VeriFone T650p Manual de usuario
WWW.TILLPAYMENTS.COM
Verifone
T650p
INTEGRATED POINT OF SALE TERMINAL
Quick
Reference
Guide
2 Quick reference guide
FOR VERIFONE T650P TERMINAL
3 Quick reference guide
Get to know
your terminal
Contactless
reader
Paper roll
cover
Power/Accessibility
mode button
Volume button
Navigation keys
Card insert
Card swipe
USB-C charging port
Notication bar
On the terminal screen, swipe down and press and hold the wi icon
Toggle ‘on’ wi and select desired network
Enter password and tap ‘connect’
Getting Started
4 Quick reference guide
Connecting to WiFi
If the ‘aeroplane mode’ message is displayed on the device, you can turn off aeroplane mode
by swiping down from the top of the terminal screen
Swipe left and press the areoplane mode icon to switch it off
Turn off aeroplane mode
Installing & Ordering Paper Rolls
STEP 1
STEP 2
Hold both sides of the paper door, which is on the upper corner of
the device and open the paper door by pulling outside. Remove any
partial roll of paper in the tray.
Loosen the glued leading edge of the new paper roll or remove the
protective strip. Unwind the paper roll past any glue residue. Hold the
roll so that paper feeds from the top of the roll. Align the printer paper
to the tabs to the paper guides and hold the paper up when closing
the door.
STEP 3
With the printer paper extending outside, close the printer door by
swinging upward until the door clicks shut, allowing the printer paper
to extend outside the printer door.
To place order for receipt paper, please contact Till Payments Support at
Menus
5 Quick reference guide
To place order for receipt paper, please contact Till Payments Support at
6 Quick reference guide
Click on the screen to start transaction
On the keypad, enter the transaction amount and tap ‘next’
The terminal will provide options to choose the transaction type (card/other. Other will
initiate various transactions such as Purchase + Cashout, Refund etc)
The card payment screen will be presented and the customer will be prompted to insert,
swipe or tap their card
Once the payment is successful, a message will appear and the terminal will prompt to print
receipt
How to process a Transaction
7 Quick reference guide
Press MENU on the home screen, and press Transaction history
You will be presented with different ways to search transactions by type
Search by:
Last transaction: Displays the last transaction accepted on the terminal
Search by RRN: Ability to input RRN Number
Search by Card number
Search by Date: Calendar view of transactions. Ability to sort by start and end date
Transaction Search
8 Quick reference guide
Press ‘Menu’ and then press ‘Manage POS Pairing’
Press the plus (‘+’) button to begin the pairing process. This will enable the ‘Start Pairing’
screen to appear’
On your POS system, start up Spice and enter your Unique POS ID and the Payment Terminal
IP Address as displayed on the Till Pairing Screen e.g. 192.168.0.35. Press ‘Pair’. At the same
time, press ‘Start’ on the terminal screen
Spice will display pairing in process and will display pairing code
Terminal will display Pairing Code. If matched then press ‘Yes’
Terminal will display Pairing Successful. Press ‘Finish’
Spice will display that the T650p Payment Terminal is connected
T650p Payment Terminal connection status is green and displays that the Terminal is paired
to the correct POS
Pairing your terminal to the
Point of Sale (POS) system
9 Quick reference guide
Press ‘Menu’ and then press ‘Manage POS Pairing’
Select the POS that you wish to unpair by pressing the POS information
Press the Unpair Button
Conrm the intention to Unpair by pressing “Unpair”
Unpaired conrmed
Unairing your terminal from the
Point of Sale (POS) system
Unpairing the T650P Terminal is a capability that is used for removing the pairing of the Payment
Terminal to the Point of Sale System. This capability is used when a merchant wants to pair the
Payment Terminal to another Point of Sale System in their premises or when a terminal has lost
its pairing for various reasons including loss of communications or other technical reasons.
To unpair the Terminal from the POS system:
Trouble
Shooting
Hardware faults
Device does not start
Ensure that the device is plugged into a dedicated power source;
Check if the power cable connector is plugged in properly.
Device Display Does Not Show Correct/ Readable Info
If the device display does not show correct/readable info, please check all the cable
connections.
Transactions Fail to Process
Check the Magnetic Card Reader:
1. Perform a test transaction using one or more different magnetic stripe cards to ensure that
the problem is not a defective card;
2. Ensure that you are swiping the card properly;
3. Process a transaction manually using the keypad instead of the card reader. If the manual
transaction works, then the problem may be a defective card reader.
Blank Display
If the device display is dark, tap the screen with the stylus or your nger. If the unit was in
screen-saver mode, the screen will turn on when touched;
If the display does not show correct or readable information, then check all the cable
connections.
Keypad Does Not Respond
Check the device display. If it displays the wrong character or nothing at all when you press a
key, follow the steps outlined in Transactions Fail to Process below;
Refer to the user documentation for that application if pressing a function key does not perform
the expected action to ensure you are entering correct data correctly.
Software faults
Check the Smart Card Reader
1. Perform a test transaction using several different smart cards to ensure the problem is not
a defective card.
2. Ensure that the card is inserted correctly.
3. Ensure that the MSAM cards are properly inserted in the slots and are properly secured.
10 Quick reference guide
