TRENDnet TV-IP430PI Manual de usuario

TV-IP430PI

ŸOutdoor 2 MP Full HD 1080p PoE+ IR Mini Speed Dome Network Camera

ŸQuick Installation Guide (1)

TV-IP430PI (V1) / 02.27.2015

1. Before You Start

1

Package Contents

Minimum Requirements

Supported Operating Systems

Android (version 2.3 and higher)

iOS (version 6.1 and higher)

TRENDnetVIEW Mobile App Requirements

ŸTV-IP430PI

ŸCD-ROM (Utility and User's Guide)

ŸQuick Installation Guide

ŸTV-HC400, TV-HW400, TV-HP400, or TV-HN400 mounting bracket (sold separately)

ŸPower over Ethernet + (PoE+) switch or injector

ŸComputer with Ethernet port and web browser

ŸCD-ROM drive

ŸWired network

ŸNetwork cable

Note:

The TV-IP430PI camera works with Power over Ethernet+ (PoE+) devices that follow the IEEE

802.3at standard.

2

2. Hardware Installation and Configuration

1. Do not install or mount the camera until you complete the installation steps below. Next to your

computer, temporarily place the IP camera in the provided protective foam insert with the dome

facing up.

2. Connect a network cable from your computer to a LAN port on your network.

3. Insert the included CD-ROM into your computer.

4. Select language from the drop down menu.

5. Select Install Camera.

6. Write down the MAC address of your camera. Then click Next.

Note: To download the latest version of the Setup Wizard, please go to

http://www.trendnet.com/support and select the TV-IP430PI from the products downloads page

dropdown menu.

3

7. Connect a network cable to the camera's network port and to your PoE+ Switch. The IR LEDs

will turn on and show a dim red light. The camera will begin the self checking sequencing.

Allow 60 seconds for the camera to complete calibration. Then click Next.

8. Select your camera, then click Next.

9. Select DHCP and then click Next.

4

10. Select the Change Password box. Enter a new password, confirm the spelling, and click

Next.

11. The initial setup is now complete. Your camera is now connected to your network. Click the

hyperlink to confirm access to the management page. This will open up a web browser. You

will need to download and install a plug-in to view video. Please refer to the Install Web

Browser Plug-in for Camera Management Interface section for instruction. To resume

installation, minimize the web browser and then click Next.

12. Congratulations! Your camera is now ready to be physically installed. Scan the QR code to

download a free mobile app to view the camera from your mobile device. Click Finish to exit

the installation wizard.

5

Note:

ŸSee User's Guide for advanced management functions.

ŸTwo User's Guides are included – one for the camera and one for TRENDnetVIEW Pro

software.

ŸWhen viewing live video from a web browser, you will be prompted to install plug-ins for full

functionality.

ŸIt is recommended that you setup a dynamic DNS service in order to view your cameras

remotely. See your router and IP camera user's guide for instructions.

ŸInstall the camera in your desired location. For mounting instructions, please refer to the

mounting installation guide.

13. To manage multiple cameras and for more advanced features, please install the

TRENDnetVIEW Pro software. From the CD-ROM autorun menu, select Install

TRENDnetVIEW Pro Software to begin installation. Refer to the User's Guide on the CD for

more information.

6

Install Web Browser Plug-in for Camera Management Interface

Windows

1. Access the camera management interface.

2. Enter your username and password. Then press Login.

3. Click on the link to download the plug-in.

4. When prompted to, click Run.

7

5. Click Next.

6. Click Finish.

7. Refresh your browser to view the video.

8

Mac OS X

1. Access the camera management interface.

2. Enter your username and password. Then press Log In.

3. Click on the link to download the plug-in.

4. Double click on the WebComponents.pkg file.

9

6. Click Continue.

7. Click Install.5. Click Continue.

9. Click Close.

8. Enter your computer's Username and

Password. Then click Install Software.
