TomTom ONE XL•S

What’s in the box1.

What’s in the box

aYour TomTom ONE XL•S

(Maps for US & Canada are pre-

loaded in internal memory)

ACharging light

BTouchscreen

COn/Off button

DSpeaker

EExternal antenna connector

FUSB connector

GRDS-TMC connector

HMemory card slot (SD card not

included) for optional additional

maps

IReset button

bCar charger cDocumentation

pack

dWindshield

Holder

eUSB cable

fAdhesive disk for

windscreen mount

ACB

Before You Start...2.

Before You Start...

Switching on and off

To switch your TomTom ONE XL•S on or off, press and hold the On/Off

button for 2 seconds. The first time you switch on, it may take a short while for

your device to start.

Note: In rare cases, your ONE XL•S may not start correctly. If this happens,

press the reset button, then switch on the device again.

Setting up

To set up your TomTom ONE XL•S you need to answer a few questions by

tapping the screen.

Important: Take care to select the correct language, since the language you

choose will be used for all menus and written instructions.

Battery notes

For information on connecting your computer, see Using TomTom HOME

(63).

Note: Your TomTom ONE XL•S uses a small amount of battery power to

remember the last screen being shown when the device is switched off.

If you do not charge your ONE XL•S for a prolonged period of time, the next

time you start your ONE XL•S it will show the default starting screen. All other

device settings will still be maintained.

Improving reception

If your TomTom ONE XL•S takes longer than 5 minutes to find your current

position, make sure that the device is in an open space away from tall objects

such as buildings or trees.

When you connect your TomTom ONE XL•S to your computer, you can use

TomTom HOME to download information about GPS satellite positions during

the next 7 days. This helps your ONE XL•S to find your position faster.

Important: Some vehicles have heat reflective shielding in the windscreen.

This may prevent your ONE XL•S from locating your current position.

The TomTom External Antenna Kit (available for purchase as an accessory)

can help to improve reception.

Windshield Holder

Use the windshield holder to install your TomTom ONE XL•S inside your car.

To attach the holder, press the suction cup firmly to the windshield in your car,

in an area of the windshield where the glass is flat.

Make sure that both the holder and your windshield are clean and dry before

you attach the holder. Place the holder so that it does not interfere with your

view of the road.

Take care of your TomTom ONE XL•S

Never leave your TomTom ONE XL•S or accessories in view when you leave

the car or they may become an easy target for thieves.

You can set a password for your TomTom ONE XL•S which must be entered

every time you start your ONE XL•S. For more information, see Using

TomTom HOME (63).

It is important to take care of your ONE XL•S.

• Your ONE XL•S is not designed for use in extreme temperatures and any

such exposure may cause permanent damage.

• Do not open the casing of your ONE XL•S under any circumstances. Doing

so may be dangerous and will invalidate the warranty.

• Wipe or dry the screen of your ONE XL•S using a soft cloth. Do not use any

liquid cleaners.

Driving View3.

Driving View When your TomTom ONE XL•S starts, you are shown the Driving View along

with detailed information about your current location.

Tap the center of the screen at any time to open the Main Menu.

Note: The Driving View is shown in black and white until your ONE XL•S

locates your current position.

ATap + and - to zoom in and out.

BYour current position.

CThe name of the next major road or road sign information, if applicable.

DNavigation instruction for the road ahead.

Tap this area to repeat the last spoken instruction and to change the

volume.

EThe name of the next street to turn onto.

FInformation about your trip such as trip time, remaining distance and arrival

time.

To select what will be shown, tap Status bar preferences in the Preferences

menu.

GGPS signal strength.

HTraffic bar

To set up Traffic information, tap the Traffic bar to open the Traffic menu or

tap TomTom Traffic in the Main Menu.

Making your first trip4.

Making your first trip Planning a route with your TomTom ONE XL•S is easy. To plan your first

route, follow the steps below.

Important: You should always plan your journey before you start driving. It is

dangerous to plan a route while driving.

1. Tap the screen to bring up the main menu.

Note: The buttons on your ONE XL•S are shown in full color unless a button

is currently unavailable. For example, the button named Find alternative... in

the Main Menu is not available until you have planned a route.

2. Tap Navigate to...

3. Tap Address.

When you enter an address, you can choose from the following options:

•City center - tap this button to set your destination as the center of a city

or town.

•Street and house number - tap this button to set an exact address as your

destination.

•ZIP code - tap this button to enter a ZIP code as your destination.

•Cross street or intersection - tap this button to set your destination as the

point where two streets meet.

For your first trip, we will enter an exact address.

4. Tap Street and house number.

Note: When planning a trip for the first time your ONE XL•S asks you to

choose a state or country. Your choice is saved and used for all routes you

plan.

You can change this setting at any time by tapping the state symbol or country

flag.

5. Start to type the name of the town where you want to go.

As you type, the names of the towns that match what you have typed are

shown. When your destination appears in the list, tap the name of the town

to set the destination.

6. Start to type the name of the street and select it when it is shown.

As with the name of the town, the names of the streets that match what you

have typed are shown. When your destination appears in the list, tap the

name of the street to set the destination.

7. Now enter the house number of your destination and then tap Done.

8. Your ONE XL•S asks if you need to arrive at a particular time. For this

exercise, tap NO.

The route is calculated by your ONE XL•S.

9. When the route has been calculated, tap Done.

Your ONE XL•S will immediately begin to guide you to your destination, using

both spoken instructions and on-screen directions.

Arrival times

When you plan a route, your TomTom ONE XL•S asks you if you need to

arrive at a particular time.

Tap YES to enter a preferred arrival time.

Your ONE XL•S calculates your arrival time and shows you whether you will

arrive on time.

You can also use this information to work out when you need to leave. If your

ONE XL•S shows that you will arrive 30 minutes early, you can wait and leave

in 30 minutes time, rather than arrive early.

Your arrival time is constantly recalculated during your trip. The status bar

shows whether you will arrive on time or if you are going to be late, as shown

below:

You will arrive 55 minutes before the arrival time you entered.

If the estimated arrival time is more than five minutes before

the time you entered, it is shown in green.

You will arrive 3 minutes before the arrival time you entered.

If the estimated arrival time is less than 5 minutes before the

time you entered, it is shown in yellow.

You will arrive 19 minutes late.

If the estimated arrival time is later than the time you entered,

it is shown in red.

Status bar

preferences

Tap Status bar preferences in the Preferences menu, to enable or disable

arrival time notifications.

Select the required options on the first menu screen and then tap Done.

To enable arrival time notifications, select Show leeway to arrival time.

To disable arrival time notifications, unselect Show leeway to arrival time.

What are the other navigation options?

When you tap Navigate to..., you can set your destination in many ways, not

just by entering the address. The other options are listed below:

Home

Tap this button to navigate to your Home location.

You will probably use this button more than any other.

For information about setting your Home location, see Change Home

location (36).

Favorite

Tap this button to select a Favorite as your destination.

For more information about Favorites, see Favorites (19).

Address

Tap this button to enter an address as your destination.

Recent

destination

Tap this button to select your destination from a list of places you have

recently used as destinations.

Point of

Interest

Tap this button to navigate to a Point of Interest (POI).

For more information about POIs and navigating to a POI, see Points of

Interest (25).

GPS position

Tap this button to select your GPS position, as your destination.

For more information about GPS, see Global Positioning System (GPS)

(62).

Point on map

Tap this button to select a point on the map as your destination using the

map browser.

For more information about the map browser, see Driving View (5).

Latitude

Longitude

Tap this button to enter a destination using latitude and longitude values.

TomTom

Buddy

Tap this button to navigate to the current position of a TomTom Buddy.

Don’t forget that the Buddy may move before you reach him.

For more information about TomTom Buddies, see TomTom PLUS (44).

Planning a route in advance

You can also use your ONE XL•S to plan trips in advance by selecting both

your starting point and your destination. You could, for example, do the

following:

• Find out how long a trip is going to take before you start.

• Check the route of a trip you are planning.

• Check a route for someone who is coming to visit you so you can explain

the route to them.

To plan a route in advance, follow these steps:

1. Tap the screen to bring up the main menu.

2. Tap the arrow button to move to the next menu screen and tap Prepare

route.

3. Select the starting point for your trip in the same way that you would select

your destination.

4. Set the destination for your trip.

5. Choose the type of route that should be planned.

•Fastest route - the route which takes the least time.

•Shortest route - the shortest distance between the locations you set. This

may not be the quickest route, especially if the shortest route is through

a town or city.

•Avoid freeways - a route which avoids freeways.

•Walking route - a route designed for making the trip on foot.

•Bicycle route - a route designed for making the trip on a bicycle.

•Limited speed - a route for a vehicle which can only be driven at a limited

speed. You have to specify the maximum speed.

6. Your TomTom ONE XL•S plans the route between the two locations you

selected.

More information about a route

You can access these options for the route you last planned, by tapping View

route in the Main Menu.

To find out about your route in detail, tap the Details button on the route

summary screen.

Position of

last stop

Tap this button to select your last recorded position, as your destination.

For more information about the GPS, see Global Positioning System (GPS)

(62).

Prepare route

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de GPS de TomTom

TomTom

TomTom XXL 530S Manual de usuario

TomTom

TomTom NAVIGATOR Manual de usuario

TomTom

TomTom GO 740 Live Manual de usuario

TomTom

TomTom Blue&Me- Manual de usuario

TomTom

TomTom Go 920 Manual de usuario

TomTom

TomTom XL 350TM Manual de usuario

TomTom

TomTom GPS Receiver Manual de usuario

TomTom

TomTom PRO Manual de usuario

TomTom

TomTom Navigator Navigator 3 Manual de usuario

TomTom

TomTom RDS-TMC Manual de usuario

TomTom

TomTom LINK 510 Manual de usuario

TomTom

TomTom NAVIGATION SYSTEM Manual de usuario

TomTom

TomTom ONE Manual de usuario

TomTom

TomTom car kit for iPhone Manual de usuario

TomTom

TomTom LINK 3000 Manual de usuario

TomTom

TomTom LTO 200D Manual de usuario

TomTom

TomTom VIO Manual de usuario

TomTom

TomTom Connect Manual de usuario

TomTom

TomTom LINK 201 Manual de usuario

TomTom

TomTom Mobile Manual de usuario

TomTom

TomTom Go 2535M LIVE Manual de usuario

TomTom

TomTom Navigator Navigator 3 Manual de usuario

TomTom

TomTom ONE XL HDT Manual de usuario

TomTom

TomTom GO Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario
