2. Function
2.1 Product Function Table
2.2 LED indicator status description
Network indicator Yellow
GPS indicator Blue
The terminal detects the car ignition ACC ON or
Moving, starts continuous positioning, and uploads the
position data every 15s.
When ACC OFF is detected (Or stop more than 5
minutes) the position data is uploaded every 5 minutes
(the last ACC ON GPS positioning data is retained).
You can set the IP (or domain name), port number,
APN, local number, working mode, etc.
When the external power supply is cut off, the power
cut alarm will be reported.
When the vehicle power supply is detected to be low,
an alarm will be reported. The default is 11V.
ACC OFF status, when the vehicle vibration is
detected, the vibration alarm will be reported.
When the vehicle speeding，default 120km/h
GPRS/LTE communication is
normal, connect to the server
twinkle 1s bright, 4s off
GPRS/LTE communication is
normal, not connect to the server
twinkle 1s bright, 1s off
not registered on the network
LTE sleep / ACC off for 3minutes
