BC Pro 120V 1050VA 705W Standby UPS, Tower,

USB port, 6 Outlets

MODEL NUMBER: BCPRO1050

Description

Tripp Lite's BCPRO1050 standby UPS offers AC surge suppression and long lasting battery support for desktop PCs, network workstations and a wide variety

of consumer and professional electronics. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within milliseconds to keep connected

equipment running without interruption or data loss during power failures, brownouts and overvoltages. AC surge suppression prevents connected equipment

damage. USB communications port supports full featured monitoring and data-saving auto-shutdown options using Tripp Lite's free PowerAlert monitoring

software.

Features

BCPRO1050 tower 120V standby UPS offers AC power protection from blackouts, brownouts, overvoltages and transient surges

1050VA / 705 watt UPS output capacity

Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts, brownouts and overvoltages to prevent data loss

and system downtime for connected equipment

Built-in USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from

www.tripplite.com

7 minutes runtime at 100% load (705 watts), 23 minutes runtime at 50% load (355 watts)

107 minutes runtime for a desktop computer system consuming 80 watts continuous

6 built-in NEMA 5-15R UPS supported outlets

NEMA 5-15P input connection with 6ft / 1.8m line cord

Network grade AC surge and lightning protection is available from all outlets

97% line mode efficiency rating uses less energy and BTU emissions

Front panel LEDs indicate line / battery mode, low battery, replace battery status; Audible alarm with alarm cancel / self-test button

Hot swappable user battery replacement

Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment

Tower housing supports desk or floor placement

Specifications

Highlights

1050VA / 1.05kVA tower 120V

standby UPS

Maintains AC output during power

failures

USB port, Front panel status

LEDs, 97% efficient

NEMA 5-15P input plug and 6

NEMA 5-15R outlets

Package Includes

BCPRO1050 UPS System

USB cable

Instruction manual

1 / 4

OUTPUT

Output Volt Amp Capacity (VA) 1050

Output kVA Capacity (kVA) 1

Output Watt Capacity (Watts) 705

Nominal Output Voltage(s)

Supported 115V; 120V

Frequency Compatibility 60 Hz

Output Voltage Regulation (Battery

Mode) 115V (+/- 5%)

Output Receptacles (6) 5-15R

Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)

Output AC Waveform (AC Mode) Sine wave

Output AC Waveform (Battery Mode) PWM sine wave

INPUT

Rated input current (Maximum Load) 6.4A

Nominal Input Voltage(s) Supported 120V AC

UPS Input Connection Type 5-15P

Input Circuit Breakers 15A

UPS Input Cord Length (ft.) 6

UPS Input Cord Length (m) 1.8

Recommended Electrical Service 15A 120V

Input Cord Length (ft.) 6

Input Cord Length (m) 1.8

Input Phase Single-Phase

BATTERY

Full Load Runtime (min.) 7 min. (705w)

Half Load Runtime (min.) 23 min. (355w)

DC System Voltage (VDC) 18

Battery Recharge Rate (Included

Batteries) Less than 4 hours from 10% to 90%

Internal UPS Replacement Battery

Cartridge RBC52 (quantity 3)

Battery Access Battery access door

Battery Replacement Description Hot-swappable, user replaceable batteries

2 / 4

LEDS ALARMS & SWITCHES

LED Indicators 5 LEDs indicate line power, battery power, battery low/replace and overload status

Audible Alarm Audible alarm indicates power-failure and low-battery conditions

Alarm Cancel Operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC Suppression Joule Rating 510

UPS AC Suppression Response

Time Instantaneous

EMI / RFI AC Noise Suppression Yes

AC Suppression Joule Rating 510

AC Suppression Response Time Instantaneous

PHYSICAL

Installation Form Factors Supported

with Included Accessories Tower

Installation Form Factors Supported

with Optional Accessories Wallmount (UPSWM - tower mounting kit)

Primary Form Factor Tower

UPS Power Module Dimensions

(hwd, in.) 11.2 x 6.8 x 7

UPS Power Module Dimensions

(hwd, cm) 28.6 x 17.1 x 17.8

UPS Power Module Weight (lbs.) 29

UPS Power Module Weight (kg) 13.2

UPS Shipping Dimensions (hwd / in.) 15.2 x 10.8 x 11.5

UPS Shipping Dimensions (hwd /

cm) 38.7 x 27.3 x 29.2

Shipping Weight (lbs.) 29

Shipping Weight (kg) 13.2

UPS Housing Material Polycarbonate

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC Mode BTU / Hr. (Full Load) 74.1

3 / 4

Battery Mode BTU / Hr. (Full Load) 562.3

AC Mode Efficiency Rating (100%

Load) 97%

COMMUNICATIONS

Communications Interface USB

PowerAlert Software Free download from www.tripplite.com

Communications Cable USB interface cable included

WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer Time 2-4 milliseconds

Low Voltage Transfer to Battery

Power (Setpoint) 99

High Voltage Transfer to Battery

Power (Setpoint) 143

SPECIAL FEATURES

Cold Start (Startup in Battery Mode

During a Power Failure) Cold-start operation supported

High Availability UPS Features Hot swappable batteries

Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Meets FCC Part 15 Category B (EMI); ROHS (Restriction of Hazardous Substances); Tested to CSA (Canada);

Tested to NOM (Mexico); Tested to UL1778 (USA)

WARRANTY

Product Warranty Period (Worldwide) 2-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $200,000 Ultimate Lifetime Insurance

Specifications are subject to change without notice. Photos may differ slightly from final products.
