Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: AVR900U

AVR Series 900VA Ultra-compact Line-Interactive 120V UPS with USB port

Highlights

900VA ultra-compact 120V line interactive UPS

Corrects brownouts and overvoltages from 83V to 147V

6 UPS battery supported outlets, 6 surge-only outlets

USB port, TEL/DSL protection, Wall mountable, 98% efficient

NEMA 5-15P input plug and 12 NEMA 5-15R outlets

Description

Tripp Lite's AVR900U Ultra-Compact Line Interactive UPS offers complete power protection for desktop PCs, network workstations and a wide

variety of professional and consumer electronic devices. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within

milliseconds to keep connected equipment running without interruption or data loss during power failures. Automatic Voltage Regulation / AVR power

conditioning maintains smooth, continuous operation of connected equipment during brownouts and overvoltages. Surge-only outlets offer

convenient protection for printers and other desktop accessories not requiring battery support. AC and dataline surge suppression prevents

connected equipment damage. USB communications port supports built-in power management and auto-shutdown features of Windows and Mac

OS X or full featured monitoring and data-saving auto-shutdown options using Tripp Lite's free PowerAlert monitoring software.

Package Includes

AVR900U UPS System

USB cable

Instruction manual

Features

AVR900U ultra-compact 120V line interactive UPS offers complete AC power protection from blackouts, brownouts and transient surges

900VA / 480 watt UPS output capacity

Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts to prevent data loss and system

downtime for connected equipment

Built-in USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download

from www.tripplite.com

HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

Automatic Voltage Regulation / AVR corrects extended brownouts and overvoltages from 83 to 147V, without using battery power

3 minutes runtime at 100% load (480 watts), 10 minutes runtime at 50% load (240 watts)

44 minutes runtime for a desktop computer system consuming 80 watts continuous

12 built-in NEMA 5-15R outlets, two with extra wide spacing to accommodate transformer plugs

6 UPS battery backup outlets, plus 6 additional surge-only outlets

Right angle NEMA 5-15P input connection with 6ft / 1.8m line cord

Network grade AC surge and lightning protection is available from all outlets; Built-in data line surge suppression protects a single dialup or

DSL line

Supports Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application/OS or hard

power off/on reboot of connected equipment, ideal for unattended kiosk applications

98% line mode efficiency rating uses less energy and BTU emissions

Built-in grounding lug

Hot swappable user battery replacement

Space saving, ultra-compact housing with support for wall-mount, desktop or floor placement

Specifications

OUTPUT

Output Volt Amp Capacity

(VA)

900

Output Watt Capacity (watts) 480

Nominal Output Voltage(s)

Supported

115V; 120V

Frequency compatibility 60 Hz

Output voltage regulation

(line mode)

120V (+8%, -21%)

Output voltage regulation

(Battery mode)

115V (+/- 5%)

Built-in UPS output

receptacles

12 5-15R outlet(s)

Surge suppression only

outlets

6 UPS outlets, 6 surge-only outlets

Output AC waveform (AC

mode)

Sine wave

Output AC waveform

(battery mode)

PWM sine wave

INPUT

Rated input current (at

maximum load)

12A

Nominal Input Voltage(s)

Supported

120V AC

UPS input connection type 5-15P

UPS Input cord length (ft.) 6

UPS Input cord length (m) 1.8

Recommended Electrical

Service

15A 120V

BATTERY

Full load runtime (minutes) 3 min. (480w)

Half load runtime (minutes) 10 min. (240w)

DC system voltage (VDC) 12

Replacement battery

cartridge (internal UPS

battery replacement)

RBC51

Battery Access Battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147

Overvoltage correction Input voltages between 129 and 147 are reduced by 12%

Undervoltage correction Input voltages between 83 and 104 are boosted by 14%

LEDS ALARMS & SWITCHES

LED Indicators 2 LEDs indicate power status and overload/check battery status

Alarms Audible alarm indicates power-failure and overload status

Switches Combination switch controls on/off power status and self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression joule

rating

420

UPS AC suppression

response time

Instantaneous

UPS Dataline suppression 1 line TEL/DSL (1 in / 2 out)

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form factors

supported with included

accessories

Tower; Ultra-compact desktop; Wallmount (using keyhole mounting tabs)

Primary form factor Desktop

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / inches)

4 x 12 x 7

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / cm)

10.2 x 30.5 x 17.8

UPS / Power Module weight

(lbs)

15.3

UPS / Power Module weight

(kg)

6.9

UPS Shipping dimensions

(height x width x depth /

inches)

5.5 x 14.5 x 9.8

UPS Shipping dimensions

(height x width x depth / cm)

14 x 36.8 x 24.8

Shipping weight (lbs) 16.3

Shipping weight (kg) 7.4

UPS housing material ABS

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full load) 27

COMMUNICATIONS

Communications interface USB (HID enabled)

PowerAlert software Free download from www.tripplite.com

Communications cable USB interface cable included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time 4 milliseconds (AC to battery) / 1 millisecond (Battery to AC)

Low voltage transfer to

battery power (setpoint)

High voltage transfer to

battery power (setpoint)

147

SPECIAL FEATURES

Cold Start (startup in battery

mode during a power failure)

Cold-start operation supported

High availability UPS

features

Hot swappable batteries

Green & high efficiency

features

Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category

B (EMI)

WARRANTY

Product Warranty Period

(U.S. & Canada)

3-year limited warranty

Product Warranty Period

(International)

2-year limited warranty

Product Warranty Period

(Mexico)

3-year limited warranty

Product Warranty Period

(Puerto Rico)

3-year limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$100,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1

Extended Warranties WEXT5-INTERNET 5-Year Extended Warranty - For Internet Office, AVR and ECO Series

UPS Systems

Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial

lines

Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and

communication lines

Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and

communication lines

USB Cables & Adapters U005-10I 10-inch USB A/A Gold Extension Cable

(USB-A Right Angle Male to USB-A Female)

USB Hubs/Accessories U222-004-R 4-Port USB2.0 Ultra-Mini Hub 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3649.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
