Totally Wicked PENGUIN Manual de usuario

USER MANUAL / BEDIENUNGSANLEITUNG

CONGRATULATIONS ON PURCHASING YOUR

TOTALLY WICKED PENGUIN

ELECTRONIC CIGARETTE KIT.

The Totally Wicked Penguin

Mouthpiece

Airﬂow Inlet

Power Button

Indicator Lights

Micro-USB Port

Penguin Battery

Mouthpiece

Sleeve

Filling with E-liquid:

To ﬁll, grasp the mouthpiece ﬁrmly

and pull the atopack assembly

loose from main body, place the

main body to one side. Take hold

of the atopack assembly and rotate

it upside down, use a ﬁnger to pry

the white ceramic atomizer from the

atopack assembly. Carefully ﬁll with

E-liquid down the central, oblong

reﬁll hole, avoid the airﬂow opening

to the side. Once ﬁlled, reinsert

the ceramic atomizer back into the

atopack assembly, then reinsert the

entire atopack assembly back into

the main body.

Note: Be sure to “prime” the

atomizer head by allowing it to

sit in a tank full of E-liquid for

ﬁve minutes before vaping, this

ensures the atomizer head is fully

saturated with E-liquid.

Using your Penguin

Atopack Ceramic

atomizer

Filling

hole

Using your Penguin

Power On and Off:

To switch the Penguin on, press

the power button ﬁve times in quick

succession, the indicator lights will

ﬂash ﬁve times to show the Penguin

has been switched on. Similarly,

when the device is powered on,

press the power button ﬁve times in

quick succession to turn the Penguin

off, the indicator lights will ﬂash ﬁve

times to show the Penguin has been

switched off.

Vaping:

Press and hold the power button as

you inhale the vapour, ﬁve indicator

lights will illuminate while the device

is being vaped.

Using your Penguin

Charging the Battery:

The Penguin is recharged by

inserting the micro USB cable into

the micro USB port located beneath

the power button, insert the other

end of the USB cable into a powered

USB port or suitable USB adaptor.

The indicator lights will initially ﬂash

ﬁve times simultaneously when the

charge lead is ﬁrst inserted, then

repeatedly ﬂash in sequence until

the battery is fully charged. Once

fully charged, the indicator lights will

turn off completely. Charging with a

QC2.0 Wall Adaptor will be around

30% faster than charging with a

standard 1.0A USB adaptor.

Installing/Replacing an Atomizer

Head:

To install a new atomizer head,

grasp the mouthpiece ﬁrmly and

pull the entire atopack assembly

loose from main body, place the

main body to one side. Take hold of

the atopack assembly and rotate it

upside down, then, use a ﬁnger to

pry the ceramic atomizer head from

the atopack assembly. Dispose of

the old atomizer head then insert a

brand new atomizer head into the

atopack assembly. Then, reinsert the

entire atopack assembly back into

the main body.

Note: Be sure let the new atomizer

head sit in a tank full of E-liquid

for ﬁve minutes before vaping to

ensure the atomizer head is fully

saturated with E-liquid.

Using your Penguin

Battery Charge Level Light Condition

90 – 100%

70 – 89%

30 – 69%

10 – 29%

0 – 9%

Using your Penguin

Battery Life Indication:

As the level of charge changes the number of indicator lights which are

illuminated will change. The table below can be used as a reference.

Using your Penguin

Short Circuit Protection:

If an atomizer short circuit occurs

before the power button is pressed,

the indicator lights will ﬂash ﬁve

times in succession. If an atomizer

short circuit occurs while the power

button is pressed, the indicator lights

will ﬂash three times in succession.

Atomizer Protection:

If the power button is pressed

for longer than ten seconds, the

Penguin will cease to function and

the indicator lights will ﬂash ten

times.

Low Voltage Protection:

When the battery voltage drops

below 3.3V, the indicator lights will

ﬂash forty times and the device will

power off. Charge the device via

USB to resume normal operation.
