Wilson Electronics Weboost Home Complete Manual de usuario

Cell Signal Booster

Home Complete

A WILSON ELECTRONICS BRAND

Use our weBoost App to guide you through the installation.

See inside page for more details.

Installation Guide

NEED HELP? support.weboost.com 1-866-294-1660

Download the weBoost App

Use our app to guide you through setting up a weBoost cell phone

signal booster in your home, business, or vehicle. Boost every

network, including 5G, right away.

Download the weBoost App

Videos to guide you

through installation

Antenna positioning guide

for optimal performance

Before and after cell

signal readings

Package Contents 1

Preparation 2

STEP 1: Inside Antenna & Booster Placement 3

STEP 2: Mount & Point Outside Antenna Toward Nearest

Cell Tower 5

STEP 3: Route & Connect Outside Antenna To Booster 8

STEP 4: Route & Connect Inside Antenna To Booster 9

STEP 5: Power Up The Booster & Optimize The System 10

Measuring Booster Performance 12

Light Patterns 14

Troubleshooting 15

Safety Guidelines 16

Speciﬁcations 18

Warranty 19

______

Index

1CELL PHONE SIGNAL BOOSTER HOME COMPLETE

______

Package

Contents

Home

Complete

Outside Antenna

Mounting Bracket

Wall Mount Brackets

w/Command Strips

Cable Mounting

Clips Qty. 15

Inside

Antenna

(314440)

Outside

Antenna

(314445)

75’ & 60’

Cables

(951160), (951175)

Power

Supply

(850030)

HOME COMPLETE CELL PHONE SIGNAL BOOSTER

______

Preparation

NOTE: These instructions will walk you through a “soft” install process to ﬁnd the

optimal locations for the inside and outside antennas, then through the process

of the permanent installation.

You Will Need (tools not included)

Make sure the following materials are prepared and ready for your installation.

o Ladder

o Drill (if routing cable through wall)

o 1” - 3” diameter existing pole for mounting

Outside Antenna (#901117 Pole Mount can be

purchased separately if needed)

o Recommended: Power Strip with surge protection

1 to 2 hours

1 Person (2 people to make antenna calibration easier)

3CELL PHONE SIGNAL BOOSTER HOME COMPLETE

NOTE: Do not connect booster to power until the system is fully installed.

______

Step 1: Inside Antenna &

Booster Placement

Place the inside antenna where you need the greatest signal boost and place

booster in your desired location at least 24” away from inside antenna.

AT LEAST 24” APART

TIP: The cable from the inside antenna can be

routed into the ceiling and connected to the

coax cable out-of-sight for a better look.

HOME COMPLETE CELL PHONE SIGNAL BOOSTER

Inside Antenna Mounting Options

Mounted

Vertically

Mounting

Bracket

Mounting

Bracket

Command

Strips

Command Strips

Mounted

Horizontally

Or use the kickstand

and set on desktop

______

(STEP 1 cont.)

The inside antenna can be mounted horizontally, vertically or on a ﬂat

surface. Command strips can be used to secure mounting bracket.

5CELL PHONE SIGNAL BOOSTER HOME COMPLETE

______

Step 2: Mount & Point

Outside Antenna Toward

Nearest Cell Tower

NOTE: Mounting on existing roof exhaust pipe would be

a good time-saver option. Watch out for power lines.

Pole mounting and wall mounting options are included. The pole

mounting option is preferred because it will be easier to adjust to the

direction of the cell tower.

Attach the mount to the outside antenna and use the bracket clamp to attach

the antenna to a pole or exhaust pipe.

Outside Antenna

Mount

Bracket

Clamp

Pole

(1.0”-3.0”dia.)

HOME COMPLETE CELL PHONE SIGNAL BOOSTER

Point the outside antenna toward the nearest cell phone tower. To ﬁnd the

nearest tower, use the weBoost app. This is the most critical step of the

installation process because it will determine the overall performance of

the booster’s system.

The greater the separation between the inside and outside antennas, the

better performance you will get from the booster.

Outside Antenna

NOTE: The outside antenna must be at least

50 feet horizontal or 20 feet vertical from

the inside antenna for best performance.

Make sure the inside antenna and outside

antennas are setup so they are facing away

from each other.

Cell Tower

______

(STEP 2 cont.)

7CELL PHONE SIGNAL BOOSTER HOME COMPLETE

If there’s not a pole to easily mount the outside antenna, this may be

mounted on the fascia by fastening the bracket as shown below.

______

(STEP 2 cont.)

Mounting On Side Of Roof (Fascia)

TIP: Make sure to do the optimization test on Step 5 to ﬁnd the best side

of your house before you mount this on the fascia.

Cable Mounting Clips provided

Using only the back Bracket Clamp

for mounting
