USER MANUAL
3
THE TOTALLY WICKED ACTIVE
TOTALLY WICKED
ACTIVE
ELECTRONIC
CIGARETTE KIT
CONGRATULATIONS
ON PURCHASING YOUR
Charging
Port
Display Screen
Power
Button
Tank Connection
Adjustment
Buttons
Speaker Pause/Play
Button
Speaker
Power Button
Volume/Music
Control Buttons
Mouthpiece
Top Cap
Atomizer
Head
Airflow
Control
Ring
Acrylic
Sleeve
Tank Base
4 5
For those familiar with Wireless speakers, the steps below can be followed to allow
the device to be used in the shortest possible time:
• Press the speaker power button – the device will begin scanning for Wireless
devices
• Turn on the Wireless connection on your selected device and pair with the
“ACTIVE”
• Select the music you wish to play on your selected device
• Charge the battery (it may not have been shipped with a full charge)
Detailed descriptions of these steps and more are given in the full user guide.
For those familiar with e-cigarettes, the steps below can be followed to allow the
device to be used in the shortest possible time:
• Prime the atomizer head
• Fill the tank
• Switch the Active on
• Set the Active to wattage mode
• Check the power setting (we suggest 15 watts with the 1.3ohm atomizer head)
• Press the power button and inhale
• Charge the battery (it may not have been shipped with a full charge)
QUICK START GUIDE QUICK START GUIDE (WIRELESS SPEAKER)
6 7
Note: It is important to “prime” a new
atomizer head before first use. Failure
to do so can cause the atomizer coil to
overheat, leading to an unpleasant taste
and sometimes irreversible damage
to the atomizer head requiring early
replacement.
Remove the tank from the battery.
Turn the Active tank upside down and
unscrew the atomizer base from the
clear acrylic section of the tank.
Prime the fitted atomizer head by
slowly dripping e-liquid onto the cotton,
avoiding dripping e-liquid directly
down the centre of the atomizer head.
Continue to slowly drip e-liquid onto the
cotton until the cotton visible through
the sides of the atomizer head appears
to be saturated. Refit the atomizer base
onto the clear acrylic section of the tank
then screw the assembled tank back
onto the Active battery. Fill the tank.
PRIMING THE ATOMIZER HEAD PRIMING THE ATOMIZER HEAD
8 9
E-liquid Level
To avoid the atomizer head becoming
dry and burning prematurely, ensure
the e-liquid level does not drop below
half way down the acrylic section of
the tank.
Atomizer Head Lifespan
Atomizer heads do not last forever and
need to be periodically replaced. The
lifespan of an atomizer head can vary
from several days up to several weeks.
Factors affecting lifespan include
wattage, vaping style, flavour and type
of e-liquid. Indicators that the atomizer
head may require replacement include
a slight burnt taste, general loss of
vapour production or a reduction in
flavour intensity.
Slide the top cap open by
pushing firmly in the direction
indicated by the arrow on the
top cap to expose the fill hole.
Insert the filling nozzle into the
fill hole and fill the tank, being
careful to leave an air gap of
approximately 2mm. Slide the
top cap shut after filling.
FILLING THE TANK USING YOUR ACTIVE KIT
10 11
wattage settings will give a cooler and
less dense vapour than higher power
settings, higher power settings will
produce larger clouds of vapour but too
much power can lead to poor flavour,
or even a burnt taste in the vapour.
Experiment to find your preference.
Tip: Long pressing either of the
adjustment buttons allows quicker
changes to the wattage.
Vaping
Press and hold the power button as you
inhale the vapour.
Atomizer Head Protection
If the power button is held down for
longer than 10 seconds while vaping
the screen will display “Over 10s
protection” and the Active will refuse to
power or produce any vapour. Release
the power button to allow normal
operation to return.
Powering On and Off
To switch the Active on, quickly press
the power button 5 times. The screen
will activate indicating that the device
is powered on. To turn the Active off,
quickly press the power button 5 times.
Setting the Mode and Wattage
The atomizer heads supplied with the
Active are compatible with wattage
mode only, and will not work in
temperature control modes. To set the
Active to wattage mode, quickly press
the power button 3 times to enter the
mode selection menu, the screen will
display your current mode. Press either
adjustment button until you have found
“Wattage”, press the power button
once to confirm your selection. Lower
USING YOUR ACTIVE KIT USING YOUR ACTIVE KIT
12 13
Weak Battery Alert
If the battery cannot supply your desired
wattage the screen will display “WEAK
BATTERY” and the wattage will be
adjusted automatically to the maximum
which can be supplied. Charge the
Active using the steps outlined in
Charging the Battery below to allow
normal operation to resume.
Battery Low
Once the Active battery completely
depletes, the indicator on the screen
will begin to flash. If the Active is used
while the battery indicator is flashing,
the screen will state “BATTERY LOW”
pressing the button again will result in
the screen displaying “BATTERY LOW
LOCK!” Charge the Active using the
steps outlined in Charging the Battery
below to allow normal operation to
resume.
Adjusting the Airflow
If you find the airflow too airy or
too restrictive while vaping, it can
be adjusted by rotating the airflow
control ring located on the atomizer
base. Experiment to find your
preferred setting.
USING YOUR ACTIVE KIT USING YOUR ACTIVE KIT
14 15
Stealth Mode
If stealth mode is enabled, the display
will not activate while pressing the
power button to vape. The display will
still activate whenever the adjustment
buttons are pressed to make changes
to wattage or change modes, or if the
power button is pressed briefly. To
enable or disable stealth mode, ensure
the Active is powered on, then press
and hold the power button and left
adjustment button at the same time.
The screen will display “STEALTH
ON” if enabled and “STEALTH OFF” if
disabled.
Key Lock Mode
Key lock mode prevents accidental
changes to the wattage or temperature
settings. To enable or disable key lock
mode, ensure the Active is powered on,
then press and hold both adjustment
buttons at the same time to enable or
disable key lock mode. The screen will
Charging the Battery
The Active is charged by connecting
the charge port located beneath the
adjustment buttons to a USB port or
suitable wall adaptor with the charging
lead supplied. The silicone plug
covering the charge port will need to
be flipped down before connecting
a charger. The battery indicator will
display a lightning bolt while charging,
and after a few minutes the screen will
display an icon showing a battery being
charged.
Replacing the Atomizer Head
To replace the atomizer head, remove
the Active tank from the Active battery
by unscrewing at the atomizer base.
Turn the tank upside down, then
unscrew the atomizer base from the
acrylic section of the tank. Unscrew
the atomizer head from the atomizer
base and replace. After following the
instructions in “Priming the Atomizer
Head”, reassemble the tank and screw
the assembled tank back onto the
Active battery.
USING YOUR ACTIVE KIT SETTINGS
16 17
Bypass Mode:
Bypass mode provides an effectively
direct connection between the device’s
battery and the atomizer. As the battery
depletes, the device supplies less
power to the tank. To enter bypass
mode, ensure the Active is turned on
and quickly press the power button 3
times. Use either adjustment button to
scroll until “Bypass” is displayed and
press the power button to confirm.
Rotating the Display:
To rotate the display by 180°, turn the
Active off then press and hold both
adjustment buttons at the same time.
Turn the Active back on.
display “KEY LOCK” when enabled
and “KEY UNLOCK” when disabled. If
key lock mode is enabled the screen
will display “KEY LOCK” when the
adjustment buttons are pressed.
Adjustments cannot be made until the
key lock has been disabled.
Switch between Current,
Puff Counter or Total Time
Vaping Displayed
Ensure the Active is powered on, press
and hold the power button and the right
adjustment button. The bottom icon will
begin to flash, use either adjustment
button to find the icon wanted and
press the power button to confirm your
selection.
Note: you can reset the puff counter
and total time vaping to zero by holding
down both adjustment buttons while the
respective icon is flashing.
SETTINGS SETTINGS
18 19
Note: The atomizer heads supplied
with the Active kit are compatible with
wattage mode only, and will not work in
temperature control mode.
Adjusting Wattage in
Temperature Control/TCR Modes
The maximum wattage that is applied
in Temperature Control or TCR modes
can be adjusted. Higher wattages allow
the target temperature to be reached
quicker, while lower wattages increase
the time taken to reach the target
temperature. Setting the wattage too
low may prevent the target temperature
from being reached at all. To adjust
the maximum wattage, quickly press
the power button 4 times to enter the
wattage adjustment screen. Increase or
decrease the wattage until the desired
wattage is reached, press the power
button once to confirm the selection.
Switching to Temperature
Control Vaping Modes
Temperature Control vaping modes
can be used only when specific coil
materials have been used for atomizer
head manufacture, generally nickel (Ni),
titanium (Ti) or stainless steel (SS).
To select the appropriate temperature
control mode, quickly press the power
button 3 times to enter the mode
selection menu; Then press either
adjustment button to cycle between the
modes of wattage, bypass, temperature
(Ni, Ti, SS) or temperature (M1, M2,
M3). Press the power button once to
confirm the selection.
Only atomizer heads with coils made
from nickel, titanium or “316” stainless
steel are compatible with temperature
control mode. Select the appropriate
mode to match your atomizer type.
TEMPERATURE CONTROL SETTINGS TEMPERATURE CONTROL SETTINGS
Tabla de contenidos
Otros manuales de Cigarrillo electrónico de Totally Wicked
Totally Wicked
Totally Wicked ARC PALM Manual de usuario
Totally Wicked
Totally Wicked OPTIMUS Manual de usuario
Totally Wicked
Totally Wicked Tornado V5 BDC Manual de usuario
Totally Wicked
Totally Wicked Curve Manual de usuario
Totally Wicked
Totally Wicked Tornado EX2 Manual de usuario
Totally Wicked
Totally Wicked Totally Wicked Manual de usuario
Totally Wicked
Totally Wicked Polka Manual de usuario
Totally Wicked
Totally Wicked Rival Manual de usuario
Totally Wicked
Totally Wicked ARC 5 Manual de usuario
Totally Wicked
Totally Wicked Skope S Manual de usuario
Totally Wicked
Totally Wicked ARC GTI Manual de usuario
Totally Wicked
Totally Wicked INTU Mini Manual de usuario
Totally Wicked
Totally Wicked eGo-C+ Manual de usuario
Totally Wicked
Totally Wicked PENGUIN Manual de usuario
Totally Wicked
Totally Wicked Curve 2 Mini Manual de usuario
Totally Wicked
Totally Wicked Revolution S Manual de usuario
Totally Wicked
Totally Wicked Corsa Micro Manual de usuario
Totally Wicked
Totally Wicked GRIP VT75 Manual de usuario
Totally Wicked
Totally Wicked Rocket Manual de usuario
Totally Wicked
Totally Wicked Corsa Mini Manual de usuario
Manuales populares de Cigarrillo electrónico de otras marcas
STEAMAX
STEAMAX TFV8 X-BABY Manual de usuario
iQOS
iQOS 3 MULTI Manual de usuario
Vaporesso
Vaporesso LUXE XR MAX Manual de usuario
ZAZO
ZAZO PRO Mini 2 Manual de usuario
Aquafog
Aquafog Turbo XE Manual
Electronic Cigarettes Australia Pty Ltd
Electronic Cigarettes Australia Pty Ltd AUSSIE BLUE ENDURANCE Manual de usuario
