VEVOR KT1103A Manual de usuario
1
Technical Support and E-Warranty Certificate www.vevor.com/support
MANUAL RATCHET PIPE THREADER
USER MANUAL
Model: KT1103A
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
1
Model: KT1103A
Thanks for purchasing one of our products, please read carefully the assembly
instructions before the installation.
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
MANUAL RATCHET
PIPE THREADER
2
PRODUCT PARAMETERS
Manual pipe threader is designed to thread pipe or conduit using individual
die heads for each size of pipe and a manually operated ratchet.
Suitable for copper pipes, aluminum pipes, galvanized pipes, iron pipes
(not recommended for use with stainless steel pipes)
ASSEMBLY AND USE PRECAUTIONS
1.Assemble needs to follow these instructions. Incorrect assembly can be
a hazard.
2.Do not assemble when tired or under the influence of alcohol, drugs or
medication.
3.Keep bystanders out of the area in use.
4.Use as intended only. Do not use handle extension to increase force.
5.Keep pipe lubricated with cutting oil (not included).
6.Secure pipe to be threaded in clamp before use.
7.Store idle equipment. When not in use, tools must be stored in a dry
location to inhibit rust. Always lock up tools and keep out of reach of
children.
8.Maintain tools with care. Keep tools sharp and clean for better and safer
performance. Follow instructions for lubricating and changing
accessories. Check tool cords periodically. If they are damaged, have them
repaired by an authorized technician. The handles must be kept clean,
dry, and free from oil and grease at all times.
9.Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty. Only use
accessories intended for use with this tool. Approved accessories are
Model
Die Sizes
Screw Die
Material
KT1103A
A:1/2" (14 TPI)
B:3/4" (14 TPI)
C:1" (11.5 TPI)
9SiCr
3
available from Harbor Freight Tools.
10.The warnings, precautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
The operator must understand that common sense and care are factors
that cannot be built into the product but must be provided by the operator.
WARNING: TO PREVENT SERIOUS INJURY AND DEATH FROM
TIPPING:
1.This product is not a toy. Do not allow children to play with or approach
this item.
2.Check before each use. Do not use the parts if they are loose or
damaged.
3.Wear safety goggles and heavy-duty work gloves in use.
Parts List and Diagram
4
5
Operating Instructions
NOTICE: Make sure the pipe end and threads of the Die are sufficiently
oiled at all times.Otherwise, Die life will be shortened and the threads will
be rough. See Figure A.
1.Assemble the Handle and insert the threaded portion of the Handle Tube into the
Ratchet Holder.
2.Determine the size of the pipe to be threaded.
3.Pick the appropriate Die to be used.Die sizes are stamped on the outside of each
Die.
4.Place the rear of the Die next to the end of the pipe to be threaded.Verify that the
inside diameter of the Die matches the outside diameter of the pipe.
5.Insert Die into Ratchet Holder.It is a forced fitting, and once the Die is in the
Ratchet Holder, it may require light tapping with a wooden mallet to remove the Die.
6.Fill the Oil Can with Thread Cutting Oil (sold separately).Keep it nearby during the
threading operation.
7.Make sure that the pipe to be threaded is properly secured in a vise (sold
separately),and make sure the pipe end to be threaded is cut cleanly and squarely.
8.Make sure that the Reversing Knob is seated all the way down into the grooves of
the Ratchet Holder and its arrow is pointing away from the handle.
6
9.Slide the pipe guide at the end of the ratchet holder through the pipe. When
pressure is applied to the front end of the die, the handle is used to rotate the
ratchet support to engage the die to the pipe end. See Figure B. Continue this
operation until the desired thread length is achieved.
10. Stop threading when the end of the Die is flush with the end of the pipe.
11. To disengage the Die after threading is complete, pull out the Reversing Knob,
turn it 180 degrees until the arrow points in the opposite direction (toward the
handle), and drop it back into place.This will reverse the Pawl.
12. Use the Handle to rotate the Ratchet Holder in the opposite direction until the
Die disengages fully from the pipe end.Maintain control of the Ratchet Holder as
the Die slides off the pipe.Be careful not to damage newly cut threads.
13.Clean any spilled oil off the ground. Clean the threader and store it indoors in a
dry clean area.
Cleaning, Maintenance, and Lubrication
--For cleaning, wipe the surface with a damp (not wet) cloth or wipe dry
with a clean lint free cotton cloth.
--DURING USE, ensure that pipe end and die threads are oiled with
Thread Cutting Oil (not included) at all times.
-- Worn die blades will result in poor thread quality. If the blade is worn,
replace it with a qualified technician.
