TomTom NAVIGATOR Manual de usuario
TomTom NAVIGATOR
Before You Start...1.
2
Before You Start...
Setting up
To start using your phone as a navigation device, tap the TomTom button in
the Windows Mobile start menu.
To set up your navigation device, you need to answer a few questions by
tapping the screen.
Important: Take care to select the correct language, since the language you
choose will be used for all menus and written instructions.
Activation
You will be asked how you want to activate the map that comes with
NAVIGATOR. There are two ways to do this:
• Automatically
To activate automatically, your device must have an active wireless data
connection (GPRS, EDGE, UMTS or CDMA).
Tap Automatic, then enter your product code. The product code is printed
on the product code card that is included with your product.
TomTom NAVIGATOR will connect to TomTom using the wireless data
connection and activate the map.
• Manually
To activate a map manually, do the following:
1. Tap Manual.
2. Go to this website: www.ttcode.com
3. Follow the instructions on this page to get an activation code.
4. Enter the activation code on your device to activate the map.
Improving reception
If your TomTom NAVIGATOR takes longer than 5 minutes to find your current
position, make sure that the device is in an open space away from tall objects
such as buildings or trees.
Important: Some vehicles have heat reflective shielding in the windshield.
This may prevent your NAVIGATOR from locating your current position.
3
Switching on and off
To switch your TomTom NAVIGATOR on or off, press and hold the On/Off
button for 2 seconds. The first time you switch on, it may take a short while for
your device to start.
Note: In rare cases, your NAVIGATOR may not start correctly. If this happens,
press the reset button, then switch on the device again.
To use your TomTom NAVIGATOR on your telephone, tap the NAVIGATOR
button.
Exit
application
To close TomTom NAVIGATOR, tap Exit application in the Main Menu. We
recommend that you close NAVIGATOR whenever you finish using the
application, since some of the phone settings are managed by NAVIGATOR
to enable you to place and receive phone calls while you are driving.
Driving View2.
4
Driving View When your TomTom NAVIGATOR starts, you are shown the Driving View
along with detailed information about your current location.
Tap the center of the screen at any time to open the Main Menu.
Note: The Driving View is shown in black and white until your NAVIGATOR
locates your current position.
ATap + and - to zoom in and out.
BQuick menu - swich this on in the Preferences menu.
CYour current position.
DThe name of the next major road or road sign information, if applicable.
ENavigation instruction for the road ahead.
Tap this area to repeat the last spoken instruction and to change the
volume.
FThe name of the street you are on.
GInformation about your trip such as trip time, remaining distance and arrival
time.
To change the information shown, tap Status bar preferences in the
Preferences menu.
HTraffic bar. For more information about how to subscribe to and receive
TomTom Traffic, go to tomtom.com/traffic.
5
To set up Traffic information, tap TomTom Traffic in the Main Menu.
Making your first trip3.
6
Making your first trip Planning a route with your TomTom NAVIGATOR is easy. To plan your first
route, follow the steps below.
Important: You should always plan your journey before you start driving. It is
dangerous to plan a route while driving.
1. Tap the screen to bring up the main menu.
Note: The buttons on your NAVIGATOR are shown in full color unless a button
is currently unavailable. For example, the button named Find alternative... in
the Main Menu is not available until you have planned a route.
2. Tap Navigate to...
3. Tap Address.
When you enter an address, you can choose from the following options:
•City center - tap this button to set your destination as the center of a city
or town.
•Street and house number - tap this button to set an exact address as your
destination.
•ZIP code - tap this button to enter a ZIP code as your destination.
7
•Cross street or intersection - tap this button to set your destination as the
point where two streets meet.
In this example, we will enter an exact address.
4. Tap Street and house number.
Note: When planning a trip for the first time your NAVIGATOR asks you to
choose a state or country. Your choice is saved and used for all routes you
plan.
You can change this setting at any time by tapping the state symbol or country
flag.
5. Start to type the name of the town where you want to go.
As you type, the names of the towns that match what you have typed are
shown. When your destination appears in the list, tap the name of the town
to set the destination.
6. Start to type the name of the street and select it when it is shown.
As with the name of the town, the names of the streets that match what you
have typed are shown. When your destination appears in the list, tap the
name of the street to set the destination.
7. Now enter the house number of your destination and then tap Done.
8
8. Your NAVIGATOR asks if you need to arrive at a particular time. For this
exercise, tap NO.
The route is calculated by your NAVIGATOR.
9. When the route has been calculated, tap Done.
Your NAVIGATOR will immediately begin to guide you to your destination,
using both spoken instructions and on-screen directions.
Arrival times
When you plan a route, your TomTom NAVIGATOR asks you if you need to
arrive at a particular time.
Tap YES to enter a preferred arrival time.
Your NAVIGATOR calculates your arrival time and shows you whether you will
arrive on time.
You can also use this information to work out when you need to leave. If your
NAVIGATOR shows that you will arrive 30 minutes early, you can wait and
leave in 30 minutes time, rather than arrive early.
Your arrival time is constantly recalculated during your trip. The status bar
shows whether you will arrive on time or if you are going to be late, as shown
below:
You will arrive 55 minutes before the arrival time you entered.
If the estimated arrival time is more than five minutes before
the time you entered, it is shown in green.
You will arrive 3 minutes before the arrival time you entered.
If the estimated arrival time is less than 5 minutes before the
time you entered, it is shown in yellow.
9
What are the other navigation options?
When you tap Navigate to..., you can set your destination in many ways, not
just by entering the address. The other options are listed below:
You will arrive 19 minutes late.
If the estimated arrival time is later than the time you entered,
it is shown in red.
Status bar
preferences
Tap Status bar preferences in the Preferences menu, to enable or disable
arrival time notifications.
Select the required options on the first menu screen and then tap Done.
To enable arrival time notifications, select Show leeway to arrival time.
Home
Tap this button to navigate to your Home location.
You will probably use this button more than any other.
Favorite
Tap this button to select a Favorite as your destination.
Address
Tap this button to enter an address as your destination.
Recent
destination
Tap this button to select your destination from a list of places you have
recently used as destinations.
Point of
Interest
Tap this button to navigate to a Point of Interest (POI).
Point on map
Tap this button to select a point on the map as your destination using the
map browser.
Latitude
Longitude
Tap this button to enter a destination using latitude and longitude values.
2
3
1
2
10
Planning a route in advance
You can also use your NAVIGATOR to plan trips in advance by selecting both
your starting point and your destination. You could, for example, do the
following:
• Find out how long a trip is going to take before you start.
• Check the route of a trip you are planning.
• Check a route for someone who is coming to visit you so you can explain
the route to them.
To plan a route in advance, follow these steps:
1. Tap the screen to bring up the main menu.
2. Tap the arrow button to move to the next menu screen and tap Prepare
route.
3. Select the starting point for your trip in the same way that you would select
your destination.
4. Set the destination for your trip.
5. Choose the type of route that should be planned.
•Fastest route - the route which takes the least time.
•Shortest route - the shortest distance between the locations you set. This
may not be the quickest route, especially if the shortest route is through
a town or city.
•Avoid freeways - a route which avoids freeways.
•Walking route - a route designed for making the trip on foot.
•Bicycle route - a route designed for making the trip on a bicycle.
•Limited speed - a route for a vehicle which can only be driven at a limited
speed. You have to specify the maximum speed.
6. Your TomTom NAVIGATOR plans the route between the two locations you
selected.
More information about a route
You can access these options for the route you last planned by tapping View
route in the Main Menu or the Details button on the route summary screen.
TomTom
Buddy
Tap this button to navigate to the last known position of a TomTom Buddy.
Don’t forget that the Buddy may move before you reach him.
Contact
Tap this button to navigate to the address of a contact on your device.
Prepare route
