TomTom RIDER 2nd Edition Manual de usuario

TomTom RIDER

•

Chapter 1

What’s in the box

aYour TomTom RIDER

1. Touchscreen

2. On/off button

3. Docking connector

4. Memory card (SD card) slot

5. USB connector

6. Charging connector

7. Reset button

hA memory card (SD

card) containing the

application and maps

iMounting kit:

Holder, Handlebar

Mount, Handlebar

Adaptor, Mirror

Mount, Adhesive

Mount and the

adhesive pad

jScrews and Allen keys

for the mounting kit

kBattery cable

lHome charger, with

international

adaptors

mTomTom RIDER

case

•

nUSB cable oCD for Microsoft

Windows® or Apple

Macintosh®.

pBluetooth™ headset

module and headset

cable

qHelmet headset

rStandard headset sScreen cloth

tDocumentation pack uYour product code

card

•

Chapter 2

Before You Start...

Back Up Your TomTom RIDER

It’s always a good idea to make a backup of the contents of your

TomTom RIDER. You can make a backup using TomTom HOME.

For more information about TomTom HOME, see Using TomTom HOME on

page 65.

Secure your TomTom RIDER

Set a password for your TomTom RIDER so that only you can use it. Every

time you start your RIDER you will have to enter your password.

To set your password, run your RIDER using TomTom HOME. From the

Preferences menu, click Set owner to set a password.

To set the password, you have to run your RIDER using TomTom HOME. You

can then use TomTom HOME to set the password. To set a password on your

device, do the following:

1. Connect your RIDER to your computer and switch it on.

2. Start TomTom HOME if it does not start automatically.

If you do not have TomTom HOME installed, insert the CD that came with

your RIDER to install it.

Alternatively, you can download TomTom HOME from www.tomtom.com.

Make sure you always have the latest version of TomTom HOME. For more

information about TomTom HOME, see Using TomTom HOME on page 65.

3. In the Planning section, select your RIDER.

A picture of your RIDER is shown in the main section of TomTom HOME.

4. Click the On/Off button on the picture of your RIDER to switch it on in

TomTom HOME.

Your RIDER starts in TomTom HOME. You can now set the password on

your RIDER using TomTom HOME. Don't unplug your RIDER, just use it as

you normally would by clicking the buttons shown on your computer.

5. From the Main Menu in your device, click Change preferences.

6. Click Set owner. You may have to click the arrow until you reach the page

where Set owner is shown.

If you cannot find the button Set owner, make sure that all buttons are

shown in your RIDER. Tap the button Show ALL menu options. All buttons

will now be shown.

Set owner

•

You can now set the password for your RIDER. You can also set your name

and address, which will then be shown when your RIDER starts up.

Take care of your TomTom RIDER

It is important to take care of your RIDER and to clean it correctly.

• Use a soft cloth to wipe the screen of your RIDER; do not use any liquid

cleaners.

• If your RIDER gets wet, dry it with a soft cloth.

• Do not open the casing of your RIDER under any circumstances. Doing so

may be dangerous and will invalidate your warranty.

• Do not use the memory card (SD card) with any device other than a

TomTom device. Other devices may damage the memory card.

• Do not expose your RIDER to high or low temperatures, which can cause

permanent damage. For example, don’t leave it in the car on hot summer

days or during cold winter nights.

•

Chapter 3

Using your TomTom RIDER

Switching on

1. Open the compartment on the bottom of your TomTom RIDER.

2. Push the memory card into the memory card slot.

3. Press and hold the On/Off button for 2 seconds, or until your

TomTom RIDER starts.

The first time you switch on your TomTom RIDER, it may take up to 20

seconds to start. To switch off your TomTom RIDER, press and hold the On/

Off button for 2 seconds.

Setting up

First, you have to answer a few questions to set up your device and your

Bluetooth headset module. Answer the questions by tapping the screen. You

will use the touchscreen for everything you do with your TomTom RIDER.

Follow the instructions to establish a Bluetooth connection between your

TomTom RIDER and your Bluetooth headset module.

See the Bluetooth headset module section below for more information about

your Bluetooth headset module.

Once you have answered the questions, your TomTom RIDER will display the

Driving View.

The screen is shown in black and white until your TomTom RIDER locates

your current position. Once this is done, the Driving View is shown in full

color.

Locating your current position

Your TomTom RIDER must be outside to be able to locate your current

position. The first time you start your RIDER, it takes up to 5 minutes for the

device to find your current position.

In future, your position will be found much faster, normally within a few

seconds. If your RIDER takes longer than 5 minutes to locate your current

•

position, make sure that you are in an open place without tall buildings or trees

around you.

Your RIDER does not transmit your location, so others cannot use it to track

you while you are driving.

TomTom RIDER uses a GPS receiver to locate your current position. For more

information about GPS, see How Does Navigation Work? on page 67.

Bluetooth headset module

1. Indicators

2. Volume controls

3. On/off button

4. Charging connector

5. Headset connector

Before you can use your Bluetooth headset module with the helmet headset,

you must charge the headset module using the home charger.

Connect the headset cable to the Bluetooth headset module and then to the

helmet headset or standard headset.

Attach the Velcro pads provided to the inside of your helmet. These hold the

helmet headset in place.

To turn your Bluetooth headset module on, press and hold the On/Off button

until the blue indicator flashes 4 times.

Note: Before driving with your TomTom RIDER, we recommend that you

charge it fully using the home charger.

•

To turn your Bluetooth headset module off, press and hold the On/Off button

until the red indicator flashes 4 times.

If you did not establish a Bluetooth connection between your Bluetooth

headset module and your TomTom RIDER when you first turned your RIDER

on, you can establish the connection at any time.

From the Main Menu, tap Change Preferences. Tap Connect to headset and

follow the instructions to establish the connection.

•
