Tripp Lite SmartOnline SU1000RTXL2U Guía de configuración

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SU1000RTXL2U

Smart Online Expandable Rack / Tower UPS System - Online, double-conversion protection for mission

critical applications

Highlights

1000VA online 2U expandable rack/tower UPS

Enhanced serial communications port and SNMP/Web card slot

Maintains 120V +/-2% output during overvoltages to 138V and brownouts as low as 65V

2 load banks, 6 outlets

Fault tolerant auto-bypass

$250,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's Smart Online SU1000RTXL2U online, double conversion UPS protects critical server, networking and telecommunications equipment

from blackouts, voltage fluctuations and transient surges. Multi-use form factor occupies only 2 rack spaces (2U) in standard 19 inch rackmount

configuration and includes tower stands to support upright placement. Large capacity 1kVA/800 watt UPS continuously converts incoming AC to

DC, then back to perfect sine wave AC output at 120V AC (+/-2%). Removes harmonic distortion, fast electrical impulses, frequency fluctuations and

other hard-to-solve power problems not addressed by other UPS types. True sine wave output and zero transfer time offers guaranteed compatibility

with all equipment types. Includes 6 outlets arranged in two individually switchable load banks that can be independently controlled via software

interface to selectively reboot remote equipment, or shed less critical loads to extend battery runtime for more critical equipment. Battery support can

be extended indefinitely through the addition of external 2U rackmount battery packs (part# BP36V142U). Includes slot for internal SNMP/web card,

plus DB9 enhanced serial monitoring port for unattended shutdown, remote control and monitoring of UPS system and power data. Compatible with

Tripp Lite's Watchdog system service software.

Applications

Ideal for protection of critical 120v equipment in server rooms, internetworking closets and telecommunications systems in rackmount or

tower applications. Common applications include corporate or departmental servers, workstations, hubs, routers, bridges, CAD/CAM

workstations, concentrators, IP telephony and traditional PBX switching systems.

Package Includes

SU1000RTXL2U Online Double-Conversion UPS System

PowerAlert Software and cabling

Mounting hardware for 4 post rack enclosures, tower stands

Instruction manual with warranty information

Features

True online, double conversion UPS provides pure, sine wave AC output at all times

Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time

Removes harmonic distortion, electrical impulses, frequency variations and other hard to solve power problems

Accepts input voltages between 80 and 138 (65 to 138 at loads under 70%), regulating output to 120v +/-2%

1000VA/800 watt power capacity with 6 NEMA 5-15R outlets

Standard internal battery set provides 18 minutes runtime at half load

Expandable runtime with multiple external battery packs (part# BP36V142U)

Innovative design makes unit adaptable for rackmount or tower applications

Uses only 2 rack spaces (2U) in standard 19 inch rack

Fault tolerant auto-bypass maintians continuous utility output to connected equipment, even in cases where the UPS is overloaded or

suffers an internal failure that requires service

DB9 serial port for network interface; SNMP compatible

Slot for optional SNMP/web card (part# SNMPWEBCARD)

PowerAlert unattended shutdown software and 6 ft. network cable included

Compatible with Tripp Lite's Watchdog system service software

Diagnostic LEDs

Battery replacement door

Mounting hardware included for 4 post rack enclosures, 2 post telecom rack compatible with separate purchase 2POSTRMKIT accessory

2 year manufacturers product warranty

$250,000 Ultimate Lifetime connected equipment insurance

Specifications

OUTPUT

Frequency

compatibility

50 / 60 Hz

Output VA 1000

Output watts 800

Output nominal

voltage

120V AC

Output voltage

regulation

Maintains full-time sine wave output within 2% of 120V, less than 5% total harmonic distortion

Output frequency

regulation

Regulates line frequency to 50/60Hz +/- 0.05Hz

Overload protection 15A input breaker

Outlet quantity /

type

6 NEMA 5-15R

Customized load

management

receptacles

"2 individually controllable load banks support automated load shedding and remote reboot on demand of locked

network devices. Configurable via PowerAlert software to automatically switch off optional loads, like monitors, to

increase available runtime for servers and other critical devices. (bank A consists of 4 outlets / bank B consists of 2

outlets)"

INPUT

UPS Input cord

length (ft.)

6 ft. 14 gauge

Recommended

Electrical Service

15A 120V

Maximum Input

Amps (A)

8.6

Maximum Input

Watts

955

Input connection

type

NEMA 5-15P

Voltage

compatibility (VAC)

120

BATTERY

Expandable battery

runtime

Supports extended runtime with optional external battery pack BP36V142u (multi-pack compatible)

DC system voltage

(VDC)

Battery Access User replaceable, hot swap battery replacement supported via front access panel

Full load runtime Internal batteries — 6 min.

1 BP36V142U battery pack (1000VA) — 37 min.

Half load runtime Internal batteries — 18 min.

1 BP36V142U battery pack (500VA) — 89 min.

Battery Pack

Accessory

(optional)

BP36V142U (optional)

Typical battery

lifespan

3-6 years, depending on usage

Battery recharge

rate

2-4 hours to 90%

VOLTAGE REGULATION

Voltage regulation

description

On-line, double-conversion power conditioning maintains output within 2% of 120 volts at all times

Overvoltage

correction

Maintains output of 120V +/-2% during overvoltages to 138V AC

Brownout

correction

Maintains output of 120V +/-2% during undervoltages to 80V AC

Severe brownout

correction

At load levels less than 70%, UPS maintains output of 120V +/-2% during undervoltages to 65V AC

LEDS ALARMS & SWITCHES

Alarms Multi-function audible alarm offers notification of UPS start, backup operation, low battery warning, overload, UPS fault

and remote shutdown

Switches Includes main power off/on switch, plus 1 switch to select battery charge / load level display

Front panel LEDs 6 LED STATUS DISPLAY: line power (green), online (green), bypass (yellow), on battery (green), overload (red),

battery low (yellow)

4 LED LOAD / BATTERY LEVEL DISPLAY (100%, 75%, 50%, 25%)

SURGE / NOISE SUPPRESSION

UPS AC

suppression joule

rating

480 joules

EMI / RFI AC noise

suppression

Yes

AC suppression

response time

Instantaneous

PHYSICAL

Shipping weight

(lbs)

Shipping weight

(kg)

28.1

Unit Dimensions

(HWD/in)

3.5 x 17.5 x 18.5

Unit Dimensions

(HWD/cm)

8.89 x 44.5 x 47

Unit weight (lbs) 41

Unit weight (kg) 18.6

Cooling method Built-in cooling fan

Material of

construction

Steel

Form factors

supported

Supports 2U rackmount installation in 4 post rack enclosures. 2 post rackmount installation supported with optional

2POSTRMKIT. Upright tower installation supported with included tower stands

ENVIRONMENTAL

Relative Humidity 0 to 95%, non-condensing

COMMUNICATIONS

WatchDog

compatibility

Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft

reboot of application / OS or hard power off/on reboot of connected equipment—ideal for unattended kiosk applications

Network

monitoring port

Built-in DB9 port offers both enhanced RS-232 enable monitoring data, plus contact closure monitoring ability

EPO port Supports "Emergency Power Off" via special-order cabling, contact Tripp Lite for more information

SNMP compatibility Yes, includes slot for optional SNMPWEBCARD accessory (#SNMPWEBCARD)

Software and

cabling included

Yes, includes PowerAlert software CD-ROM and complete cabling

LINE / BATTERY TRANSFER

Transfer time from

line power to

battery mode

Zero, online UPS continuously converts incoming AC to DC, then back to AC. When commercial power is interrupted,

UPS maintains continuous output from battery reserves with absolutely no disruption in output AC power.

Low voltage

transfer to battery

power

Maintains continuous operation during undervoltages as low as 80V (65V at load levels under 70%). Below this

switchover point, output is supported from battery derived AC power.

High voltage

transfer to battery

power

Maintains continuous operation without using battery power during overvoltages to 138V. Above this point, output is

supported from battery derived AC power.

SPECIAL FEATURES

Appearance Attractive black steel rackmount housing

Cold Start Yes, inverter can be "cold started" to enable temporary AC output during a power failure

CERTIFICATIONS

Certifications Tested to UL1778 (USA), cUL (Canada), FCC Class A (emissions), NOM (Mexico)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Optional Coverage 3-5 year warranties, plus next day and on-site warranty coverage available for select opportunities. Contact Tripp Lite

for additional information.

Connected

Equipment

Insurance (U.S.,

Canada & Puerto

Rico)

$250,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2547.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
