TP-Link Auranet EAP110 Manual de usuario

Installation Guide

Indoor Access Point

CONTENTS

English ��01

Български��07

Čeština��13

Қазақша��19

Lietuvių��25

Magyar��31

Polski��37

Русский язык ��43

Română��49

Slovenčina��55

Srpski jezik ��61

Українська мова��67

English

Note: The image may differ from the actual product�

Network Topology

■For the EAP

A typical network topology for the EAP is shown below�

EAP Controller

A computer running the EAP Controller software, which can be in the same or

different subnet with the EAPs, is used to centrally manage the EAPs�

You can get the EAP Controller software from our website http://www�tp-link�com�

■For the CAP (FIT Mode)

A typical network topology for the CAP is shown below.

The wireless controller can be in the same or different subnet with the CAPs�

And the management host is used to log in to the wireless controller to centrally

manage the CAPs�

Controller Host

Router Switch

Internet

Clients

EAP

Router Switch

Internet

Clients

CAP

Management Host

Wireless Controller

English

Hardware Installation

■Option1: Ceiling Rail Mounting

The ceiling rail mounting is only for the devices with the following accessories�

Follow the steps below to install the EAP/CAP with the provided accessories:

1Position the Ceiling T-rail Clip and push the

movable part toward the rail base�

2Use an M3×6 pan-head screw to secure the T-rail

Clip onto the ceiling rail�

3Attach the mounting bracket to the Ceiling T-rail

Clip using four M3x6 pan-head screws�

Ceiling T-rail Clip M3×6 Pan-head Screws (Qty.5)

English

4Attach the EAP/CAP to the mounting bracket by

aligning ARROW 1 (on the EAP/CAP) with ARROW

2 (on the mounting bracket), then rotate the EAP/

CAP clockwise until it locks into place�

5Connect the Ethernet cable to the ETHERNET

port�

■Option2: Ceiling Mounting

Follow the steps below to install the EAP/CAP with the provided accessories:

1Remove the ceiling tile�

2Place the mounting bracket in the center of the

ceiling tile� Mark three positions for the screw

holes and a position for the Ethernet cable hole�

Drill three 4mm diameter holes for the screws

and a 25mm diameter hole for the Ethernet

cable at the marked positions�

Washers

(Qty.3)

M3×30 Pan-head Screws

(Qty.3)

Wing Nuts

(Qty.3)

Hole for Ethernet cable

English

3Secure the mounting bracket to the ceiling tile

using three M3x30 pan-head screws, washers

and wing nuts�

4Feed the Ethernet cable through the hole and

set the ceiling tile back into place�

5Connect the Ethernet cable to the ETHERNET

port� Attach the EAP/CAP to the mounting

bracket by aligning the arrow mark on the EAP/

CAP with the arrow mark on the mounting

bracket, then rotate the EAP/CAP until it is

locked into place�

■Option3: Wall Mounting

Follow the steps below to install the EAP/CAP with the provided accessories:

M3×28 Plastic Wall Anchors

(Qty.3)

M3×20 Self-tapping Screws

(Qty.3)

English

1If your Ethernet cable feeds through the wall,

you can position the mounting bracket to make

the cable through the fixing hole� Mark three

positions for the screw holes and then drill three

6mm diameter holes at the marked positions�

2Insert the plastic wall anchors into the 6mm

diameter holes�

3Secure the mounting bracket to the wall by

driving the self-tapping screws into the anchors�

Make sure that the shoulders of the mounting

bracket are on the outside�

4Connect the Ethernet cable to the ETHERNET

port on the EAP/CAP�

5Attach the EAP/CAP to the mounting bracket by

aligning the arrow mark on the EAP/CAP with the

arrow mark on the mounting bracket, then rotate

the EAP/CAP until it is locked into place�

English

Power Supply

■Power via PSE Device or Power Adapter

If the product is provided with a power adapter, power the device via a PSE device

(such as a PoE switch) or the power adapter�

Via PoE Switch

Via Power Adapter

■Power via PoE Adapter

If the product is provided with a POE adapter, power the device via the POE

adapter�

PoE LAN

PoE Adapter

(Up to 100m)

Switch

Power Adapter

PoE Switch

Български

Забележка: Действителният продукт може да се различава от показания тук.

Мрежова топология

■ За ЕАР

Типична мрежова топология за ЕАР е показана по-долу.

EAP Controller

Един компютър, на който работи софтуера на EAP Контролера, който може

да бъде в същата или различна мрежа с EAP устройствата, се използва, за да

управлява централно ЕАР устройствата.

Можете да вземете софтуера на EAP Контролера от нашия уебсайт http://www.

tp-link�com�

■ За CAP (FIT режим)

Типична мрежова топология за CAP е показана по-долу.

Безжичният контролер може да бъде в същата или различна подмрежа с

CAP устройствата. Хост компютърът за управление се използва за влизане в

безжичния контролер, за централно управление на CAP устройствата.

Хост на Контролера

Рутер Комутатор

Интернет

Клиенти

EAP

Рутер Комутатор

Интернет

Клиенти

CAP

Хост компютър за управление

Безжичен контролер

Български

Инсталиране на хардуера

■ Вариант 1: Монтаж на релса на тавана

Монтажът на релса на тавана се използва само за устройствата със следните

аксесоари. Следвайте описаните по-долу стъпки, за да инсталирате EAP/CAP

устройствата с доставените аксесоари:

1Разположете Т-релсовия клип и натиснете

подвижната част напред към релсовата

основа.

2С един M3×6 винт закрепете Т-релсовия клип

към релсата на тавана.

3Закрепете монтажната скоба към Т-релсовия

клип с четири M3x6 винтове тип звезда.

T-релсов клип за монтаж на тавана M3×6 винтове тип звезда (5 бр.)
