Winmate Military Series Manual de usuario

15”/ 17”/ 19”/ 21.5”/ 23.8”/ 32”

Console Rack Panel PC

Intel® Core™ i5 -1135G7 2.4 GHz (turbo to 4.2 GHz)

Military Series

Model No. R15IT3S-MLA3FP

R17IT3S-MLA1FP

R19IT3S-MLA3FP

W22IT3S-MLA3FP

W24IT3S-MLA2FP

W32IT3S-MLA3FP

User Manual

Version 1.0

Document Part No. 91521110111I

Military Console Rack PCAP Panel PC User Manual

Contents

Preface............................................................................................................................................3

About This User Manual........................................................................................................6

Chapter 1: Introduction .................................................................................................................6

1.1 Overview.........................................................................................................................7

1.2 Product Features.............................................................................................................7

1.3 Package Contents...........................................................................................................8

1.4 Appearance.....................................................................................................................8

1.5 Connector Description.....................................................................................................9

1.6 Panel Controls...............................................................................................................10

1.6.1 Control Keys........................................................................................................10

1.6.2 LED Indicators.....................................................................................................10

1.7 Dimensions ...................................................................................................................11

Chapter 2: Installation .................................................................................................................14

2.1 Wiring Requirements.....................................................................................................14

2.2 Mounting the Device......................................................................................................15

2.2.1 Panel Mount........................................................................................................15

2.2.2 VESA Mount........................................................................................................16

2.3 Powering On .................................................................................................................17

2.3.1 Connecting to AC Input Power Source (Default) .................................................17

2.3.2 Connecting to DC Input Power Source (Optional)...............................................18

2.4 Connecting Other Devices ............................................................................................19

2.4.1 RS-232/422/485 Connector.................................................................................19

2.4.2 HDMI Connector..................................................................................................19

2.4.3 LAN1/ LAN2: Gigabit Ethernet.............................................................................20

2.4.4 Two USB 3.0 (Compliable with USB 2.0) ............................................................20

2.5 Turning On and Off Your Device...................................................................................20

2.6 How to Enable Watchdog..............................................................................................21

2.7 Using Recovery Wizard to Restore Computer...............................................................22

Chapter 3: BIOS Setup.................................................................................................................23

3.1 How and When to Use BIOS Setup...............................................................................23

3.2 BIOS Functions.............................................................................................................24

3.2.1 Main Menu...........................................................................................................24

3.2.2 Advanced ............................................................................................................25

3.2.3 Boot.....................................................................................................................37

3.2.4 Security ...............................................................................................................40

3.2.5 Power..................................................................................................................41

Preface

3.2.6 Exit ......................................................................................................................42

Chapter 4: Technical Support.....................................................................................................43

4.1 Software Developer Support .........................................................................................43

4.2 Problem Report Form....................................................................................................43

Appendix.......................................................................................................................................44

Appendix A: Technical Specifications..................................................................................44

Appendix B: Military Grade Compliance..............................................................................46

Appendix C: Maintenance...................................................................................................47

Appendix D: Serial Port Settings.........................................................................................48

Military Console Rack PCAP Panel PC User Manual

Preface

No part of this document may be reproduced, copied, translated, or transmitted in any form or by

any means, electronic or mechanical, for any purpose, without the prior written permission of the

original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective owners.

Disclaimer

We reserve the right to make changes, without notice, to any product, including circuits and/or

software described or contained in this manual in order to improve design and/or performance. We

assume no responsibility or liability for the use of the described product(s) conveys no license or

title under any patent, copyright, or masks work rights to these products, and make no

representations or warranties that these products are free from patent, copyright, or mask work

right infringement, unless otherwise specified. Applications that are described in this manual are

for illustration purposes only. We make no representation or guarantee that such application will

be suitable for the specified use without further testing or modification.

Warranty

Our warranty guarantees that each of its products will be free from material and workmanship

defects for a period of one year from the invoice date. If the customer discovers a defect, we will,

at his/her option, repair or replace the defective product at no charge to the customer, provide it is

returned during the warranty period of one year, with transportation charges prepaid. The returned

product must be properly packaged in its original packaging to obtain warranty service. If the serial

number and the product shipping data differ by over 30 days, the in-warranty service will be made

according to the shipping date. In the serial numbers the third and fourth two digits give the year of

manufacture, and the fifth digit means the month (e. g., with A for October, B for November and C

for December).

For example, the serial number 1W21Axxxxxxxx means October of year 2021.

Customer Service

We provide a service guide for any problem by the following steps: First, visit the website of our

distributor to find the update information about the product. Second, contact with your distributor,

sales representative, or our customer service center for technical support if you need additional

assistance.

You may need the following information ready before you call:

Product serial number

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers every business day. We are

always ready to give advice on application requirements or specific information on the installation

and operation of any of our products.

Preface

Federal Communications Commission Radio Frequency

Interface Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class "B" digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at him own expense.

European Union

This equipment is in conformity with the requirement of the following EU

legislations and harmonized standards. Product also complies with the

Council directions.

Electromagnetic Compatibility Directive (2014/30/EU)

EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

EN55032: 2012/AC:2013

EN61000-3-2:2014

EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

Military Console Rack PCAP Panel PC User Manual

Advisory Conventions

Four types of advisories are used throughout the user manual to provide helpful information or to

alert you to the potential for hardware damage or personal injury. These are Notes, Important,

Cautions, and Warnings. The following is an example of each type of advisory.

Note:

A note is used to emphasize helpful information

Important:

An important note indicates information that is important for you to know.

Caution A Caution alert indicates potential damage to hardware and explains how

to avoid the potential problem.

Attention Unealerted’ attention indique un dommage possible à l’équipement et

explique comment éviter le problem potentiel.

Warning! An Electrical Shock Warning indicates the potential harm from electrical

hazards and how to avoid the potential problem.

Avertissement! Un Avertissement de Choc Électriqueindique le potentiel de

chocssur des emplacements électriques et comment éviterces problèmes.

Earth Ground The Protective Conductor Terminal (Earth Ground) symbol

indicates the potential risk of serious electrical shock due to improper grounding.

Mise à la Terre Le symbole de Miseà Terre indique le risqué potential de choc

électrique grave à la terre incorrecte.

Safety Information

Warning! This monitor is equipped with Mini USB port, signals and power is

obtained from standard USB 2.0 or USB 3.0 port. Do not expose this unit in the rain

or moisture environment to damage the monitor.

Avertissement! Ce moniteur est équipé d'un port mini USB, les signaux et

l'alimentation sont obtenus à partir d'un port USB 2.0 ou USB 3.0 standard.

N'exposez pas cet appareil à la pluie ou à l'humidité pour endommager le moniteur.

Caution Do not touch the surface of the LCD panel. Pressure on the panel may

cause non-uniformity of color or disorientation of the liquid crystals.

Attention! Ne touchez pas la surface du panneau LCD. La pression sur le

panneau peut entraîner une non-uniformité de la couleur ou une désorientation des

cristaux liquides.

Chapter 1: Introduction

PRECAUTIONS

•Do not use the monitor near water.

•Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can

injure a person and cause serious damage to the appliance. Use only a cart or stand

recommended by the manufacturer or sold with the monitor. If you mount the monitor on a

wall or shelf, use a mounting kit approved by the manufacturer and follows the kit

instructions.

•The monitor should be operated with an USB cable with Mini USB B type connector on

monitor end and standard USB A type connector on the other end to PC or USB signal

source.

•Normally it is packed with monitor.

•Never spill liquids on the monitor.

•Do not attempt to service the monitor yourself; opening or removing covers can damage to

the monitor or panel. Please refer all servicing to qualified service personnel.

•For Wall mount adaptor, wall socket shall be installed near the equipment and shall be

easily accessible.

•

About This User Manual

This User Manual provides information about using the Military Console Rack Panel PC. The

documentation set provides information for specific user needs, and includes:

Military Console Rack Panel PC User Manual –contains detailed description on how to

use the display, its components and features.

Note:

Some pictures in this guide are samples and can differ from actual product.

Chapter 1: Introduction

This chapter gives you product overview, describes features and

hardware specification. You will find all accessories that come with the

display device in the packing list. Mechanical dimensions and drawings

included in this chapter.

Military Console Rack PCAP Panel PC User Manual

1.1 Overview

Congratulations on purchasing Winmate® Military Console Rack Panel PC. Winmate's military

series of console rack Panel PCs are durable PCs that have undergone rigorous testing to ensure

safety and performance that goes beyond standard military compliance. These PCs include MIL-

DTL-38999 type I connectors and are built to survive drops, shocks, liquid spills, vibrations, dust

and extreme temperatures; our specially designed military line of products have also been tested

for MIL-STD-810G environmental and MIL-STD 461F EMC standards. The rugged, high-resolution

display offers optimized visibility with optical bonding and easy-to-use OSD front panel controls.

The advanced computing platform enables faster searches and real-time positioning information,

providing rapid response capabilities that are incomparable to a standard PC.

1.2 Product Features

Military Console Rack PCAP Panel PC features:

15”/ 17”/ 19”/ 21.5”/ 23.8”/ 32” screen with PCAP touch

Intel® Core™ i5 1135G7 2.4 GHz (turbo to 4.2 GHz) Processor

AC 110~240 V Power input default

Anti-Corrosion Housing / Fanless

Built-in Light Sensor for auto brightness control

Compliant with MIL-STD-810G/F , MIL-STD-461E/F

Convenient On-Screen Display Controls

Flush Rack / Rack Mount Mechanical Design

Isolation DC 9~36 V Power input (Optional)

Chapter 1: Introduction

1.3 Package Contents

Carefully remove the box and unpack your display. Please check if all the items listed below are

inside your package. If any of these items are missing or damaged contact us immediately.

Standard package includes:

Panel PC

User Manual

(Hardcopy)

Power Cord

MIL-DTL-38999/1

Varies by product

specifications

Part No. 91521110111l

Part No.

94B303003000 (US)

1.4 Appearance

This section includes appearance and input/ output connectors’ layout.

Military Console Rack PCAP Panel PC User Manual

1.5 Connector Description

The I/O connectors are located on the bottom rear side of the panel PC.

Item

Description

Function

Power input connector

Power input AC 110~240V (Default) or DC 9~36V

(Optional).

Serial port RS-232/422/485

Provides serial communication transmission of

data RS-232/422/485. Default setting RS-232.

Two USB 3.2 connectors

Use USB 3.2 connector to connect your device to

other USB 2.0/ USB 3.0 compatible devices.

HDMI connector

Transmits uncompressed video data and

compressed or uncompressed digital audio data

from a display.

Two LAN connectors

Transfers the data within local area networks to

devices to which it is connected.

I/O position varies by display size. Refer to the section 1.7 Dimensions of this user manual to check

mechanical drawing and I/O position.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Winmate

Winmate

Winmate M-Series Manual de usuario

Winmate

Winmate G-WIN Slim IP65 Manual de usuario

Winmate

Winmate GC Series Manual de usuario

Winmate

Winmate W10IB3S-GSH1 Manual de usuario

Winmate

Winmate R19IHAT-66EX Manual de usuario

Winmate

Winmate R15IB3S-65A1FTP Manual de usuario

Winmate

Winmate W10IB3S-MRH2 Manual de usuario

Winmate

Winmate R15IH3S-SPC3 Manual de usuario

Winmate

Winmate W07IB3S-PCO1-POE Manual de usuario

Winmate

Winmate W07IB3S-POT1 Manual de usuario

Winmate

Winmate 7'' S-Series Manual de usuario

Winmate

Winmate W04FA3S-EHT1 Manual de usuario

Winmate

Winmate R15IH3S-MRA3FP Manual de usuario

Winmate

Winmate R15IH3S-MRA3FP Manual de usuario

Winmate

Winmate R15IH3S-SPC369 Manual de usuario

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Manual de usuario

Winmate

Winmate R17IK3S-SPM1 Manual de usuario

Winmate

Winmate R05FA3S-OFD1HMHB Manual de usuario

Winmate

Winmate R15IK3S-SPC3 Manual de usuario

Winmate

Winmate IP69K Stainless P-Cap Manual de usuario

Winmate

Winmate R15IH3S-MRA3FP Manual de usuario

Winmate

Winmate W10IE3S-MRH2FP Manual de usuario

Winmate

Winmate E-Series Manual de usuario

Winmate

Winmate 7'' S-Series Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
