VEVOR RC-2005F Manual de usuario
Technical Support and E-Warranty Certificate www.vevor.com/support
MECHANICAL HAND-HELD PIPE DREDGER
USER MANUAL
Model: RC-2005F
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us
only represents an estimate of savings you might benefit from buying
certain tools with us compared to the major top brands and doses not
necessarily mean to cover all categories of tools offered by us. You are
kindly reminded to verify carefully when you are placing an order with us
if you are actually saving half in comparison with the top major brands.
- 1 -
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Model: RC - 2005F
Please read these operating instructions carefully
before starting to work.
Mechanical Hand-Held
Pipe Dredger
- 2 -
1. Tool Handle
4. Storage Chamber
2. Anti-rotation Bolt
5. Crank Handle
3. Cleaning Spring
6. Drill Adaptor
Application：
Kitchen and bathroom plumbing: wash basins, sink, toilets and floor drains.
Manual Operation:
4
3
1
2
5
6
Bellows
O ring
- 3 -
1. Hold the tool handle and press [ Figure 1] .
2. Pull the cleaning spring out of the pantry. And insert it into the tube
until you feel resistance. Always keep a 20-30cm spring between the drain
drain clog remover and the pipe opening.
3. Turn the wrench to the upright position. Four.
4.The crank according to the clockwise direction and turn to clean the
spring.
5. After the blockage is cleared, the wrench is pulled back to the level and
pulled manually back to the storage room. Repeat this process until the
obstruction is removed.
Electric Drill Operation:
1. Connect the dredger and drill as shown in Figure 2.
2. Pull the cleaning spring out of the pantry. And insert it into the pipe
mouth.
3. Set the bit to a low torque setting to avoid injury.
4. Start the drill at a low speed and increase the rotation speed according to
the blocking type. Warning: keep both hands away from the handle when
using to remove the blockage and prevent the rotary bolt from loosening.
5.Manually pull the cleaning spring back into storage. Repeat this process
until the obstruction is removed.
Caution
Always tighten the anti-rotation bolt before turning the cleaning spring
manually or with an electric drill.
Always point the spring away from the body whilst loosening the anti-
rotation bolt.
When clearing blocked sinks, remove water filters and other objects.
Always wear gloves and eye protection when clearing drains.
We recommend that the cleaning spring is cleaned and left to dry before
- 4 -
storing back into the storage chamber for future use.
Technical Data
MODEL
RC-2005F
Feed mode
Manual output
Cable length
25ft
Diameter of cable
6mm
Cable type
Hollow
Address: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: VEVOR STORE INC, 9448 RINCHMOND PL #E
RANCHO CUCAMONGA, California, 91730 United States of America
Made In China
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House,
The Pavilions Preston, United Kingdom
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021,76351
Linkenheim-Hochstetten, Germany
- 5 -
