Tripp Lite AGPS5542 Manual de usuario

SmartOnline®

Rack/Tower Mount On-Line UPS

Systems

Not suitable for mobile applications.

Models:

SU750RTXL2U (Series Number: AGPS5542)

SU1000RTXL2UA (Series Number: AGPS5180)

SU1500RTXL2UA (Series Number: AGPS5194)

SU2200RTXL2UA (Series Number: AGPS5183)

SU3000RTXL2U, SU3000RTXR3U (Series Number: AGPS5204)

SU3000RTXR3UHW (Series Number: AGPS7039)

Important Safety Instructions 2

Installation 4

Basic Operation 9

Troubleshooting 13

Battery Replacement 14

Storage and Service 15

Product Registration 16

Regulatory Compliance 16

Español 17

Français 33

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

17-05-032-932471.indb 1 5/23/2017 1:41:30 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of all Tripp Lite UPS Systems. Failure to heed these

warnings may affect your warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust

or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in

this manner will seriously inhibit the unit’s internal cooling, eventually causing product

damage not covered under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS ground

connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must

provide clean, filtered, computer-grade output.

CAUTION: Install in accordance with National Electrical Code standards ANSI/NFPA 70 and

Canadian Electrical Code, Part I, C22.1. Be sure to use the proper overcurrent branch

protection for the installation, in accordance with the plug/equipment rating.

CAUTION: Short Circuit backup protection and overcurrent protection is provided by the

building installation for permanently connected models.

CAUTION: To reduce the risk of fire, connect only to a circuit-provided branch circuit

overcurrent protection in accordance with the National Electrical Code, ANSI/NFPA 70 and

the Canadian Electrical Code, Part I, C22.1. Use 30A maximum overcurrent protection for

models SU3000RTXL2U and SU3000RTXR3U (series AGPS5204), and SU3000RTXR3UHW

(series AGPS7039).

• Your UPS may be equipped with a terminal block for permanent connection to AC Mains.

Installation is by qualified service personnel only. When connecting to permanently connected

units use only copper conductors 10AWG with a minimum temperature rating 165°F (75°C).

• Be sure to provide a local disconnect device on any models that are permanently installed

without a plug that is easily accessible.

17-05-032-932471.indb 2 5/23/2017 1:41:30 PM

Important Safety Instructions

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended.

• Do not connect surge protectors or extension cords to the UPS output. This may damage the

UPS and affect the surge protector and UPS warranties.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current.

Observe proper precautions. Do not dispose of the batteries in a fire. Do not open the UPS or

batteries. Do not short or bridge the battery terminals with any object. Unplug and turn off the

UPS before performing battery replacement. Use tools with insulated handles. There are no

user-serviceable parts inside the UPS. Battery replacement should be performed only by

authorized service personnel using the same number and type of batteries (Sealed Lead-

Acid). The batteries are recyclable. Refer to your local codes for disposal requirements or visit

http://www.tripplite.com/support/recycling-program for recycling information. Tripp Lite offers a

complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the

Web at http://www.tripplite.com/products/battery-finder/ to locate the specific replacement

battery for your UPS.

17-05-032-932471.indb 3 5/23/2017 1:41:30 PM

Installation

Rack Mounting

Mount your equipment in either a 4-post or 2-post rack or rack enclosure (see next page for

2-post mounting). The user must determine the fitness of hardware and procedures before

mounting. If hardware and procedures are not suitable for your application, contact the

manufacturer of your rack or rack enclosure. The procedures described in this manual are for

common rack and rack enclosure types and may not be appropriate for all applications.

4-Post Mounting

All UPS models include hardware required to mount in a 4-post rack. Select models include an

adjustable rackmount shelf kit to provide additional support. If your UPS model does not

include an adjustable rackmount shelf kit, skip steps 1 and 2.

1Connect the two segments of each shelf

Ausing the included screws and nuts B.

Leave the screws slightly loose so that the

shelves can be adjusted in the next step.

2Adjust each shelf to fit your rack, then

mount them in the lowest available space

of your rack with the screws, nuts and

washers provided C. The support ledges

should face inward. Tighten the screws

that connect the shelf segments B.

3Attach mounting ears Dto the front

mounting holes of your equipment E

using the provided screws F. The ears

should face forward.

4Using an assistant (if necessary), lift your

equipment and slide it onto the mounting

shelves. Attach your equipment to the

rack by using the appropriate hardware G

through its mounting ears and into the

rack rails.

17-05-032-932471.indb 4 5/23/2017 1:41:41 PM

Your model may differ.

2-Post (Telecom) Mounting

If you mount 2U UPS models in 2-post racks, they require the addition of a Tripp Lite 2-Post

Rackmount Installation Kit (model: 2POSTKITRMWM, sold separately). See Installation Kit

owner’s manual for installation procedure for 2U UPS models.

Installation

Mounting (Tower)

Your UPS can be mounted in an upright tower

position with optional base stands sold

separately by Tripp Lite (Model #

2-9USTAND). When mounting the UPS on

adjustable base stands, make sure that the

control panel is toward the top. The control

panel may be rotated to make it easier to

read. Insert a small screwdriver or similar tool

in the slots on either side of the panel, pop it

out, rotate it, and pop it back into place as

shown.

WARNING!

All UPS systems are extremely

heavy. Use caution when lifting

and mounting. User must properly

stabilize the UPS when lifting and

mounting.

Connection and Start-Up

1Plug your UPS line cord into an

electrical outlet.

Your UPS must be connected to a

dedicated circuit of sufficient amperage.

However, the select models may be fitted

with different plug types. Refer to the “OP

Rating/Plug Rating” chart printed on the

top of your UPS.

Once your UPS is plugged in, the fan and

all Indicator Lights will turn ON. The “LINE”

and “LOAD ACTIVE METER” LEDs will

illuminate and the UPS will beep to

indicate normal operation. However, power

is not supplied to your UPS AC outlets

until the UPS is turned on.

2Plug your equipment into your UPS.

Your UPS is designed to support computer

equipment only. You will overload your

UPS if you connect household appliances

or laser printers to the UPS outlets.

17-05-032-932471.indb 5 5/23/2017 1:41:43 PM

1Your model may differ.

Your model

may differ.

Your model may differ.

Installation

3Turn your UPS ON:

• Press the “ON/TEST” Button

• Hold it for several seconds until you

hear a beep

• Release it

Your UPS will begin providing AC power to

its outlets. The “ON LINE” LED will

illuminate.

Note: UPS system will function properly upon

initial startup; however, maximum runtime for

the unit’s battery will only be accessible after it

has been charged for 24 hours.

Optional Connections

Your UPS will function properly without these connections.

1Phone Line or Phone/Network

Line Surge Suppression

Your UPS has jacks which protect against

surges on a phone line. Select models

feature jacks which also protect against

surges on a network line.* Using

appropriate telephone or network cords

connect your wall jack to the UPS jack

marked “IN.” Connect your equipment to

the UPS jack marked “OUT.” Make sure

the equipment you connect to the UPS

jacks is also protected against surges on

the AC line.

* Not compatible with PoE (Power Over Ethernet)

applications.

2USB and RS-232 Serial

Communications

Use the included USB cable 2a and/or

DB9 serial cable 2b to connect the

communication port of your computer to

the communication port of your UPS.

Install on your computer the Tripp Lite

PowerAlert®Software appropriate to your

computer's operating system. Your UPS

may feature additional communications

ports; these ports may be connected to

additional computers that have PowerAlert

Software installed. Consult your PowerAlert

manual for more information.

17-05-032-932471.indb 6 5/23/2017 1:41:44 PM

4-5

Your model may differ.

Installation

3EPO Port Connection

This optional feature is only for those

applications requiring connection to a facility’s

Emergency Power Off (EPO) circuit. When the

UPS is connected to this circuit, it enables

emergency shutdown of the UPS inverter and

inhibits transfer to internal bypass. Using the

provided cable, connect the UPS EPO port 3a

to a user-supplied, normally-closed or

normally-open switch according to the circuit

diagram 3b .

Note:

1. If using a cable other than what is supplied, the

cable should not exceed 350 feet or have a

resistance of greater than 10 ohms.

2. If a non-latching EPO switch is used, the EPO

must be held for a minimum of 1 second. This

does not apply to a latching EPO switch.

CAUTION: The EPO port is not a

phone line surge suppressor; do

not connect a phone line to this

port.

UPS Unit State when asserting EPO with AC line present:

LEDs Output Fans Serial SNMP USB

OFF OFF ON ON ON ON

To restart the UPS unit after asserting EPO with AC line present:

Option 1:

1. Verify that the EPO assertion has been removed or cleared.

2. Press OFF button until you hear a click (approx. 1 second).

3. Press ON button and UPS output will turn back on.

Option 2:

1. Verify that the EPO assertion has been removed or cleared.

2. Remove AC line power to the UPS unit.

3. Reapply AC line power. Now the UPS will start back up in normal operation mode.

UPS Unit State when asserting EPO without AC line power:

LEDs Output Fans Serial SNMP USB

OFF OFF OFF OFF OFF OFF

To restart the UPS unit after asserting EPO without AC line power:

1. Verify that the EPO assertion has been removed or cleared.

2. Reapply AC line power to the UPS unit. Now the UPS will start back up in normal operation

mode.

17-05-032-932471.indb 7 5/23/2017 1:41:45 PM

Installation

4External Battery Pack Connector (configuration varies by model):

Use to connect optional Tripp Lite Battery Packs for additional runtime. Use only Tripp Lite

external battery packs with overcurrent protection. Adding external batteries will increase

recharge time as well as runtime. Installation should be performed by qualified service

personnel only. Refer to the battery pack owner’s manual for complete installation

instructions. Make sure cables are firmly inserted into their connectors. Small sparks may

result during battery connection; this is normal. Do not connect or disconnect battery packs

when the UPS is operating on battery power. The following battery packs are available in the

table below. Contact Tripp Lite Customer Support at 773.869.1234 for assistance in

determining the appropriate Tripp Lite battery pack to connect.

24V Battery Packs 48V Battery Packs 72V Battery Packs

Model

Amp-Hour

Rating Model

Amp-Hour

Rating Model

Amp-Hour

Rating

BP24V15RT2U 14 Ah BP48V24-2U 18 Ah BP72V15-2U 15 Ah

BP24V28-2U 28 Ah BP48V27-2US 27 Ah BP72V18-2US 18 Ah

BP24V36-2US 36 Ah BP48V60RT-3U 42 Ah BP72V28RT-3U 28 Ah

BP24V70-3U 70 Ah

When connecting to two-conductor external battery packs, be sure to use the ground strap

included with the external battery packs to bond the battery packs to the metal enclosure of

the UPS in accordance with your external battery pack Owner’s Manual.

Note: Three-conductor battery packs are equipped with a ground bond plug. Refer to the battery pack

instructions for complete connection information and safety warnings.

17-05-032-932471.indb 8 5/23/2017 1:41:45 PM

Basic Operation

Front Panel Switches

“ON/TEST” Button: This switch controls four separate UPS functions:

UPS Power ON

To turn the UPS on, press this button, hold for several seconds until you

hear a beep, then release. The “ON LINE” LED will illuminate.

UPS Self-Test

During normal on-line operation, press this button and hold it until you

hear a beep. This initiates a 10-second battery self-test. The UPS will

shift to battery power (all LEDs will illuminate) for ten seconds.

Alarm Silence

To silence the UPS “on-battery” alarm, press this button and hold it until

you hear a beep.

UPS Cold Start

To use your UPS as a standalone power source when AC power is

unavailable (i.e. during a blackout), press this button and hold it until you

hear a beep. The UPS will then provide battery power to its outlets.*

* The “ON BATT” Indicator Light will be illuminated since your UPS will be operating

from battery power.

“OFF” Button: This button turns power OFF at the UPS receptacles.

Press this switch, hold until you hear a beep, then release. The UPS will

continue charging and the fan will continue to cool internal components

even after you turn the UPS receptacles off. To turn the UPS OFF

completely, including the charger, disconnect the UPS’s power cord after

pressing the “OFF” switch.

Front Panel Indicator Lights

“ON LINE” LED: This green light will illuminate constantly to indicate the

UPS is performing normal on-line operation (filtering and resynthesizing

incoming AC line voltage to provide pure sine wave output). When this

light is illuminated, you can monitor the load level of your UPS on the

“LOAD ACTIVE METER” LEDs.

“LINE” LED: This green light will illuminate constantly to indicate the

utility supplied AC line voltage at your wall outlet is nominal. It will flash if

the line voltage is outside the nominal range (either too low or two high).

No action is required on your part when the LED flashes; the UPS

continuously and automatically filters AC line power to provide your

equipment with pure sine wave AC power, regardless of brownout or

overvoltage conditions. If this light is off, then AC line voltage is not

present (blackout) or is at an extremely high voltage, and the UPS will

provide connected equipment with power from battery.

17-05-032-932471.indb 9 5/23/2017 1:41:45 PM

Basic Operation

“BYPASS” LED: This yellow light will flash to indicate that the UPS DC/AC

inverter is deactivated and the UPS is in the “Bypass” mode. During

normal operation this LED will light briefly when the unit is plugged in,

but if an internal fault or overload occurs, this light will flash constantly

and the fault LED will illuminate to show that connected equipment will

receive filtered AC mains power, but will not receive battery power during

a blackout. In this case, contact Tripp Lite for service. If the UPS has

been placed into Economy Mode (available on select UPS systems), it

configures an online UPS to function as a switching UPS. When the UPS

system is in Economy Mode, it operates at increased efficiency while AC

utility power is available (within +/- 10% nominal) and switches to

battery power if AC utility power is interrupted. The yellow “BYPASS” LED

will remain on when the UPS system is in Economy Mode. (For more

information on how to access the Economy Mode, please refer to the

PowerAlert software User’s Manual)

“FAULT” LED (select models only): This red light will flash when your

UPS detects an internal fault (overheating, overvoltages, etc.) or when it

detects a wiring fault in your wall outlet (reversed phases, missing

ground, etc.) The UPS will only detect wiring faults when it is plugged

into a utility outlet but not turned ON. If the light persists after restarting

the UPS, contact an electrician to check the AC line. Your UPS will

identify the presence of most (but not all) wiring faults.

“LOAD ACTIVE METER” LED: This green light will illuminate when your

UPS is receiving AC power to indicate that the set of four dual-function

LEDs is displaying the load level of your UPS.

“BATT ACTIVE METER” LED: This green light will illuminate when your

UPS is operating from battery power to indicate that the set of four dual-

function LEDs is displaying the battery charge level of your UPS.

Note: The “ON BATT” LED will also be illuminated.

“OVERLOAD” LED: This red light will illuminate constantly to indicate

that your UPS capacity has been exceeded while it is in on-line

operation. The UPS alarm will beep continuously. Immediately remove

overload until light and alarm goes off. If you do not immediately remove

the overload, the UPS will transfer from on-line to bypass operation.

“BATT LOW” LED: This yellow light will illuminate when your UPS battery

charge level is low. The UPS alarm will beep until either the battery

charge is depleted or the batteries are adequately recharged.

“ON BATT” LED: This green light will illuminate constantly to indicate

that AC line voltage is not present and your UPS is providing your

equipment with battery power. The UPS will also beep every two seconds,

unless silenced by the “ON/TEST” Button. When this light is illuminated,

you can monitor the battery charge level of your UPS on the “BATT

ACTIVE METER” LEDs.

17-05-032-932471.indb 10 5/23/2017 1:41:47 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Unión Postal Universal de Tripp Lite

Tripp Lite

Tripp Lite SmartOnline 3-Phase 10kVA Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU1500XLCD Manual de usuario

Tripp Lite

Tripp Lite SmartOnline 120/208V Manual de usuario

Tripp Lite

Tripp Lite OmniPro 675 Manual de usuario

Tripp Lite

Tripp Lite TE600 Manual de usuario

Tripp Lite

Tripp Lite SmartPro 450 RTI Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART2200RM2U Manual de usuario

Tripp Lite

Tripp Lite SMART1500LCDXL Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU2200XLNAFTA Manual de usuario

Tripp Lite

Tripp Lite SMART2500XLHG Manual de usuario

Tripp Lite

Tripp Lite SMART1200LCD Manual de usuario

Tripp Lite

Tripp Lite Internet Office Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL3U Manual de usuario

Tripp Lite

Tripp Lite SmartPro Rackmount Manual de usuario

Tripp Lite

Tripp Lite SmartPro AGSM152DRTi2U Manual de usuario

Tripp Lite

Tripp Lite SmartPro SLT SMX750SLT Guía de configuración

Tripp Lite

Tripp Lite ECO-UPS ECO850LCD Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU40K Manual de usuario

Tripp Lite

Tripp Lite HT850UPS Manual de usuario

Tripp Lite

Tripp Lite SmartPro VS SMART3000VS Manual de usuario

Tripp Lite

Tripp Lite SmartOnline 220/380V Manual de usuario

Tripp Lite

Tripp Lite TE600 Manual de usuario

Tripp Lite

Tripp Lite SMART1500LCDXL Manual de usuario

Tripp Lite

Tripp Lite OmniSmart 725 Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
