Totally Wicked ARC MINI Manual de usuario

USER MANUAL / BEDIENUNGSANLEITUNG

ELECTRONIC CIGARETTE KIT

Congratulations on purchasing your new

Totally Wicked arc Mini Electronic Cigarette.

The Totally Wicked arc Mini brings you a small, discreet easy to use device. Comfortable to

hold with outstanding variable power performance. The highlight is the LED display showing

power settings in volts or watts, battery charge level, ohms resistance and puff duration.

The voltage is adjustable from 3.3V to 5.0V and the wattage is adjustable from 5W to 20W

according to your vaping needs.

arc Mini Battery

1. LED display

2. Power button

3. “Up” button

4. “Down” button

5. Charging port

CS Micro Tank

6. Atomizer base

7. CS atomizer head (1.5 ohm)

8. Tank

9. Mouthpiece

Using your arc Mini

Power on and off:

Press the power button 5 times in quick

succession; the LED display will light and

show the percentage of battery power

remaining, the arc Mini is now on and

ready to use. The display will turn off after

10 seconds of inactivity, but will seamlessly

recover when any button is pressed. To turn

the arc Mini off, press the power button 5

times in quick succession.

To ﬁll the tank:

Remove the complete CS Micro Tank from the

arc Mini battery by unscrewing at the atomizer

base. Invert the tank, unscrew and remove the

atomizer base. Reﬁll the tank through one of

the apertures either side of the central air tube.

Do not place liquid in the central tube. Reﬁt the

atomizer base and screw the assembled tank

back onto the arc Mini battery.

Maximum reﬁll nozzle diameter: 2.8mm

Using your arc Mini

Vaping:

Press the power button as you inhale. When

the button is held down the LED display will

display vaping time in seconds for a period

of 2 seconds, the display will then show

battery power remaining as a percentage

for a further 2 seconds.

Vaping Time

Remaining Battery

Using your arc Mini

Vaping Time

Remaining Battery

Using your arc Mini

Changing output between volts and

watts:

Press the power button 3 times to go into

the power selection mode. Press either the

“up” or “down” buttons to cycle through

options.

Volts:

Cycle through the selections until the “V”

ﬂashes and then press the power button to

select voltage mode.

Watts:

Cycle through the selections until the “W”

ﬂashes and then press the power button to

select wattage mode.

In selection mode you can see the

remaining power, ohms resistance of the

atomizer in use and the power mode you

selected by pressing the “up” or “down”

buttons.

Using your arc Mini

Adjusting output level:

Output from the battery can be adjusted

by pressing the “up” or “down” buttons

momentarily whilst the arc Mini battery is

switched on. The LED display will show the

volts or watts as selected.

V/W DOWN V/W UP

Using your arc Mini

Charging the battery:

Remaining battery charge is indicated

on the LED display as a percentage of

remaining power, and the battery charge

indicator will ﬂash several times when

remaining charge is 10% or below. The

battery can be recharged using the supplied

USB cable. Connect the large USB plug

into a dedicated USB port or wall adaptor,

and connect the micro USB plug into the

USB port on the base of the arc Mini. When

connected, the LED will display “USB” for 2

seconds and then change to show the level

of charge for 10 seconds. The “%” will ﬂash

while the battery is charging, and will go out

when the battery is fully charged. The arc

Mini can be used normally during battery

charging.

Using your arc Mini
