USER MANUAL

ELECTRONIC CIGARETTE KIT

TOTALLY WICKED RIVAL

ELECTRONIC CIGARETTE

CONGRATULATIONS ON PURCHASING YOUR THE TOTALLY WICKED RIVAL

Tank connection Mouthpiece

Tank glass

Atomizer head

Tank base

Display screen

USB port

Adjustment buttons

Power button

• Prime the atomizer head.

• Fill the tank.

• Switch the Rival on (5 clicks of the power button).

• The Rival will automatically set to 15 watts.

• Press and hold the power button and inhale.

• Charge the battery (possibly not shipped with a full charge).

Detailed descriptions of these steps and more

are given in the following pages of this manual.

If you are familiar with

using e-cigarettes,

follow the quick start

guide to be vaping in

minutes.

4 5

PRIMING THE ATOMIZER HEAD PRIMING THE ATOMIZER HEAD

It is important to “prime” a new atomizer

head before ﬁrst use. Failure to do so

can cause the atomizer coil to overheat,

resulting in a burnt taste and sometimes

irreversible damage to the atomizer head

requiring early replacement.

Unscrew and remove the tank from the

battery and invert. Unscrew the base of

the tank, grip the atomizer head by its

connector, and remove it from the tank

by pulling straight out. Prime the atomizer

head by dripping a few drops of E-liquid

into the central hole of the atomizer head.

After priming the atomizer head, insert it

back into the tank, screw the base back on,

and screw the tank back onto the battery.

6 7

FILLING THE TANK USING YOUR RIVAL

Slide the top cap open by pushing ﬁrmly

in the direction indicated by the arrow on

the top cap to expose the ﬁll hole. Insert

the ﬁlling nozzle into the ﬁll hole and ﬁll the

tank, being careful to leave an air gap of

approximately 2mm. Slide the top cap shut

after ﬁlling.

Note: After priming a new atomizer

head and ﬁlling the tank with e-liquid,

it is recommended to wait 5 minutes

to ensure the atomizer head is fully

saturated with e-liquid.

Atomizer Head Lifespan

Atomizer heads do not last forever and

need to be periodically replaced. The

lifespan of an atomizer head can vary

from several days up to several weeks.

Factors affecting lifespan include wattage,

vaping style, ﬂavour and type of e-liquid.

Indicators that the atomizer head may

require replacement include a slight burnt

taste, general loss of vapour production or

a reduction in ﬂavour intensity.

Switching On and Off

Switch the Rival on by quickly pressing

the power button ﬁve times, the screen

will display “RIVAL BY TOTALLY WICKED”

indicating the Rival has been switched

on. Quickly press the power button ﬁve

times to switch the Rival off, the screen

will display “SLEEP MODE” indicating the

device has been switched off.

8 9

USING YOUR RIVAL USING YOUR RIVAL

Setting the Wattage

The Rival has adjustable wattage that can

be set from 1 – 60 watts. Use the left or

right adjustment buttons to increase or

decrease the wattage on the battery. The

ﬁtted atomizer head can be used from 8-16

watts. For the best balance of ﬂavour and

vapour production we suggest a starting

point of 8 watts, which you can then adjust

in small increments to ﬁnd your favourite

setting.

Vaping

Press and hold the power button as you

inhale the vapour, the LED surrounding the

button will light up while the power button

is held down.

Adjusting Airﬂow

If you ﬁnd the air ﬂow too airy or too tight

while vaping, rotate the airﬂow control ring

located on the tank base. Experiment by

rotating the air ﬂow control ring to ﬁnd your

preferred setting.

E-liquid Level

To prevent the atomizer head from

becoming dry and burning prematurely,

ensure the amount of e-liquid inside the

Rival tank does not drop below the ﬂuid

feed holes located on the sides of the

atomizer head.

Charging the Battery

The Totally Wicked Rival is charged by

connecting the charge port on the battery

to a USB port or suitable wall adaptor with

the supplied charging lead. The battery

icon will begin to ﬂash onscreen for 15

seconds, after which the screen will switch

off. The LED surrounding the button will

start to ﬂash in 5 second intervals with a 1

second break between ﬂashes. Once fully

charged the LED surrounding the button

will stay illuminated until taken off charge.

10 11

USING YOUR RIVAL ONSCREEN MESSAGES

Battery Life Indicator

In addition to the on screen battery life

indicator, battery life is also indicated by

the colour of the LED that is illuminated

around the power button, as described in

the following table.

Replacing the Atomizer Head

To install a new atomizer head follow the

process shown in the “Priming the atomizer

head”.

Reminder: After priming a new atomizer

head and ﬁlling the tank with e-liquid,

it is recommended to wait 5 minutes

to ensure the atomizer head is fully

saturated with e-liquid.

Atomizer Head Protection

If the power button is held down for longer

than 10 seconds while vaping, the screen

will display “OVER TIME” and the Rival

will not continue to power the atomizer

or produce any vapour. Releasing the

power button will allow normal operation

to resume.

Low Battery

If “LOW BATTERY” is displayed onscreen,

this indicates the Rival has insufﬁcient

battery voltage to deliver the currently

selected wattage; the LED surrounding the

button will ﬂash 4 times. Charge the battery

using the steps outlined in “Charging

the Battery” to allow normal operation to

resume.

Battery Level LED Condition

100%-60% Glows WHITE for 3 seconds

59%-21% Glows BLUE for 3 seconds

20%-0% Glows RED for 3 seconds

12 13

ADDITIONAL SETTINGS PROTECTIONS

Locked Mode

Locked mode prevents accidental ﬁring

of the Rival. If Locked mode is enabled,

the screen will display “Locked” whenever

any button is pressed. Pressing any button

on the Rival won’t have any effect until

“Locked Mode” is disabled.

To turn “Locked Mode” on/off, ensure the

Rival is switched on, then press and hold

down both adjustment buttons at the same

time; the screen will display “Locked” when

enabled. Repeat the process to disable

locked mode; the screen will display

“Unlocked” when disabled.

Automatic Wattage

The Totally Wicked Rival is equipped with

an “automatic wattage” feature. This feature

allows the device to automatically set the

wattage when connecting a new atomizer.

For example, when using the 1.5ohm

atomizer which comes ﬁtted in the tank,

the Rival will automatically set the power

to 15W.

Short Circuit Protection

If an atomizer short circuit occurs, the

screen will display “SHORT”, the Rival

will not provide power to the atomizer

or produce any vapour and the LED

surrounding the button will ﬂash red 4

times. Replacing the atomizer head should

allow normal operation to resume. To

replace the atomizer head follow the steps

outlined in “Replacing the atomizer head”.

No Atomizer Detected Protection

If no atomizer is detected, the screen

will display “No Atomizer” and the Rival

will not provide power to the atomizer or

produce any vapour, the LED surrounding

the button will ﬂash blue 4 times. Ensure

the atomizer head is fully pushed into the

base of the tank, then ﬁt the tank back onto

the battery. If the “No Atomizer” message

continues, replacing the atomizer head

should allow normal operation to resume.

Follow the steps outlined in “Replacing the

atomizer head”.

14 15

CLEANING AND MAINTENANCE SPECIFICATIONS

The Totally Wicked Rival battery can be

cleaned by wiping down with tissue or a

dry cloth. The Rival tank can be cleaned by

removing it from the battery, unscrewing

the tank base from the glass section of the

tank then removing the atomizer head.

The entire Rival tank and base can now be

cleaned under hot running water. Allow the

tank to fully dry before reﬁtting the atomizer

head into the tank base. Reassemble the

tank.

Note: Do not attempt to clean the

atomizer head with water. Do not

submerge the Rival battery unit in water

or allow it to get wet.

Additional Product Information

There are no reported medical side effects

with this product. If you believe you

experience a side effect, please contact the

manufacturer.

Rival Battery

Dimensions: 66mm (height) x 50.7mm

(width) x 31mm (depth)

Weight: 143g

Battery Capacity: 3200mAh

Wattage Range: 1 – 60W

Voltage Range: 1.0 – 8.5V

Maximum Charge Current: 2.0A

Maximum Tank Diameter: 25mm

Thread Type: Spring Loaded 510

Connection

Atomizer Resistance Compatibility:

0.15ohm – 3.0ohm

Rival Tank

Dimensions: 22mm (diameter) x 34mm

(height)

Weight: 33g

Tank Capacity: 2.0ml

Atomizer Type: SW

Thread Type: 510 Connection

Atomizer Head Resistance:1.5ohm

Airﬂow Type: Bottom – Bottom, adjustable

Maximum Reﬁll Nozzle Diameter: 3.7mm

16 17

PRODUCT STORAGE AND BATTERY PRECAUTIONS WARRANTY KIT CONTENTS

• Store the Rival e-cigarette and its accessories away from children whilst not in use.

• Please only use the charging cable provided.

• Please dispose of dead batteries in accordance with your country’s appropriate legislation.

• Do not charge the battery in a damp environment, or in temperatures under 0°C or above

45°C.

• Do not use the device in temperatures under -10°C or above 60°C.

• Do not carry batteries in a pocket or bag with other metallic objects.

• Do not attempt to repair a faulty Rival battery as these are sealed units with no serviceable

parts. Attempted repairs will void the warranty.

Totally Wicked Rival components have a

28-day parts warranty with the exception

of atomizer heads which are consumable

items and are covered by our ‘Dead on

Arrival’ warranty only. The USB cable

supplied has a 12-month warranty. If any

parts are found to be faulty within this

time please contact our customer service

team, whose details are on the back page

of this booklet and we will arrange for a

replacement. We may require the goods to

be returned for further investigation.

1 x Rival battery

1 x Rival tank

1 x Spare glass

1 x SW 1.5ohm atomizer head (ﬁtted)

1 x SW 0.8ohm atomizer head (spare)

1 x User manual

1 x Spare parts set

18 19

Tabla de contenidos

Otros manuales de Cigarrillo electrónico de Totally Wicked

Totally Wicked

Totally Wicked arc pico Manual de usuario

Totally Wicked

Totally Wicked e-lectron-L Manual de usuario

Totally Wicked

Totally Wicked Corsa Mini Manual de usuario

Totally Wicked

Totally Wicked Odyssey Pipe Manual de usuario

Totally Wicked

Totally Wicked Forza 75 Manual de usuario

Totally Wicked

Totally Wicked Revolution S Manual de usuario

Totally Wicked

Totally Wicked TORNADO EX Manual de usuario

Totally Wicked

Totally Wicked MAG-OID Manual de usuario

Totally Wicked

Totally Wicked Tornado eGo-C+ Manual de usuario

Totally Wicked

Totally Wicked Corsa Manual de usuario

Totally Wicked

Totally Wicked Skope S Manual de usuario

Totally Wicked

Totally Wicked eGo-C+ Manual de usuario

Totally Wicked

Totally Wicked ARC MINI Manual de usuario

Totally Wicked

Totally Wicked Active Manual de usuario

Totally Wicked

Totally Wicked Skope P Manual de usuario

Totally Wicked

Totally Wicked aio2 Manual de usuario

Totally Wicked

Totally Wicked aio Slider Hellfire Manual de usuario

Totally Wicked

Totally Wicked Curve Lite Manual de usuario

Totally Wicked

Totally Wicked Tornado-T Manual de usuario

Totally Wicked

Totally Wicked Arc pico grande Manual de usuario

Totally Wicked

Totally Wicked Odyssey Manual de usuario

Totally Wicked

Totally Wicked Totally Wicked Manual de usuario

Totally Wicked

Totally Wicked OPTIMUS Manual de usuario

Totally Wicked

Totally Wicked GRIP VT75 Manual de usuario

Manuales populares de Cigarrillo electrónico de otras marcas

STEAMAX

STEAMAX TFV8 X-BABY Manual de usuario

iQOS

iQOS 3 MULTI Manual de usuario

Vaporesso

Vaporesso LUXE XR MAX Manual de usuario

ZAZO

ZAZO PRO Mini 2 Manual de usuario

Aquafog

Aquafog Turbo XE Manual

Electronic Cigarettes Australia Pty Ltd

Electronic Cigarettes Australia Pty Ltd AUSSIE BLUE ENDURANCE Manual de usuario

UWELL

UWELL Whirl T1 Manual de usuario

VooPoo

VooPoo VMATE Manual de usuario

Yogs-Pfeifen

Yogs-Pfeifen E-PIPE nex KLASSIK Manual de usuario

TSI Instruments

TSI Instruments 3075 Manual de usuario

Vaporesso

Vaporesso GTX ONE Manual de usuario

VooPoo

VooPoo DRAG 2 Manual de usuario

Innova

Innova 3.0 Manual de usuario

Aquafog

Aquafog XE CRSM Manual de usuario

hi-Fun

hi-Fun hi-Cigarette Manual de usuario

Neptronic

Neptronic SKH Series Manual de usuario

Vaporesso

Vaporesso LUXE Q2 SE Manual de usuario

iQOS

iQOS 3 DUO Manual de usuario
