TP-Link TL-WA901ND Manual de usuario
7106507509 REV1.1.0
TP-Link Technologies Co., Ltd.
Specifications are subject to change without notice. is a registered trademark of TP-Link
Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of
their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from
TP-Link Technologies Co., Ltd. Copyright © 2017 TP-Link Technologies Co., Ltd. All rights reserved.
www.tp-link.com
Quick Installation Guide
Wireless N Access Point
CONTENTS
01 / English
06 / Български
11 / Čeština
16 / Eesti
21 / Қазақша
26 / Latviešu
31 / Lietuvių
36 / Magyar
41 / Polski
46 / Русский язык
51 / Română
56 / Slovenčina
61 / Srpski jezik/Српски језик
66 / Українська мова
1
English
Note: TL-WA901ND is used for demonstration in this installation guide.
Before You Start
Which mode do you need? Please refer to the table to choose a proper mode.
Scenarios Operating Modes
You want to convert your wired (Ethernet) network to a wireless network. Access Point Mode (Default Mode)
You are in a Wi-Fi dead-zone or a place with weak wireless signal. You
want to have a greater eective range of the wireless signal throughout
your home or oce.
Repeater (Range Extender) Mode
You want to link multiple local networks to the same network using
wireless connections where physical wires are inconvenient (when
connecting networks in dierent oce buildings, for example).
Bridge with AP Mode
You have a wired device with an Ethernet port and no wireless capability,
for example, a Smart TV, Media Player, or game console. You want to
connect it to the Internet wirelessly.
Client Mode
You want your devices connected to different wireless networks and
isolated by VLANs. Multi-SSID Mode
Connect the AP Device
1. Connect the AP device according to steps in the diagram.
2. Turn on the power, wait until the Power ( ) and Wireless ( ) LEDs are lit and stable, and use the
default SSID and Password printed on the product label to join the AP device’s Wi-Fi network.
2
English
• Access Point Mode (Default)
A
B
C
D
Note: You can enjoy internet surng now. For your wireless network security, it is recommended to change the default SSID (network name)
and the password of your Wi-Fi network. To do so, refer to Congure the AP Device.
• Repeater/Bridge with AP
A
B
Internet
Wired Router
Transforms your existing wired network to a wireless one.
TL-WA901ND's SSID
Extends the range of an existing Wi-Fi network.
Internet TL-WA901ND's SSID
3
English
• Client Mode
CAB
D
• Multi-SSID Mode
A
B
C
D
Connects your wired devices to a wireless network.
Internet Host AP's SSID
Creates multiple wireless networks to provide dierent security and VLAN groups.
Internet VLAN1
VLAN2
4
English
Congure the AP Device
1. Launch a web browser and enter http://tplinkap.net. Then log in using admin (all lowercase) for both
Username and Password.
2. Click Quick Setup, select your corresponding mode and click Next. Follow the step-by-step
instructions to complete the conguration.
3. Now, reconnect your devices to the AP device.
Note: In Repeater mode, the AP device’s SSID is the same as your Host AP’s.
In Client mode, only the wired connected devices can enjoy the internet surng.
In Multi-SSID mode, connect your wireless devices to the dierent Wi-Fi networks to be isolated by VLANs.
Power on via PoE Injector
Power the device with the included passive PoE injector when the device is located far from a power outlet.
Note: The passive PoE injector supports a cable length up to 30 meters due to the environment.
Internet
Passive PoE Injector
TL-WA901ND’s SSID
5
English
Frequently Asked Questions (FAQ)
Q1. How do I restore the AP device to its factory default settings?
With the device powered on, use a pin to press and hold the Reset button until the Power LED starts blinking, then
release the button.
Note: Upon resetting, all previous congurations will be cleared, and the AP device will reset to the default Access Point Mode.
Q2. What can I do if the login window does not appear?
• Change the computer's static IP address to obtain an IP address automatically.
• Verify if http://tplinkap.net or http://192.168.0.254 is correctly entered in the web browser.
• Use another web browser and try again.
• Reboot your AP device and try again.
• Power o your host AP and enter http://tplinkap.net into the web browser to try again.
Q3. How do I recover the AP device’s web management password or retrieve my Wi-Fi password?
• If you forget the password required to access the AP device's web management page, you must restore the AP
device to its factory default settings.
• If your forget your Wi-Fi password, but are able to access the AP device's management interface, connect a
computer or mobile device to the AP device via wired or wireless. Log in and go to Wireless > Wireless Security to
retrieve or reset your Wi-Fi password.
Q4. What can I do if my wireless is not stable?
It may be caused by too much interference, you can try the following methods:
• Set your wireless channel to a dierent one.
• Move the AP device to a new location away from Bluetooth devices and other household electronics, such as
cordless phone, microwave, and baby monitor and more, to minimize signal interference.
6
Български
Забележка: TL-WA901ND се използва за демонстрация в това ръководство за инсталация.
Преди да започнете
От кой режим имате нужда? Моля, вижте таблицата, за да изберете подходящия режим.
Сценарии Режими на работа
Искате да превърнете вашата кабелна (Ethernet) мрежа в безжична мрежа. Режим "Точка за достъп" (режим по
подразбиране)
Вие сте в т.нар. "мъртва Wi-Fi зона", или на място със слаб сигнал. Желаете
да имате по-ефективен обхват на безжичния сигнал в целия ваш дом или
офис.
Режим "Повторител" (Удължител на
обхват)
Искате да свържете множество локални мрежи към същата мрежа,
използвайки безжични връзки там, където физическите кабелни връзки са
неудобни (например, при свързване на мрежи в различни офис сгради).
Мост с режим "Точка за достъп"
Имате кабелно свързано устройство с Ethernet порт, без възможност
за безжична връзка, например интелигентен телевизор (Smart TV),
мултимедиен плейър, или игрална конзола. Искате да ги свържете към
интернет безжично.
Клиентски режим
Искате вашите устройства да бъдат свързани към различни безжични
мрежи и да са изолирани с VLAN мрежи. Режим Мулти-SSID
Свързване на устройство Точка за достъп
1. Свържете Точката за достъп съгласно стъпките в схемата.
2. Включете захранването, почакайте, докато светодиодите Power (Захранване) ( ) и Wireless (Безжична връзка) ( ) светнат
стабилно, и използвайте името на мрежата (SSID) и паролата намиращи се на етикета на устройството, за да се свържете към
Wi-Fi мрежата на Точката за достъп.
7
Български
• Режим "Точка за достъп" (по подразбиране)
A
B
C
D
Забележка: Сега можете да се наслаждавате на сърфиране в интернет. За сигурността на вашата безжична мрежа се препоръчва да смените поставените
по подразбиране SSID (името на мрежата) и паролата на вашата Wi-Fi мрежа. За целта, вижте Конфигуриране на Точка за достъп.
• Repeater/Bridge with AP
A
B
Интернет
Кабелен рутер
Превръща вашата съществуваща кабелна мрежа в безжична.
Име (SSID) на TL-WA901ND
Разширява обхвата на съществуващата Wi-Fi мрежа
Интернет Име (SSID) на TL-WA901ND
8
Български
• Режим Клиент
CAB
D
• Режим Мулти-SSID
A
B
C
D
Свързва вашите кабелни устройства към безжична мрежа.
Интернет Име (SSID) на Точката
за достъп на хоста
Създава множество безжични мрежи за предоставяне на различна степен на сигурност и VLAN групи.
Интернет VLAN1
VLAN2
