VEVOR GZL66 Manual de usuario
Technical Support and E-Warranty Certificate www.vevor.com/support
Anvil
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
GZL66 GZL22 GZL9
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
ANVIL
- 2 -
1. Important safety instructions
Warning - To reduce the risk of injury, user must read instructions
manual carefully.
Warning- Be sure to wear ear protectors when using this product.
Warning- Be sure to wear eye protectors when using this product.
Warning- Be sure to wear dust masks when using this product.
Warning- Be sure to wear gloves when using this product.
WARNING!
1. Use the product only after receiving professional metalworking
training.
2. Wear necessary personal protective equipment such as safety
goggles, earplugs, and protective gloves during use.
3. Ensure that the workspace remains clean, dry, and well-ventilated
during operation.
4. Do not use the anvil in flammable, explosive, or damp environments.
5. Ensure that the anvil is securely installed and stable to prevent
movement or tipping during use.
6. Follow safe operating procedures when using the anvil, avoiding
excessive force or incorrect techniques.
7. Fix it first when using it. so as not to be injured.
8. Keep away from children
2. Product overview
This cast steel anvil is manufactured using high-quality casting techniques,
providing blacksmiths and metalworkers with a sturdy and stable work
surface. It is suitable for various processes such as forging, hammering,
- 3 -
shaping, and cutting metal materials. This product features excellent
durability and impact resistance, bringing higher efficiency and accuracy to
your metalworking tasks.
3. Product properties- 66lbs Anvil
3.1 Product Structure
1. Hardy hole : The Hardy hole hole on
the anvil is used to insert other tools,
and other tools can be firmly connected
to the anvil for further processing.
2. Pritchel hole: The Pritchel hole can
be punched out on the product with a
chisel or other tools.
3. Horn:The horn are specially
designed to help blacksmiths shape
metal pieces into round or curved
shapes.
3.2 parameter
1) Model: GZL66
2) Material: Casting 40# steel
3) Working Surface Hardness: 53±4HRC
4) Hardy hole size: 22×22mm
5) Pritchel hole size:φ16mm
6) N.W.: 30kg
7) G.W.: 33.3kg
8) Package Size: 470x230x235mm
4.Product properties- 22lbs Anvil
4.1 Product Structure
1. Hardy hole : The Hardy hole hole on the
anvil is used to insert other tools, and other
tools can be firmly connected to the anvil for
- 4 -
further processing.
2. Pritchel hole: The Pritchel hole can be punched out on the product with a
chisel or other tools.
3. Horn:The horn are specially designed to help blacksmiths shape metal
pieces into round or curved shapes.
4.2 parameter
1. Model: GZL22
2. Material: Casting 40# steel
3. Working Surface Hardness: 53±4HRC
4. Hardy hole size: 16×16mm
5. Pritchel hole size:φ16mm
6. N.W.: 10kg
7. G.W.: 11.1kg
8. Package Size: 400x145x140mm
5. Product properties- 9lbs Anvil
5.1 Product Structure
1. Mounting holes : There are 4 mounting
holes on the bottom, which can be fixed to
the platform with screws.
2. Horn:The horn are specially designed to
help blacksmiths shape metal pieces into
round or curved shapes.
5.2 parameter
1. Model: GZL9
2. Material: Casting 40# steel
3. Working Surface Hardness: 53±4HRC
4. N.W.: 4kg
5. G.W.: 4.6kg
6. Package Size: 250x120x130mm
- 5 -
6. User Guide
1．Place the anvil on a flat, sturdy base, ensuring it is securely installed
and resistant to sliding.
2．Heat the metal material to be forged to an appropriate temperature.
3．Place the heated metal material on the anvil surface and use a hammer
or other tools to strike, shape, or cut it.
4．Reheat and forge the metal material as needed until the desired shape
and dimensions are achieved.
5．After using, allow the metal material to cool naturally to room
temperature.
7. Maintenance
1. If you do not use this tool for a long time, please add anti-rust oil on the
surface.
2. Store the anvil in a dry, well-ventilated area away from direct sunlight.
Address: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
Made In China
