADULT

SUPERVISION.

*NEVER ATTEMPT TO OPERATE THE SCOOTER WHILE UNDER THE

INFLUENCE OF ALCOHOL.

If a situation arises that is not covered in the manual,

proceed with caution and use good judgment.

Contact your dealer or X-Treme (www.x-tremescooters.com/support/)

if you need further assistance

QUICK REFERENCE

SAFETY GUIDE

Page4

TABLE OF CONTENTS

IMPORTANT INFORMATION…………………………………….…2-3

QUICK REFERENCE………………………………………………….4

TABLE OF CONTENTS……………………………….……………….5

GETTING TO KNOW YOUR X-TREME X-560……………………..6

PACKING CONTENTS……………………………………………..….7

GETTING STARTED………………..………………….…………….7

ASSEMBLY………………………………………………………..7

FUSE INSTALLATION………………………….………………..8

CHARGING. ..……………………………………………………..8

RIDING/BRAKING………………………………………………..9

BRAKING SYSTEM………………………………………………9

ADJUSTING THE BRAKES………….…..………………..………..10

TIRES…………………………….………………………………….…10

MAINTENANCE………………………………………………………11

RECOMMENDED TOOLS……………………………………...11

ADJUSTING THE CHAIN………..………………………….….11

MAINTENANCE SCHEDULE………………………………….12

TROUBLESHOOTING GUIDE……………………………………..12

ADDITIONAL INFORMATION………………….…………………..13

GENERAL INFORMATION/TECH SUPPORT……………………14

Page5

GETTING TO KNOW YOUR X-TREME X-560

(Photo’s may vary)

Page6

PACKAGE CONTENTS

Your X-Treme X-560 comes with the following items in the box. Please locate

all of the following:

1. The X-Treme X-560 Scooter

2. Right & Left Side Fairings

3. 36V Battery Charger

4. Tool Kit & assorted nuts/bolts/washers

5. Seat & Seat Post

6. Trunk with Keys & mounting hardware

7. Trunk Rack & mounting nuts/bolts

8. Spare Fuse(s)

9. Product Handbook

10. Rear Tail Light

11. Footpad Mat

GETTING STARTED

Please read and understand these instructions and the OPERATING

PROCEDURES section, prior to starting or riding your X-560

ssembly

1. Carefully remove the X-560 from the box.

2. Slide the handlebars onto the fork. (Fig.

3. Locate the Handlebar Lock Pin, and

insert it into the side of the handlebar,

ensuring it feeds thru the fork bracket.

Secure the lock pin using the attached

bolt. (Fig. 2).

Slide the handlebar clamp up and over the

base of the handlebar. Tighten the clamp

ensuring the front wheel is in prope

alignment with the handlebars. (Fig. 3)

fter the handlebar is securely attached,

slide the black rubber boot over the

connection.

Fig. 3

Fig. 1

Fig. 2

Page7

1. Attach Throttle and Brake Handle Grips

by Inserting the handle grips into the

handlebar posts.

2. Attach Left & Right Side Fairings as shown

in figure 4.

3. Mount trunk/cargo rack

4. Mount the seat post to the bottom of the

seat, then insert seat post into the receive

and tighten the clamp

5. Install the rear taillight to the mounting

bracket being sure to attach the plug to

the scooter. (Fig. 6)

6. Install the enclosed 25amp glass fuse into

the fuse holder located on the right side o

your scooter.

Fuse Installation

Your scooter comes with a 25amp fuse that is

NOT installed at the factory.

1. Locate the 25amp glass fuse that came

with your scooter.

2. Locate the fuse holder on the right side o

the scooter

3. Remove the fuse holder cap and insert the

fuse into the cap first.

Then insert fuse/cap into fuse holder and gently

tighten. DO NOT OVER TIGHTEN THE CAP.

For more detailed assembly instructions go to:

http://www.x-tremescooters.com/electric_scoot

ers/x560/images/adobe/x-560-assembly-manu

al.pdf

Fig. 4

Fig. 5

Fig.6

Charging

Your scooter comes partially charged out of the carton. It is recommended

that you charge the unit for 6-8 hours prior to it’s first use. We also

recommend charging your scooter after each use and prior to storage.

WARNING: Do not allow your scooter to go into deep discharge, as this will

damage the batteries.

Page8

1. Open the charging socket cover located

on the left side of the scooter body.

(Fig. 7)

2. Locate your Battery Charger. (Fig. 8)

Find the charger socket end that has a

three-prong socket and plug it into the

scooter.

3. Next, plug the AC plug into a wall outlet.

When first plugged in, the charger has a

red light and green light that indicate the

charging process has begun. Once both

lights turn green, you may remove the

charger and close the safety cap.

Fig. 7

Fig. 8

Riding

1. Make sure that all of the exposed bolts and screws are tightened.

2. Raise the kickstand to its upright position.

3. Turn the Ignition key to the on position.

4. Gently rotate the THROTTLE GRIP, on the right side of the handlebars.

The X-560 will begin to move on its own power. Your scooter has a

variable speed hand throttle. You can control the speed of your scooter by

the amount of pressure you use when rotating the hand throttle. The more

you rotate, the faster you will go.

Stopping/Braking

To brake, release the THROTTLE GRIP and depress the BRAKE LEVER on

the left side of the handlebar. Depressing the brake will disengage power to

the motor. When the unit feels like it is loosing power or not accelerating to

full speed, the scooter is ready to be re-charged.

BRAKING SYSTEM

The X-560 uses a hub brake system on the front and rear wheel of the scooter

activated by a hand brake lever on the left & right side of the handlebar.

Make sure to release the HAND THROTTLE GRIP when engaging the brakes.

Practice braking on a smooth, dry surface to get used to the feel of the braking

system. Braking distance is affected by wet conditions and loose and uneven

riding surfaces.

Page9

Adjusting the Brakes

The Brakes on the X-560 should come fully adjusted from the factory.

However, it may be necessary to adjust the brakes from time to time.

To adjust brakes:

For brakes that are adjusted too tight:

1. Loosen the tension screw on the

left or right hand brake lever by

rotating it counter-clockwise until

the wheel spins freely. (Fig. 6)

For brakes that are adjusted too loose:

1. Tighten the tension screw on the

left or right hand brake lever by

rotating it clockwise until the wheel

has a slight drag. (Fig. 6)

For further adjustment, Locate the

adjustment screw on the front or rea

brake hub.

For brakes that are adjusted too tight:

1. Loosen the tension screw on the

brake hub by rotating it clockwise

until the wheel spins freely. (Fig. 7)

For brakes that are adjusted too loose:

1. Tighten the tension screw on the

brake hub by rotating i

counter-clockwise until the wheel

has a slight drag. (Fig. 7)

Fig. 6

Fig. 7

Squeaky Brakes

The brakes may squeak before they are broken in. This is normal and will not

affect the function or performance of the brakes. With continued use the

squeak should go away.

TIRES

The X-Treme X-560 uses 13” tires on the front and rear wheels. Tire wear will

differ based on rider weight, riding conditions and care. Replacement tires can

be obtained at your local X-Treme dealer, through motorcycle shops, or from

the X-Treme website at www.x-tremescooters.com

Tire Pressure

The tires must be inflated to a maximum of 36-40 P.S.I. It is also recommended

to use a tube additive like Slime, available from any motorcycle shop, to avoid

inconvenient punctures.

Page10

Tabla de contenidos

Otros manuales de Scooter de Xtreme

Xtreme

Xtreme XG-470 Manual de usuario

Xtreme

Xtreme XA-750 Manual de usuario

Xtreme

Xtreme XG-499 Manual de usuario

Xtreme

Xtreme XMB-320 Manual de usuario

Xtreme

Xtreme XB-300SLA Manual de usuario

Xtreme

Xtreme XM-3150 Guía de solución de problemas

Xtreme

Xtreme X-600 Manual de usuario

Xtreme

Xtreme X-500 Manual de usuario

Xtreme

Xtreme XB-420M Manual de usuario

Xtreme

Xtreme XR-302 Manual de usuario

Xtreme

Xtreme XM-3000 Guía de solución de problemas

Xtreme

Xtreme XB-300SLA Manual de usuario

Xtreme

Xtreme X-360 Manual de usuario

Xtreme

Xtreme XG-505 Manual de usuario

Xtreme

Xtreme XG-550 Manual de usuario

Xtreme

Xtreme XG-550 Manual de usuario

Xtreme

Xtreme X-400 Manual de usuario

Xtreme

Xtreme X-250 Manual de usuario

Xtreme

Xtreme XH-505 Manual de usuario

Xtreme

Xtreme XG-565 A-Blaze Signature Series Manual de usuario

Xtreme

Xtreme XMB-400 Manual de usuario

Xtreme

Xtreme X-010 Manual de usuario

Xtreme

Xtreme XB-700Li Manual de usuario

Xtreme

Xtreme XB-420M Manual de usuario

Manuales populares de Scooter de otras marcas

TEKTRO

TEKTRO CHEETAH Manual de usuario

Douglas

Douglas Vespa Sprint Guía de instalación

PLAYTIVE

PLAYTIVE AS-2448 Manual de usuario

Ebinger

Ebinger DONKEY XL Manual de usuario

Flyer

Flyer Mountain Guía del usuario

BackCountry eBikes

BackCountry eBikes Storm Manual de usuario

equipmed

equipmed FreeRoam II Manual de usuario

Yoto

Yoto Lion Manual de usuario

WESTHILL BIKES

WESTHILL BIKES LINK Manual de usuario

BAnff

BAnff eProdigy series Manual de usuario

Winther

Winther 475 Manual de usuario

Jetson

Jetson JBZL17 Manual de usuario

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manual de usuario

Carrera

Carrera impel Manual de usuario

Afikim

Afikim Superlight SL-3 Manual de usuario

CareCo

CareCo ZOOM Manual de usuario

Douglas

Douglas Vespa G.S. Manual de usuario

Gazelle

Gazelle with BOSCH System Manual de usuario
