TomTom START Manual de usuario

TomTom START

Getting started1.

Get-

ting

started Mounting your navigation device

1. Push the EasyPort™ Mount on your TomTom START against the windshield in your car.

2. Adjust the angle of your device.

3. Lock the EasyPort Mount by twisting the base.

4. Insert the Car Charger into your device.

5. Insert the Car Charger into the cigarette lighter in your car.

6. Switch your device on by pressing the On/Off button on the top of your device.

7. You now have to answer some questions to set up your device. Tap the screen to

answer the questions.

8. To remove the Mount from your windshield, first unlock the EasyPort Mount, then gen-

tly pull one of the tabs. The Mount comes off of the windshield.

GPS reception

When you first start your TomTom START navigation device, the device may need a few minu-

tes to determine your GPS position and show your current position on the map. In the

future, your position will be found much faster, usually within a few seconds.

To ensure good GPS reception, you should use your device outdoors. Large objects such

as tall buildings can sometimes interfere with reception.

Troubleshooting

In rare cases, your TomTom START navigation device may not start correctly or may stop res-

ponding to your taps.

First, check that the battery is properly charged. To charge the battery, connect your

device to the car charger. It can take up to 2 hours to fully charge the battery.

If this does not solve the problem, you can reset the device. First turn your device off and

wait for at least 10 seconds. Then use a straightened paper clip, or something similar, to

push the reset button. The reset button is on the bottom of your device.

Driving View2.

Driving

View

1. Your current position.

2. The name of the next street or street sign information.

3. Your speed and the speed limit, if known.

Tap this area to repeat the last spoken instruction and to change the volume.

4. Navigation instruction for the road ahead.

Tap this panel on the status bar to switch between 2D and 3D views of the Driving View.

5. The name of the street you are on.

6. Information about your trip: trip time, remaining distance and arrival time.

Tap this panel on the status bar to see a route summary.

Advanced Lane Guidance3.

Advan-

ced

Lane

Gui-

dance Advanced Lane Guidance

Note: Lane guidance is not available for all junctions or in all countries.

Your TomTom START helps you prepare for highway exits and junctions by showing the cor-

rect driving lane for your planned route.

As you approach an exit or junction, the lane you need is shown on the screen.

For some exits and junctions, the lane you need is shown in the status bar.

Main Menu4.

Main

Menu The Main Menu is the starting point for planning a route, looking at a map or changing

your device settings.

To open the Main Menu from the Driving View, tap the center of the screen.

To return to the Driving View from the Main Menu, tap done.

Main Menu buttons

The following buttons are shown on the Main Menu.

Plan route

Tap this button to plan a new route.

This button is shown when you have not planned a route.

Change route

Tap this button to change the existing route or to plan a new route.

This button is shown when you have planned a route.

Browse map

Tap this button to look at the map.

Sound

sound

Tap this button to turn the sound off.

sound

Tap this button to turn the sound on.

Night /Day

night

Tap this button to set the night color scheme, which reduces the brightness of

the screen and shows the map using dark colors.

This is useful when driving at night or in dark environments such as long tunnels.

day

Tap this button to set the day color scheme, which increases the brightness of

the screen and shows the map using bright colors.

Options

options

Tap this button to adjust the settings for your device.

For more information, see the chapter Options.

Help

help

Tap this button to see contact details for local emergency services and other

specialized services, such as hospitals and veterinary clinics. You can then

plan a route to your chosen service center.

For more information, see the chapter Help.

Browse map5.

Browse

map To look at the map in the same way as you might look at a traditional paper map, tap

Browse map in the Main Menu.

You can move the map by touching the screen and sliding your finger across the screen.

1. Scale bar

2. Marker

Markers point to your current location, your home location and your destination. The

marker shows the distance to the location.

Tap a marker to center the map on the location pointed to by the marker.

3. POI button

Tap this button to select which POIs are shown.

4. Cursor

5. Find button

Tap this button to find specific addresses.

6. Cursor button

Tap this button to plan a route to the cursor position, create a Favorite at the cursor

position or find a Point of Interest near to the cursor position.

7. Zoom bar

Zoom in and out by moving the slider.

Planning a route6.

Plan-

ning a

route 1. Tap the screen to open the Main Menu.

2. Tap Plan route.

You can enter an address in various ways, but we will enter the full address.

3. Tap Address.

4. Start to type the name of the town where your trip will begin and tap on the name when

it appears in the list.

Tip: When you plan a route for the first time you are asked to select the country or state.

Your choice is saved and used for all future routes. You can change this setting by tapping

on the flag and selecting a new country or state.

5. Enter the street name and the house number, then tap Done.

Tip: Before you start to enter a street name, City center is shown at the top of the list. This

is useful if you do not have an address and only need general directions.

6. Tap Done.

The route is planned and a summary of the route is shown.

7. Tap Done.

Your navigation device is ready to guide you to your destination.

Planning a route with a new starting point

To plan a route in advance of traveling or to use a starting point that isn’t your current loca-

tion, do the following:

1. Tap the screen to open the Main Menu.

2. Tap Plan route.
